Velopedia Bicycle Archive

2006 Schwinn Mini Mesa

Original specifications: 20" wheels.

Share owner experience

Planning to sell? Draft your listing

At a glance

Archive #11391
Model year
2006
Category
Kids
Original MSRP
$229.99
Sizes
10"
Colors
Brilliant Silver/WRX Blue
In this record
23 specifications · archived image · original MSRP
Model history 4 other years

Browse other years

Compare side by side

Identification clues

2006 archived details

Published colors
Brilliant Silver/WRX Blue
Frame
Aluminum
Original equipment
N/A

Clues, not proof of model year. Colors vary and components may have been replaced.

Original buildAluminum · 20" wheels

Historical catalog variants

Archived sizes and colors

1 item record

Item-level catalog entries recovered from Velopedia’s original bicycle archive. They document how this model was listed historically; they do not identify the frame size associated with legacy reference geometry or indicate current availability.

Published sizes

10"

Published colors

Brilliant Silver/WRX Blue
View 1 archived size/color combination
SizeColor
10"Brilliant Silver/WRX Blue

Historical catalog evidence. Exact specifications and naming may vary by market, production run or manufacturer revision.

Frameset

Frame ConstructionTIG-welded
Frame MaterialAluminum
ForkRST 181
Fork MaterialSteel/aluminum, single crown

Drivetrain

ShiftersSRAM MRX
Rear DerailleurShimano RD-FT-30 SS
CranksetSugino Urban, 36 teeth
Bottom BracketLoose ball, 126mm spindle
BB Shell Width68mm English
Rear Cogs7-speed, 14 - 28 teeth
ChainKMC Z51
PedalsNylon

Brakes

BrakesAluminum linear-pull brakes, aluminum/resin levers

Cockpit & Contact Points

Headset1 1/8" threadless steel ahead
HandlebarSteel
StemAlloy Ahead
SaddlePadded
SeatpostAluminum, 27.2mm diameter

Wheels & Tires

HubsAluminum
RimsAluminum, 36-hole
Spokes14ga. (2.0mm) straight gauge
Front Tire20 x 2.00" Innova IA-2070
Wheel Size20" wheels

Gearing

Lower gears help on climbs. Higher gears suit higher speeds.

RPM

RPM = pedal turns per minute.

All published sizes36T · 14–28T · 7-speed
Lowest1.29:1 Highest2.57:1 Total range200%
Estimated speed At 90 RPM Lowest gear6.9 mph Highest gear13.8 mph

Uses front tire 20×2; rear size isn’t listed.

How it works

Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.

Speeds are estimates from tire size and pedal cadence. Actual speeds vary.

Try other gearing

Try your current gearingChanged tires or gears? Calculate your setup.

Your changes apply to this calculation. The archived build stays unchanged.

Your gearing setup
Gears

Use up to three front tooth counts, separated by /. For one rear sprocket, enter the same count twice.

Rear tire

Apply the marking on your rear tire or edit its dimensions below. Older or fractional inch sizes need the ISO marking (e.g. 37-590).

For 32-622, width is 32 mm and rim diameter is 622 mm. Use the rear tire on mixed-wheel bikes. Leave both fields empty to compare ratios only.

Gear, dimension and cadence changes update results automatically.

Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.

Parts & serviceability

Find replacement parts

Original specifications
Chain · Original
KMC Z51
Front tire · Original
20 x 2.00" Innova IA-2070 Replacement search: 20x2 bicycle tire Before ordering: Check rim type and tire clearance.
More parts (2)Fewer parts
Brake pads · Original
Aluminum linear-pull brakes

aluminum/resin levers

Rear derailleur · Original
Shimano RD-FT-30 SS

Based on the original build. Check fit and installed parts before ordering. Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.

Parts and service referenceQuick reference before buying parts

Archived specifications for reference. Check the fitted parts before ordering.

Front tire
20 x 2.00" Innova IA-2070
Drivetrain
7-speed
Seatpost diameter
27.2 mm
Bottom bracket / shell
Loose ball, 126mm spindle · 68mm English
Equipment inspection checks 10 checks based on 5 archived component groups Open equipment checksClose equipment checks
0 of 10 checked Progress stays in this browser for this record.

Checks selected from the archived equipment. Confirm what is fitted today. This is not a complete safety inspection; use the full inspection guide before test riding.

Full used-bike inspection guide →

Archived: Frame: TIG-welded · Fork: RST 181 · Steel/aluminum, single crown

Archived: Shifters: SRAM MRX · Rear derailleur: Shimano RD-FT-30 SS · Crankset: Sugino Urban, 36 teeth · Bottom bracket: Loose ball, 126mm spindle · Rear cogs: 7-speed, 14 - 28 teeth · Chain: KMC Z51

Archived: Brakes: Aluminum linear-pull brakes, aluminum/resin levers

Archived: Wheel size: 20" wheels · Rims: Aluminum, 36-hole · Hubs: Aluminum · Front tire: 20 x 2.00" Innova IA-2070

Controls and contact points

Archived: Headset: 1 1/8" threadless steel ahead · Handlebar: Steel · Stem: Alloy Ahead · Seatpost: Aluminum, 27.2mm diameter · Saddle: Padded · Pedals: Nylon
