2026 Salsa Fargo Ti Frameset
Cyclocross/Gravel bicycle from the Velopedia specification archive.
- Original MSRP
- $3,299.00
- Sizes
- XS, S, M, L, XL
- Colors
- Titanium
- Geometry
- 5 manufacturer sizes · Ride analysis
- Archive ID
- 900000584
Current market
Snapshot not yet availableProtected live updateReady after page interactionAutomated crawlers do not trigger marketplace requests.
Move, scroll, tap or type to start the protected update.
Used-frameset inspection
If you’re buying this frameset used
Before buying: confirm the serial number and exact model, inspect frame and fork alignment, and inventory every included axle, hanger, clamp, headset part, cable guide and proprietary fitting.
Inspect the frame and fork →- FrameCheck paint chips, vent holes and the inside of the seat tube for corrosion. Also look for dents, bent tubes and cracking around welded or brazed joints.Inspect the frame and fork →
- Included hardwareInventory every axle, hanger, clamp, headset part, cable guide, frame plug and proprietary fitting included with the frameset. Confirm replacement availability before treating a missing small part as insignificant.
- AlignmentSight along the frame and fork from several directions. Confirm that the fork, rear dropouts, head tube and other visible interfaces appear straight; professional measurement is appropriate when alignment cannot be established visually.
Used-frameset inspection checklist 14 universal checks for a record with limited component data Open checklistClose checklist
The archived record does not contain enough component detail for a fully specification-informed frameset checklist. Use these universal checks on the frameset in front of you, inventory every included part and confirm exact interfaces before choosing components.
Identity and fit
Follow the full used-bike inspection order →Archived: 2026 Salsa Fargo Ti Frameset · Cyclocross/Gravel · Published sizes: XS, S, M, L, XL
Frame and fork
Inspect the frame and fork →Archived: Frame: Triple-butted CroMoly Steel · Fork: Carbon · Carbon Fiber
Alignment
Inspect the frame and fork →Frame interfaces
Inspect the bottom bracket and shell →Before accepting the frameset
Inspect the frame and fork →Have you owned this bike?Help preserve its real-world history by sharing your owner experience.
Share the details that would help another rider understand how this model fits, rides and holds up over time. Velopedia reviews every contribution before publication.
Already contributed? Send me a fresh private edit link
For privacy, Velopedia shows the same confirmation whether or not an experience exists.
Frameset
| Frame Construction | Triple-butted CroMoly Steel |
|---|---|
| Frame Material | Steel |
| Fork | Carbon |
| Fork Material | Carbon Fiber |
Cockpit & Contact Points
| Headset | FSA Orbit ITA |
|---|
Wheels & Tires
| Wheel Size | 29"; 27.5" |
|---|
Size-specific frame data
Geometry
Manufacturer-published geometry normalized for consistent archival comparison. Effective top tube and reach remain separate measurements because they describe different aspects of fit.
| Measurement | X-Small | Small | Medium | Large | X-Large |
|---|---|---|---|---|---|
| Seat tube | 355.6 mm | 406.4 mm | 457.2 mm | 508 mm | 558.8 mm |
| Effective top tube | 520 mm | 540 mm | 565 mm | 590 mm | 620 mm |
| Head tube | 90 mm | 110 mm | 140 mm | 170 mm | 190 mm |
| Head-tube angle | 68.5° | 69° | 69° | 69° | 69° |
| Seat-tube angle | 74° | 74° | 73° | 73° | 73° |
| Chainstay / rear center | 462 mm | 462 mm | 462 mm | 462 mm | 462 mm |
| Wheelbase | 1067 mm | 1083 mm | 1099 mm | 1126 mm | 1158 mm |
| Bottom-bracket drop | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm |
| Bottom-bracket height | 303 mm | 303 mm | 303 mm | 303 mm | 303 mm |
| Reach | 352 mm | 366 mm | 371 mm | 388 mm | 412 mm |
| Stack | 584 mm | 605 mm | 633 mm | 661 mm | 680 mm |
| Standover height | 690 mm | 732 mm | 778 mm | 821 mm | 859 mm |
| Fork offset / rake | 51 mm | 51 mm | 51 mm | 51 mm | 51 mm |
| Fork length / axle-to-crown | 483 mm | 483 mm | 483 mm | 483 mm | 483 mm |
Geometry source: Manufacturer HTML geometry table ↗ Measurements can vary by configuration, wheel size, or flip-chip position where noted by the manufacturer.
Geometry interpretation
What this geometry means
X-Small geometry
Riding position
The 584 mm stack is tall relative to the 352 mm reach, leaving room for a more upright, relaxed gravel position.
Handling tendencies
A 68.5° head angle combined with a 1067 mm wheelbase points to calm and stability-oriented steering and chassis behavior. The longer the chassis and slacker the front end, the more the bike tends to favor composure over very quick direction changes. The 462 mm chainstay is on the longer side for a drop-bar chassis, generally favoring stability and tire/heel clearance over an especially compact rear end.
Archive context
The chainstay of 462 mm sits toward the longer rear-center end. Its reach of 352 mm sits toward the shorter end. Its wheelbase of 1067 mm sits toward the longer end.
Small geometry
Riding position
The 605 mm stack is tall relative to the 366 mm reach, leaving room for a more upright, relaxed gravel position.
Handling tendencies
A 69° head angle combined with a 1083 mm wheelbase points to calm and stability-oriented steering and chassis behavior. The longer the chassis and slacker the front end, the more the bike tends to favor composure over very quick direction changes. The 462 mm chainstay is on the longer side for a drop-bar chassis, generally favoring stability and tire/heel clearance over an especially compact rear end.
Archive context
The chainstay of 462 mm sits toward the longer rear-center end. Its stack of 605 mm sits toward the taller end. Its reach of 366 mm sits toward the shorter end.
Medium geometry
Riding position
The 633 mm stack is tall relative to the 371 mm reach, leaving room for a more upright, relaxed gravel position.
Handling tendencies
A 69° head angle combined with a 1099 mm wheelbase points to calm and stability-oriented steering and chassis behavior. The longer the chassis and slacker the front end, the more the bike tends to favor composure over very quick direction changes. The 462 mm chainstay is on the longer side for a drop-bar chassis, generally favoring stability and tire/heel clearance over an especially compact rear end.
Archive context
The chainstay of 462 mm sits toward the longer rear-center end. Its reach of 371 mm sits toward the shorter end. Its stack of 633 mm sits toward the taller end.
Large geometry
Riding position
The 661 mm stack is tall relative to the 388 mm reach, leaving room for a more upright, relaxed gravel position.
Handling tendencies
A 69° head angle combined with a 1126 mm wheelbase points to calm and stability-oriented steering and chassis behavior. The longer the chassis and slacker the front end, the more the bike tends to favor composure over very quick direction changes. The 462 mm chainstay is on the longer side for a drop-bar chassis, generally favoring stability and tire/heel clearance over an especially compact rear end.
Archive context
The chainstay of 462 mm sits toward the longer rear-center end. Its stack of 661 mm sits toward the taller end. Its wheelbase of 1126 mm sits toward the longer end.
X-Large geometry
Riding position
The 680 mm stack is tall relative to the 412 mm reach, leaving room for a more upright, relaxed gravel position.
Handling tendencies
A 69° head angle combined with a 1158 mm wheelbase points to calm and stability-oriented steering and chassis behavior. The longer the chassis and slacker the front end, the more the bike tends to favor composure over very quick direction changes. The 462 mm chainstay is on the longer side for a drop-bar chassis, generally favoring stability and tire/heel clearance over an especially compact rear end.
Archive context
The chainstay of 462 mm sits toward the longer rear-center end. Its stack of 680 mm sits toward the taller end. Its wheelbase of 1158 mm sits toward the longer end.
Across the size range
From X-Small to X-Large, reach grows by 60 mm and stack by 96 mm, showing how the frame becomes both longer and taller through the published size range. The rear center stays essentially constant at about 462 mm across sizes, so most of the wheelbase growth happens in the front half of the bike rather than by lengthening the rear triangle.
Geometry describes frame proportions and likely tendencies, not a ride test. Rider proportions, cockpit setup, tires, suspension settings, wheel configuration, and component choices can materially change how a bicycle fits and feels.
