Velopedia Bicycle Archive
2015 Specialized EPIC ELITE M5 WORLD CUP
Mountain Dual Suspension bicycle from the Velopedia specification archive.
- Original MSRP
- $4,900.00
- Sizes
- S, M, L, XL
- Colors
- Satin/Gloss/Black/Dirty White/Red
- Archive ID
- 1244662
Image not yet recovered
Current market
Checking current listings…Frameset
| Frame Construction | M5 alloy, 29" World Cup Geometry, tapered headtube, World Cup mega-chainstays, single ring only, full internal shift/brake routing, 142mm dropouts, sealed cartridge bearing pivots, replaceable derailleur hanger, 95mm travel |
|---|---|
| Frame Material | Aluminum |
| Fork | RockShox SID 29 Brain, Solo Air spring, tapered alloy steerer, bottom-mount BrainFade, rebound adjust, 15mm thru-axle, 95mm travel |
| Fork Material | Suspension |
| Rear Shock | FOX/Specialized remote Mini-Brain w/ AUTOSAG, inertia valve, BrainFade adjust, 200x48mm, 95mm travel |
Drivetrain
| Component Group | SRAM X1 |
|---|---|
| Shifters | SRAM X1, 11-speed, trigger |
| Front Derailleur | None |
| Rear Derailleur | SRAM X1, 11-speed, alloy cage |
| Crankset | SRAM X1 1000, 11-speed, PF30, Clean Spider, 32T, 94mm BCD spider |
| Bottom Bracket | SRAM, PF30, OS press-in bearings, sealed cartridge |
| Rear Cogs | SRAM XG 1180, 11-speed, 10-42 |
| Pedals | Resin test ride, w/ toe clips, CEN std. |
Brakes
| Brakes | Magura MTS, hydraulic disc, Hi Friction pad, alloy master cylinder, alloy caliper, Storm SL rotor, S/M: 160mm rotor, Others: 180mm, Magura MTS, hydraulic disc, Hi Friction pad, alloy master cylinder, alloy caliper, 160mm Storm SL rotor |
|---|
Cockpit & Contact Points
| Headset | 1-1/8" and 1-1/2" threadless, Campy style upper with 1-1/2" lower, cartridge bearings |
|---|---|
| Handlebar | Specialized flat, 8-degree backsweep, 31.8mm |
| Stem | Specialized, forged alloy, 6-degree rise |
| Saddle | Body Geometry Phenom Comp, hollow Cr-Mo rails, 143mm |
| Seatpost | Specialized alloy, single bolt, 27.2mm |
Wheels & Tires
| Hubs | Roval Control Carbon 29, 15mm thru-axle, 32h, Roval Control Carbon 29 142+, DT Swiss Star Ratchet, XX1 driver body, 12mm thru-axle, 32h |
|---|---|
| Rims | Roval Control Carbon 29, carbon disc, hookless bead, 22mm internal width, 32h |
| Spokes | DT Swiss Revolution |
| Front Tire | S-Works Fast Trak Control, 120TPI, 2Bliss Ready, folding bead, 29x2.0", Specialized Fast Trak Control, 60TPI, 2Bliss Ready, folding bead, 29x2.0" |
| Wheel Size | 29 |
Specifications are presented as a reference. Components may vary by market, size, production run, or later manufacturer revisions.
