2015 Specialized Stumpjumper EVO 29

Archived: 2015 Specialized Stumpjumper EVO 29 · Mountain Hardtail · Published sizes: S, M, L, XL

• Confirm the frame markings and seller description match this archived model. Note every component that differs from the published build.
• Record the frame serial number. It should be legible, unaltered and consistent with the seller’s ownership history.
• Find the size marking on the bicycle and confirm the fit before judging the condition or price.

Archived: Frame: M5 alloy, 29” EVO geometry, tapered headtube, PF30 BB, internal shift/brake routing, 142mm dropouts, PM 160 rear brake, replaceable alloy rear derailleur hanger · Fork: RockShox Pike RC 29, Solo Air spring, tapered alloy steerer, w/ lockout, compression, rebound adj., 15mm thru-axle, 120mm travel · Suspension

• Look for dents or shape changes and inspect the edges of welds around the head tube, bottom bracket, seat cluster and suspension mounts for hairline cracks.
• Stand behind and in front of the bicycle to look for obvious frame, fork or wheel misalignment. Ask directly about crashes, transport damage and repairs.

Archived: Fork: RockShox Pike RC 29, Solo Air spring, tapered alloy steerer, w/ lockout, compression, rebound adj., 15mm thru-axle, 120mm travel

• Inspect the fork stanchions for scratches or coating wear, look for oil or dirt rings at the seals, and cycle the fork through its travel while checking for binding or bushing play.
• Ask for dated fork-service records. A clean exterior does not establish the condition of internal seals, oil or bushings.

Archived: Group: SRAM mix · Shifters: SRAM X7, 10-speed, w/ MatchMaker clamp · Rear derailleur: SRAM X0 Type 2, 10-speed, mid cage · Crankset: SRAM X1 1000, X SYNC ring, PF30, 32T, 94mm BCD spider · Bottom bracket: SRAM, PF30, OS press-in bearings, sealed cartridge · Rear cogs: SRAM PG 1030, 10-speed, 11-36 · Chain: SRAM PC 1031, 10-speed, w/ PowerLink, nickel finish

• Shift through every available gear under light load. Hesitation, skipping or inconsistent indexing can reflect wear, damage, poor adjustment or mismatched replacement parts.
• Measure chain wear with a compatible gauge and inspect chainring, cassette or freewheel teeth. A new chain does not rule out wear in the remaining drivetrain.
• Turn the cranks slowly, feel for rough bearings and check for side-to-side play. Inspect crank arms, chainring bolts and pedal threads for looseness or damage.

Archived: Brakes: Shimano SLX BR-M675, hydraulic disc, metallic pads, S/M: 180mm rotor, Others: 160mm, Shimano SLX BR-M675, hydraulic disc, metallic pads, 160mm rotor

• Squeeze each lever firmly. It should feel consistent and return cleanly. Check levers, hoses and calipers for fluid, inspect pad thickness and contamination, and examine rotors for wear or bending.
• Before riding, test every installed brake separately at walking speed. Each should stop firmly and release cleanly without its control reaching the end of its usable travel.

Archived: Wheel size: 29 · Rims: Roval Traverse Fattie 29, alloy disc, 29mm inner width, 32h · Hubs: Specialized Hi Lo disc, sealed cartridge bearings, 15mm thru-axle, 32h, Specialized Hi Lo disc, 4 sealed cartridge bearings, 12mm thru-axle, 32h · Front tire: Specialized Ground Control, 60TPI, 2Bliss Ready, folding bead, 29x2.1"

• Spin both wheels and watch for side-to-side and vertical movement. Check spoke tension, rim condition and hub play.
• Inspect both tire casings for cuts, cracking, plugs, bulges or exposed threads and confirm the installed sizes are safe for the rims and available frame and fork clearance.
• Remove and reinstall or closely inspect both wheel-retention systems. Axles or quick releases should tighten correctly with undamaged threads, hardware and dropouts.

Archived: Headset: 1-1/8" and 1-1/2" threadless, Campy style upper with 1-1/2" lower, cartridge bearings · Handlebar: Specialized XC, mini rise, 7050 alloy, 8-backsweep, 6-upsweep, 10mm rise, 31.8mm · Stem: Specialized, forged alloy, 6-degree rise · Seatpost: Command Post XCP, carbon lower tube, 2-position height adjustable, internal routing, 35mm travel, 27.2mm · Saddle: Body Geometry Henge Comp, hollow Cr-Mo rails, 143mm · Pedals: Resin test ride, w/ toe clips, CEN std.

• Apply the front brake and rock the bike to check for headset play or notchiness. Inspect the stem, handlebar and clamp zones, then confirm every fastener and control is secure.
• Cycle the dropper post repeatedly. It should reach full travel, remain extended under load and have no unusual oil, excessive rotational play or damaged remote, cable, hose or battery.

• Before riding, confirm both wheels are secure, tires are safe, both brakes function, and the headset, handlebar, stem, cranks and pedals have no looseness.
• Begin at low speed. Test steering, braking and shifting progressively, then load the drivetrain and suspension only after the basic safety checks pass.
• Listen and feel for repeated knocks, grinding, skipping, brake pulsation or movement at joints. Stop the test if the bicycle cannot be controlled safely.
