Velopedia Bicycle Archive
1998 Santa Cruz Heckler (01)
Mountain bike, front & rear suspension bicycle from the Velopedia specification archive.
- Original MSRP
- $1,840.00
- Sizes
- 14", 16", 18", 20", 22"
- Colors
- Black, lime green, metallic green, orange, polished, red, Sid blue, Transparent Blue, Transparent Red, white, yellow
- Weight
- 26
- Archive ID
- 77365
Image not yet recovered
Current market
Checking current listings…Frameset
| Frame Construction | TIG-welded |
|---|---|
| Frame Material | 6061 T6 aluminum, double-butted |
| Fork | Rock Shox Judy T2 |
| Fork Material | Aluminum/magnesium, triple-clamp crown |
| Rear Shock | Fox Vanilla R, 4.25" travel |
Drivetrain
| Component Group | Mountain Mix |
|---|---|
| Shifters | Grip Shift SRT-600 |
| Front Derailleur | Shimano Deore LX top-swing, top-pull/clamp-on 31.8mm |
| Rear Derailleur | Shimano Deore LX GS |
| Crankset | Shimano Deore LX, 22/32/44 teeth |
| Bottom Bracket | Shimano BB-UN52, 107mm spindle |
| BB Shell Width | 68mm English |
| Rear Cogs | 8-speed, 11 - 30 teeth |
| Chain | Shimano CN-IG51, 1/2 x 3/32" |
| Pedals | Not included |
Brakes
| Brakes | Shimano Deore LX V-Brake brakes, Avid SD-1.9 L levers |
|---|
Cockpit & Contact Points
| Headset | 1 1/8" threadless Aheadset Kontak SA-2 |
|---|---|
| Handlebar | Azonic |
| Handlebar Extensions | Not included |
| Stem | Titec aluminum |
| Saddle | Bontrager |
| Seatpost | Kalloy Uno, 26.8mm diameter |
Wheels & Tires
| Hubs | Shimano STX-RC |
|---|---|
| Rims | Bontrager Red Label, 32-hole |
| Spokes | DT stainless steel, 1.8mm straight gauge |
| Spoke Nipples | Brass nipples |
| Front Tire | 26 x 1.95" IRC Mythos XC kevlar |
| Wheel Size | 26" wheels |
Specifications are presented as a reference. Components may vary by market, size, production run, or later manufacturer revisions.
