2015 Specialized S-WORKS DEMO 8
Mountain Dual Suspension bicycle from the Velopedia specification archive.
- Original MSRP
- $9,000.00
- Sizes
- Short, Medium, Long, X-Long
- Colors
- SATIN/GLOSS RED/CARBON
- Archive ID
- 1115403
Current market
Checking current listings…Frameset
| Frame Construction | FACT 11m carbon, S3 Geometry, carbon front triangle, full carbon link and rear end, FACT IS construction, PF30 BB, full internal cable routing, 135mm dropouts, lipped and sealed cartridge bearing pivots, replaceable derailleur hanger, 200mm travel |
|---|---|
| Frame Material | Carbon Fiber/Aluminum |
| Fork | RockShox Boxxer Team 650b, coil spring, alloy steerer, compression and rebound adjust, 20mm thru-axle, 200mm travel |
| Fork Material | Suspension |
| Rear Shock | Custom Öhlins TTX22M, coil over w/ piggy back, spherical bearing mount, high/low speed compression, rebound adjust, 9.5x3.0", S: 52x297lb, M: 60x343lb, L: 68x388lb, XL: 76x434lb |
Drivetrain
| Component Group | DH mix |
|---|---|
| Shifters | SRAM X0 1 DH, 7-speed |
| Front Derailleur | None |
| Rear Derailleur | SRAM X01 DH Type 2, 7-speed, short cage |
| Crankset | SRAM X0 DH, BB30, carbon arms, triple base, w/ Gamut bashguard |
| Bottom Bracket | SRAM, BB30 to BSA 83mm adapter |
| Rear Cogs | SRAM X01 DH, 7-speed, 10-24 |
| Chain | SRAM PC-1130, 11-speed, w/ PowerLink, nickel finish |
| Pedals | Specialized Boomslang, 6061 alloy, sealed cartridge bearings |
Brakes
| Brakes | SRAM Guide RS DH, metallic pads, Code caliper, 200mm rotor, SRAM Guide RS DH, metallic pads, Code caliper, 200mm rotor |
|---|
Cockpit & Contact Points
| Headset | 1-1/2", semi-integrated for 1-1/8" steerer, loose ball bearings |
|---|---|
| Handlebar | S-Works DH, carbon, 8-degree backsweep, 6-degree upsweep, 31.8mm |
| Stem | Specialized P.Series MTB, direct mount, forged alloy, 4-bolt |
| Saddle | Body Geometry Phenom Expert, hollow Ti rails, 143mm |
| Seatpost | Thomson, alloy, straight, 12-degree clamp |
Wheels & Tires
| Hubs | Specialized Hi Lo disc, sealed cartridge bearings, 20mm thru-axle, 32h, Custom DT Swiss, Star Ratchet, XX1 driver body, 12mm thru-axle, 32h |
|---|---|
| Rims | Roval 650b, alloy, 24mm inner width, 32h |
| Spokes | DT Competition, stainless, 2.0mm |
| Front Tire | Specialized Butcher DH, 60TPI, wire bead, 650bx2.5", Specialized Slaughter DH, 60TPI, wire bead, 650bx2.3" |
| Wheel Size | 27.5 |
Specifications are presented as a reference. Components may vary by market, size, production run, or later manufacturer revisions.
