2004 Specialized Langster Pro

Original specifications: Track Mix drivetrain · 700c wheels · legacy reference geometry.

Share owner experience

Planning to sell? Draft your listing

At a glance

Archive #92322
Model year
2004
Category
Track
Original MSRP
$1,200.00
Sizes
50cm, 52cm, 54cm, 56cm, 58cm, 62cm
Colors
White, Silver
Geometry
Legacy reference
In this record
24 specifications · archived image · original MSRP · geometry
Model history 4 other years

Browse other years

Compare side by side

Identification clues

2004 archived details

Published colors
White, Silver
Frame
Specialized A1 aluminum
Original equipment
Track Mix

Clues, not proof of model year. Colors vary and components may have been replaced.

Original buildSpecialized A1 aluminum · Track Mix · 700c wheels

Manufacturer catalog

Published sizes and colors

6 sizes · 2 colors

Manufacturer-published sizes and colors; availability and exact size/color pairings may vary by market or production run.

Published sizes

50cm52cm54cm56cm58cm62cm

Published colors

WhiteSilver

Frameset

Frame ConstructionTIG-welded
Frame MaterialSpecialized A1 aluminum
ForkSpecialized C-3
Fork MaterialCarbon fiber composite w/aluminum steerer, unicrown crown

Drivetrain

Component GroupTrack Mix
CranksetSugino SG-75, 48 teeth
Bottom BracketSugino 75, 103mm spindle
BB Shell Width68mm English
Rear Cogs16 - 25 teeth
ChainIzumi V, 1/2 x 1/8"
PedalsNot included

Brakes

BrakesAluminum dual pivot rear

Cockpit & Contact Points

Headset1 1/8" integrated aluminum
HandlebarNitto Track Bend
Handlebar ExtensionsNot included
StemAluminum
SaddleSpecialized Turbo
SeatpostSpecialized aluminum, 27.2mm diameter

Wheels & Tires

HubsShimano Dura-Ace
RimsMavic Open Pro, 32-hole
SpokesDT Champion stainless steel, 15/17ga. (1.8/1.5mm) double-butted
Spoke NipplesAluminum nipples
Front Tire700 x 23c Specialized Mondo Comp
Wheel Size700c wheels

Geometry

Legacy reference · 6 measurements

Historical measurements. Frame size unknown.

All geometry measurementsLegacy reference · 6 measurements
MeasurementLegacy reference
Top tube555 mm
Head-tube angle74°
Seat-tube angle74.3°
Chainstay / rear center390 mm
Wheelbase968 mm
Fork offset / rake40 mm

Frame size not recorded.

Gearing

Original gearing is incomplete. Enter your setup to calculate ratios and cadence speeds.

Try your current gearingChanged tires or gears? Calculate your setup.

Your changes apply to this calculation. The archived build stays unchanged.

Your gearing setup
Gears

Use up to three front tooth counts, separated by /. For one rear sprocket, enter the same count twice.

Rear tire

Apply the marking on your rear tire or edit its dimensions below. Older or fractional inch sizes need the ISO marking (e.g. 37-590).

For 32-622, width is 32 mm and rim diameter is 622 mm. Use the rear tire on mixed-wheel bikes. Leave both fields empty to compare ratios only.

Gear, dimension and cadence changes update results automatically.

Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.

Parts & serviceability

Find replacement parts

Original specifications

Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.

Front tire · Original
700 x 23c Specialized Mondo Comp
Seatpost · Original
Specialized aluminum

27.2mm diameter

Saddle · Original
Specialized Turbo
More parts (3)Fewer parts
Handlebar · Original
Nitto Track Bend
Rims · Original
Mavic Open Pro

32-hole

Hubs · Original
Shimano Dura-Ace

Based on the original build. Check fit and installed parts before ordering.

Parts and service referenceQuick reference before buying parts

Archived specifications for reference. Check the fitted parts before ordering.

Front tire
700 x 23c Specialized Mondo Comp
Drivetrain
Track Mix
Seatpost diameter
27.2 mm
Bottom bracket / shell
Sugino 75, 103mm spindle · 68mm English
Equipment inspection checks 10 checks based on 5 archived component groups Open equipment checksClose equipment checks
0 of 10 checked Progress stays in this browser for this record.

Checks selected from the archived equipment. Confirm what is fitted today. This is not a complete safety inspection; use the full inspection guide before test riding.

Full used-bike inspection guide →

Archived: Frame: TIG-welded · Fork: Specialized C-3 · Carbon fiber composite w/aluminum steerer, unicrown crown

Archived: Group: Track Mix · Crankset: Sugino SG-75, 48 teeth · Bottom bracket: Sugino 75, 103mm spindle · Rear cogs: 16 - 25 teeth · Chain: Izumi V, 1/2 x 1/8"

Archived: Brakes: Aluminum dual pivot rear

Archived: Wheel size: 700c wheels · Rims: Mavic Open Pro, 32-hole · Hubs: Shimano Dura-Ace · Front tire: 700 x 23c Specialized Mondo Comp

Controls and contact points

Archived: Headset: 1 1/8" integrated aluminum · Handlebar: Nitto Track Bend · Stem: Aluminum · Seatpost: Specialized aluminum, 27.2mm diameter · Saddle: Specialized Turbo · Pedals: Not included
