Uses front tire 26×2; rear size isn’t listed.
Velopedia Bicycle Archive
2002 Santa Cruz Heckler R Disc
Original specifications: Shimano Deore XT · 9-speed · mechanical rear derailleur · 26" wheels.
Planning to sell? Draft your listing
No archive photo is available for this record.
At a glance
Archive #37853- Model year
- 2002
- Category
- Mountain
- Original MSRP
- $2,230.00
- Sizes
- S, M, L, XL
- Colors
- Black, Gunmetal Grey, Red, Scuba Yellow, Sid Blue
- In this record
- 28 specifications · original MSRP
Model history 1 other year
Browse other years
Compare side by side
Identification clues
2002 archived details
- Published colors
- Black, Gunmetal Grey, Red, Scuba Yellow, Sid Blue
- Frame
- 6061 T6 butted aluminum w/replaceable derailleur hanger
- Original equipment
- Mountain Mix
Clues, not proof of model year. Colors vary and components may have been replaced.
Original build6061 T6 butted aluminum w/replaceable derailleur hanger · Mountain Mix · 26" wheels
Frameset
| Frame Construction | TIG-welded |
|---|---|
| Frame Material | 6061 T6 butted aluminum w/replaceable derailleur hanger |
| Fork | Fox F125RLC, 3.15" travel |
| Fork Material | Aluminum, triple-clamp crown |
| Rear Shock | Fox Float R, 5.0" travel |
Drivetrain
| Component Group | Mountain Mix |
|---|---|
| Shifters | Shimano Deore RapidFire SL |
| Front Derailleur | Shimano Deore LX, top-pull/clamp-on 31.8mm |
| Rear Derailleur | Shimano Deore XT SGS |
| Crankset | Shimano Deore LX, 22/32/44 teeth |
| Bottom Bracket | 113mm spindle |
| BB Shell Width | 68mm English |
| Rear Cogs | 9-speed, 11 - 32 teeth |
| Chain | Shimano CN-HG72, 1/2 x 3/32" |
| Pedals | Not included |
Brakes
| Brakes | Hayes/Magura Louise Hydraulic Disc brakes, Hayes/Magura Louise levers |
|---|
Cockpit & Contact Points
| Headset | 1 1/8" threadless Aheadset STS |
|---|---|
| Handlebar | Easton Monkey Bar |
| Handlebar Extensions | Not included |
| Stem | Titec Big AL |
| Saddle | WTB SST, hollow chromoly rails |
| Seatpost | Kalloy Uno, 27.2mm diameter |
Wheels & Tires
| Hubs | DT Swiss Onyx Disc |
|---|---|
| Rims | Front: Bontrager Valiant, Rear: Bontrager Valiant Assymetric, 32-hole |
| Spokes | DT stainless steel, double-butted |
| Spoke Nipples | Aluminum nipples |
| Front Tire | 26 x 2.00" Hutchinson Python |
| Wheel Size | 26" wheels |
No specifications match. Try a component name or clear your search.
Gearing
Lower gears help on climbs. Higher gears suit higher speeds.
RPM = pedal turns per minute.
How it works
Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.
Speeds are estimates from tire size and pedal cadence. Actual speeds vary.
Try your current gearingChanged tires or gears? Calculate your setup.
Your changes apply to this calculation. The archived build stays unchanged.
Gearing results
| Measure | Original | Your setup |
|---|---|---|
| Lowest ratio | — | — |
| Highest ratio | — | — |
| Total range | — | — |
| Lowest-gear speed | — | — |
| Highest-gear speed | — | — |
Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.
Parts & serviceability
Find replacement parts
Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.
27.2mm diameter

Race Face Ride XC Seatpost Black, 27.2x375mm
Replacement option
More parts (6)Fewer parts
hollow chromoly rails
22/32/44 teeth
Based on the original build. Check fit and installed parts before ordering.
Parts and service referenceQuick reference before buying parts
Archived specifications for reference. Check the fitted parts before ordering.
- Front tire
- 26 x 2.00" Hutchinson Python
- Drivetrain
- 9-speed
- Seatpost diameter
- 27.2 mm
- Bottom bracket / shell
- 113mm spindle · 68mm English
Equipment inspection checks 13 checks based on 6 archived component groups Open equipment checksClose equipment checks
Checks selected from the archived equipment. Confirm what is fitted today. This is not a complete safety inspection; use the full inspection guide before test riding.
Full used-bike inspection guide →
Frame and fork
Inspect the frame and fork →Archived: Frame: TIG-welded · Fork: Fox F125RLC, 3.15" travel · Aluminum, triple-clamp crown
Suspension
Evaluate the suspension →Archived: Fork: Fox F125RLC, 3.15" travel · Rear shock: Fox Float R, 5.0" travel
Drivetrain
Check drivetrain wear →Archived: Group: Mountain Mix · Shifters: Shimano Deore RapidFire SL · Front derailleur: Shimano Deore LX, top-pull/clamp-on 31.8mm · Rear derailleur: Shimano Deore XT SGS · Crankset: Shimano Deore LX, 22/32/44 teeth · Bottom bracket: 113mm spindle · Rear cogs: 9-speed, 11 - 32 teeth · Chain: Shimano CN-HG72, 1/2 x 3/32"
Brakes
Inspect the brakes →Archived: Brakes: Hayes/Magura Louise Hydraulic Disc brakes, Hayes/Magura Louise levers
Wheels and tires
Check wheels and tires →Archived: Wheel size: 26" wheels · Rims: Front: Bontrager Valiant, Rear: Bontrager Valiant Assymetric, 32-hole · Hubs: DT Swiss Onyx Disc · Front tire: 26 x 2.00" Hutchinson Python
Controls and contact points
Archived: Headset: 1 1/8" threadless Aheadset STS · Handlebar: Easton Monkey Bar · Stem: Titec Big AL · Seatpost: Kalloy Uno, 27.2mm diameter · Saddle: WTB SST, hollow chromoly rails · Pedals: Not included
Have you owned this model?Help document firsthand fit, ride and maintenance details that may no longer be available.
This archive record has limited published detail. Share what would help another rider understand how this model fit, rode and held up over time. Velopedia reviews every contribution before publication.
Already contributed? Send me a fresh private edit link
For privacy, Velopedia shows the same confirmation whether or not an experience exists.
No recent price sample is available for this bike. Check eBay for matching listings.
Find this bike on eBay
Search eBay US; check the model year, size and installed components. We may earn a commission from purchases.
Specifications are presented as a reference. Components may vary by market, size, production run, or later manufacturer revisions.
