1998 Schwinn Circuit

Original specifications: Road Mix drivetrain · 700c wheels · legacy reference geometry.

Share owner experience

Planning to sell? Draft your listing

No archive photo is available for this record.

At a glance

Archive #73751
Model year
1998
Category
Road
Original MSRP
$1,199.95
Sizes
48 cm, 50 cm, 52 cm, 54 cm, 56 cm, 58 cm, 60 cm
Colors
Metallic red
Geometry
Legacy reference
In this record
24 specifications · original MSRP · geometry
Model history 3 other years

Browse other years

Compare side by side

Identification clues

1998 archived details

Published colors
Metallic red
Frame
7000 aluminum, butted
Original equipment
Road Mix

Clues, not proof of model year. Colors vary and components may have been replaced.

Sponsored affiliate link
Original build7000 aluminum, butted · Road Mix · 700c wheels

Manufacturer catalog

Published sizes and colors

7 sizes · 1 color

Manufacturer-published sizes and colors; availability and exact size/color pairings may vary by market or production run.

Published sizes

48 cm50 cm52 cm54 cm56 cm58 cm60 cm

Published colors

Metallic red

Frameset

Frame ConstructionTIG-welded
Frame Material7000 aluminum, butted
ForkRock Shox Ruby
Fork MaterialAluminum/magnesium, triple-clamp crown

Drivetrain

Component GroupRoad Mix
ShiftersShimano 105SC STI Dual Control
Front DerailleurShimano RX-100 top-swing
Rear DerailleurShimano RX-100 GS
CranksetShimano RX-100, 30/42/52 teeth
Rear Cogs8-speed, 13 - 26 teeth
Chain1/2 x 3/32"
PedalsScott clipless

Brakes

BrakesShimano RX-100 Dual Pivot brakes, Shimano 105SC levers

Cockpit & Contact Points

Headset1" Tioga sealed
HandlebarScott Drop
Handlebar ExtensionsNot included
StemKalloy aluminum
SaddleSelle San Marco Slim
SeatpostJD Components 495

Wheels & Tires

HubsFront: Formula aluminum, Q/R, Rear: Shimano RX-100
RimsMavic CXP 21, 32-hole
SpokesStainless steel, 2.0mm straight gauge
Front Tire700 x 23c Schwinn Natural 66
Wheel Size700c wheels

Geometry

Legacy reference · 6 measurements

Historical measurements. Frame size unknown.

All geometry measurementsLegacy reference · 6 measurements
MeasurementLegacy reference
Top tube560 mm
Head-tube angle74°
Seat-tube angle73.5°
Chainstay / rear center410 mm
Wheelbase983 mm
Fork offset / rake38.1 mm

Frame size not recorded.

Gearing

Lower gears help on climbs. Higher gears suit higher speeds.

RPM

RPM = pedal turns per minute.

All published sizes52/42/30T · 13–26T · 8-speed
Lowest1.15:1 Highest4.00:1 Total range347%
Estimated speed At 90 RPM Lowest gear8.1 mph Highest gear28.2 mph

Uses front tire 700C×23; rear size isn’t listed.

How it works

Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.

Speeds are estimates from tire size and pedal cadence. Actual speeds vary.

Try other gearing

Try your current gearingChanged tires or gears? Calculate your setup.

Your changes apply to this calculation. The archived build stays unchanged.

Your gearing setup
Gears

Use up to three front tooth counts, separated by /. For one rear sprocket, enter the same count twice.

Rear tire

Apply the marking on your rear tire or edit its dimensions below. Older or fractional inch sizes need the ISO marking (e.g. 37-590).

For 32-622, width is 32 mm and rim diameter is 622 mm. Use the rear tire on mixed-wheel bikes. Leave both fields empty to compare ratios only.

Gear, dimension and cadence changes update results automatically.

Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.

Parts & serviceability

Find replacement parts

Original specifications

Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.

Chain · Original
1/2 x 3/32" Replacement search: 8-speed bicycle chain Before ordering: Check chain width and length.
Front tire · Original
700 x 23c Schwinn Natural 66 Replacement search: 700cx23 bicycle tire Before ordering: Check rim type and tire clearance.
Front derailleur · Original
Shimano RX-100 top-swing
More parts (2)Fewer parts
Rear derailleur · Original
Shimano RX-100 GS
Rims · Original
Mavic CXP 21

32-hole

Based on the original build. Check fit and installed parts before ordering.

Parts and service referenceQuick reference before buying parts

Archived specifications for reference. Check the fitted parts before ordering.

Front tire
700 x 23c Schwinn Natural 66
Drivetrain
8-speed
Sponsored affiliate link
Equipment inspection checks 10 checks based on 5 archived component groups Open equipment checksClose equipment checks
0 of 10 checked Progress stays in this browser for this record.

Checks selected from the archived equipment. Confirm what is fitted today. This is not a complete safety inspection; use the full inspection guide before test riding.

Full used-bike inspection guide →

Archived: Frame: TIG-welded · Fork: Rock Shox Ruby · Aluminum/magnesium, triple-clamp crown

Archived: Group: Road Mix · Shifters: Shimano 105SC STI Dual Control · Front derailleur: Shimano RX-100 top-swing · Rear derailleur: Shimano RX-100 GS · Crankset: Shimano RX-100, 30/42/52 teeth · Rear cogs: 8-speed, 13 - 26 teeth · Chain: 1/2 x 3/32"

Archived: Brakes: Shimano RX-100 Dual Pivot brakes, Shimano 105SC levers

Archived: Wheel size: 700c wheels · Rims: Mavic CXP 21, 32-hole · Hubs: Front: Formula aluminum, Q/R, Rear: Shimano RX-100 · Front tire: 700 x 23c Schwinn Natural 66

Controls and contact points

Archived: Headset: 1" Tioga sealed · Handlebar: Scott Drop · Stem: Kalloy aluminum · Seatpost: JD Components 495 · Saddle: Selle San Marco Slim · Pedals: Scott clipless
