2010 Schwinn Sierra 7

Original specifications: Shimano Tourney · 7-speed rear derailleur · 26" wheels.

Share owner experience

Planning to sell? Draft your listing

No archive photo is available for this record.

At a glance

Archive #21702
Model year
2010
Category
City & Commuter
Original MSRP
$319.99
Sizes
S, M, L, XL
Colors
Silver
In this record
25 specifications · original MSRP
Model history 2 other years

Browse other years

Compare side by side

Identification clues

2010 archived details

Published colors
Silver
Frame
Schwinn N' Gauged Hi-Ten
Original equipment
Comfort Mix

Clues, not proof of model year. Colors vary and components may have been replaced.

Original buildSchwinn N' Gauged Hi-Ten · Comfort Mix · 26" wheels

Historical catalog variants

Archived sizes and colors

4 item records

Item-level catalog entries recovered from Velopedia’s original bicycle archive. They document how this model was listed historically; they do not identify the frame size associated with legacy reference geometry or indicate current availability.

Published sizes

SMLXL

Published colors

Silver
View 4 archived size/color combinations
SizeColor
SSilver
MSilver
LSilver
XLSilver

Historical catalog evidence. Exact specifications and naming may vary by market, production run or manufacturer revision.

Frameset

Frame ConstructionTIG-welded
Frame MaterialSchwinn N' Gauged Hi-Ten
ForkSchwinn
Fork MaterialN' Gauged Hi-Ten, unicrown crown

Drivetrain

Component GroupComfort Mix
ShiftersSram MRX 204
Rear DerailleurShimano Tourney
CranksetPro Wheel, 36 teeth
Bottom BracketSealed cartridge JIS
CassetteShimano freewheel
Rear Cogs7-speed, 13 - 34 teeth
ChainKMC Z-51
PedalsResin body, steel cage & axle

Brakes

BrakesProMax linear-pull brakes, ProMax Aluminum w/reach adjust levers

Cockpit & Contact Points

Headset1 1/8" Threaded
Handlebar80mm rise, 30-degree bend
Handlebar ExtensionsNot included
StemAlloy Quill
SaddleComfort Tuned
SeatpostAlloy Suspension

Wheels & Tires

HubsKT alloy sealed mechanism QR
RimsWeinman TM-19, 32-hole
SpokesStainless steel, 14ga. (2.0mm)
Front Tire26 x 1.95" city tread
Wheel Size26" wheels

Gearing

Lower gears help on climbs. Higher gears suit higher speeds.

RPM

RPM = pedal turns per minute.

All published sizes36T · 13–34T · 7-speed
Lowest1.06:1 Highest2.77:1 Total range262%
Estimated speed At 90 RPM Lowest gear7.3 mph Highest gear19.2 mph

Uses front tire 26×1.95; rear size isn’t listed.

How it works

Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.

Speeds are estimates from tire size and pedal cadence. Actual speeds vary.

Try other gearing

Try your current gearingChanged tires or gears? Calculate your setup.

Your changes apply to this calculation. The archived build stays unchanged.

Your gearing setup
Gears

Use up to three front tooth counts, separated by /. For one rear sprocket, enter the same count twice.

Rear tire

Apply the marking on your rear tire or edit its dimensions below. Older or fractional inch sizes need the ISO marking (e.g. 37-590).

For 32-622, width is 32 mm and rim diameter is 622 mm. Use the rear tire on mixed-wheel bikes. Leave both fields empty to compare ratios only.

Gear, dimension and cadence changes update results automatically.

Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.

Parts & serviceability

Find replacement parts

Original specifications

Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.

Chain · Original
KMC Z-51
Front tire · Original
26 x 1.95" city tread Replacement search: 26x1.95 bicycle tire Before ordering: Check rim type and tire clearance.
Brake pads · Original
ProMax linear-pull brakes

ProMax Aluminum w/reach adjust levers

More parts (1)Fewer parts
Rear derailleur · Original
Shimano Tourney

Based on the original build. Check fit and installed parts before ordering.

Parts and service referenceQuick reference before buying parts

Archived specifications for reference. Check the fitted parts before ordering.

Front tire
26 x 1.95" city tread
Drivetrain
7-speed
Bottom bracket / shell
Sealed cartridge JIS
Equipment inspection checks 10 checks based on 5 archived component groups Open equipment checksClose equipment checks
0 of 10 checked Progress stays in this browser for this record.

Checks selected from the archived equipment. Confirm what is fitted today. This is not a complete safety inspection; use the full inspection guide before test riding.

Full used-bike inspection guide →

Archived: Frame: TIG-welded · Fork: Schwinn · N' Gauged Hi-Ten, unicrown crown

Archived: Group: Comfort Mix · Shifters: Sram MRX 204 · Rear derailleur: Shimano Tourney · Crankset: Pro Wheel, 36 teeth · Bottom bracket: Sealed cartridge JIS · Cassette: Shimano freewheel · Rear cogs: 7-speed, 13 - 34 teeth · Chain: KMC Z-51

Archived: Brakes: ProMax linear-pull brakes, ProMax Aluminum w/reach adjust levers

Archived: Wheel size: 26" wheels · Rims: Weinman TM-19, 32-hole · Hubs: KT alloy sealed mechanism QR · Front tire: 26 x 1.95" city tread

Controls and contact points

Archived: Headset: 1 1/8" Threaded · Handlebar: 80mm rise, 30-degree bend · Stem: Alloy Quill · Seatpost: Alloy Suspension · Saddle: Comfort Tuned · Pedals: Resin body, steel cage & axle
