Uses front tire 700C×23; rear size isn’t listed.
Velopedia Bicycle Archive
2000 Specialized Allez M4 Pro
Original specifications: Shimano Ultegra drivetrain · 700c wheels · legacy reference geometry.
Planning to sell? Draft your listing
At a glance
Archive #45151- Model year
- 2000
- Category
- Road
- Original MSRP
- $2,219.99
- Sizes
- 48cm, 50cm, 52cm, 54cm, 56cm, 58cm, 60cm, 62cm
- Colors
- Pearl Yellow/Black
- Geometry
- Legacy reference
- In this record
- 26 specifications · archived image · original MSRP · geometry
Model history 1 other year
Browse other years
Compare side by side
Identification clues
2000 archived details
- Published colors
- Pearl Yellow/Black
- Frame
- Specialized M4 Metal Matrix
- Original equipment
- Shimano Ultegra
Clues, not proof of model year. Colors vary and components may have been replaced.
Original buildSpecialized M4 Metal Matrix · Shimano Ultegra · 700c wheels
Frameset
| Frame Construction | TIG-welded |
|---|---|
| Frame Material | Specialized M4 Metal Matrix |
| Fork | Look Aero2 carbon |
| Fork Material | Carbon fiber composite, unicrown crown |
Drivetrain
| Component Group | Shimano Ultegra |
|---|---|
| Shifters | Shimano Ultegra STI Dual Control |
| Front Derailleur | Shimano Ultegra, braze-on |
| Rear Derailleur | Shimano Ultegra SS |
| Crankset | Shimano Ultegra, 39/53 teeth |
| Bottom Bracket | Shimano BB-6500 |
| Rear Cogs | 9-speed, 12 - 23 teeth |
| Chain | Shimano, 1/2 x 3/32" |
| Pedals | Not included |
Brakes
| Brakes | Shimano Ultegra Dual Pivot brakes, Shimano Ultegra STI levers |
|---|
Cockpit & Contact Points
| Headset | 1" threadless Tange Seiki |
|---|---|
| Handlebar | Ritchey Logic Road Pro |
| Handlebar Extensions | Not included |
| Stem | Ritchey Logic Pro |
| Saddle | Specialized Body Geometry Pro Leather |
| Seatpost | Ritchey Expert, 27.2mm diameter |
Wheels & Tires
| Hubs | Shimano Ultegra |
|---|---|
| Rims | Mavic Open Pro, 28-hole/32-hole |
| Spokes | DT stainless steel, 1.8mm double-butted |
| Spoke Nipples | Alloy nipples |
| Front Tire | 700 x 23c Specialized Turbo Team |
| Wheel Size | 700c wheels |
No specifications match. Try a component name or clear your search.
Geometry
Historical measurements. Frame size unknown.
Reference drawing
Select an available measurement to locate it on the frame.
All geometry measurementsLegacy reference · 6 measurements
| Measurement | Legacy reference |
|---|---|
| Top tube | 565 mm |
| Head-tube angle | 73° |
| Seat-tube angle | 73° |
| Chainstay / rear center | 405 mm |
| Wheelbase | 990 mm |
| Fork offset / rake | 43 mm |
Frame size not recorded.
Gearing
Lower gears help on climbs. Higher gears suit higher speeds.
RPM = pedal turns per minute.
How it works
Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.
Speeds are estimates from tire size and pedal cadence. Actual speeds vary.
Try your current gearingChanged tires or gears? Calculate your setup.
Your changes apply to this calculation. The archived build stays unchanged.
Gearing results
| Measure | Original | Your setup |
|---|---|---|
| Lowest ratio | — | — |
| Highest ratio | — | — |
| Total range | — | — |
| Lowest-gear speed | — | — |
| Highest-gear speed | — | — |
Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.
Parts & serviceability
Find replacement parts
Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.
27.2mm diameter
More parts (8)Fewer parts
39/53 teeth
braze-on
Based on the original build. Check fit and installed parts before ordering.
Parts and service referenceQuick reference before buying parts
Archived specifications for reference. Check the fitted parts before ordering.
- Front tire
- 700 x 23c Specialized Turbo Team
- Drivetrain
- 9-speed
- Seatpost diameter
- 27.2 mm
- Bottom bracket / shell
- Shimano BB-6500
Equipment inspection checks 10 checks based on 5 archived component groups Open equipment checksClose equipment checks
Checks selected from the archived equipment. Confirm what is fitted today. This is not a complete safety inspection; use the full inspection guide before test riding.
Full used-bike inspection guide →
Frame and fork
Inspect the frame and fork →Archived: Frame: TIG-welded · Fork: Look Aero2 carbon · Carbon fiber composite, unicrown crown
Drivetrain
Check drivetrain wear →Archived: Group: Shimano Ultegra · Shifters: Shimano Ultegra STI Dual Control · Front derailleur: Shimano Ultegra, braze-on · Rear derailleur: Shimano Ultegra SS · Crankset: Shimano Ultegra, 39/53 teeth · Bottom bracket: Shimano BB-6500 · Rear cogs: 9-speed, 12 - 23 teeth · Chain: Shimano, 1/2 x 3/32"
Brakes
Inspect the brakes →Archived: Brakes: Shimano Ultegra Dual Pivot brakes, Shimano Ultegra STI levers
Wheels and tires
Check wheels and tires →Archived: Wheel size: 700c wheels · Rims: Mavic Open Pro, 28-hole/32-hole · Hubs: Shimano Ultegra · Front tire: 700 x 23c Specialized Turbo Team
Controls and contact points
Archived: Headset: 1" threadless Tange Seiki · Handlebar: Ritchey Logic Road Pro · Stem: Ritchey Logic Pro · Seatpost: Ritchey Expert, 27.2mm diameter · Saddle: Specialized Body Geometry Pro Leather · Pedals: Not included
