2004 Schwinn Automatic TJ Lavin Team
Freestyle/jumping bicycle from the Velopedia specification archive.
- Original MSRP
- $399.99
- Colors
- Black
- Archive ID
- 31332
Current market
Checking current listings…Frameset
| Frame Construction | TIG-welded |
|---|---|
| Frame Material | Chromoly |
| Fork | Schwinn |
| Fork Material | Chromoly, unicrown crown |
| Rear Shock | N/A |
Drivetrain
| Component Group | N/A |
|---|---|
| Shifters | N/A |
| Front Derailleur | N/A |
| Rear Derailleur | N/A |
| Crankset | Chromoly three-piece, 39 teeth |
| Rear Cogs | 1-speed, 14 teeth |
| Chain | KMC, 1/2 x 1/8" |
| Pedals | Die cast alloy |
Brakes
| Brakes | Tektro alloy U-brake rear brakes, Tektro rear levers |
|---|
Cockpit & Contact Points
| Headset | 1 1/8" threadless Tange-Seiki Fatty MX |
|---|---|
| Handlebar | Chromoly BMX |
| Handlebar Extensions | N/A |
| Stem | Aluminum threadless |
| Saddle | Padded freestyle, 8mm rails |
| Seatpost | 25.4mm diameter |
Wheels & Tires
| Hubs | Aluminum, 14mm axle |
|---|---|
| Rims | Sun Rims Black Box, 48-hole |
| Spokes | Stainless steel, 14ga. (2.0mm) straight gauge |
| Spoke Nipples | Brass nipples |
| Front Tire | Front: 20 x 2.10" Duro Jumper, Rear: 20 x 1.95 Duro Basket Case |
| Wheel Size | 20" wheels |
Specifications are presented as a reference. Components may vary by market, size, production run, or later manufacturer revisions.
