Velopedia Bicycle Archive

2019 Salsa Warroad C Frameset

Road bicycle from the Velopedia specification archive.

Original MSRP: $2,199.00
Sizes: 49cm; 52.5cm; 54.5cm; 56cm; 57.5cm; 59cm; 61cm
Colors: Black
Geometry: 7 manufacturer sizes
Archive ID: 900000637

Recently checked market

0 close matches

Observed used market No listingsNo close used matches in the latest snapshot.

New asking No listingsNo close matches in this condition.

View market details

Frameset

Frame Construction	Warroad Carbon
Frame Material	Carbon Fiber
Fork	Warroad Carbon Deluxe
Fork Material	Carbon Fiber

Cockpit & Contact Points

Headset	Cane Creek 40

Wheels & Tires

Wheel Size	29"; 27.5"; 26"

Size-specific frame data

Geometry

7 sizes · 15 measurements

Manufacturer-published geometry normalized for consistent archival comparison. Effective top tube and reach remain separate measurements because they describe different aspects of fit.

Measurement	49cm	52.5cm	54.5cm	56cm	57.5cm	59cm	61cm
Seat tube	400 mm	450 mm	485 mm	520 mm	530 mm	555 mm	580 mm
Effective top tube	499 mm	525 mm	545 mm	560 mm	575 mm	590 mm	610 mm
Head tube	92 mm	132 mm	152 mm	172 mm	192 mm	212 mm	232 mm
Head-tube angle	70.5°	71°	71°	71°	71°	71°	71°
Seat-tube angle	75°	74°	73°	73°	73°	73°	72.5°
Chainstay / rear center	415 mm	415 mm	415 mm	415 mm	415 mm	415 mm	415 mm
Wheelbase	980 mm	994.33 mm	1004.68 mm	1020.41 mm	1036.14 mm	1051.87 mm	1066.47 mm
Bottom-bracket drop	72 mm	72 mm	72 mm	72 mm	72 mm	72 mm	72 mm
Reach	363.14 mm	368.25 mm	372.1 mm	381.31 mm	390.54 mm	399.75 mm	407.83 mm
Stack	507.02 mm	546.64 mm	565.55 mm	584.46 mm	603.73 mm	622.28 mm	641.19 mm
Standover height	665.27 mm	717.9 mm	747.41 mm	761.44 mm	787.56 mm	809.98 mm	832.12 mm
Fork offset / rake	51 mm	51 mm	51 mm	51 mm	51 mm	51 mm	51 mm
Fork length / axle-to-crown	390 mm	390 mm	390 mm	390 mm	390 mm	390 mm	390 mm
Crank length	165 mm	170 mm	170 mm	172.5 mm	172.5 mm	175 mm	175 mm
Stem length	70 mm	70 mm	80 mm	90 mm	90 mm	100 mm	110 mm

Geometry source: Salsa first-party metric geometry table ↗ Measurements can vary by configuration, wheel size, or flip-chip position where noted by the manufacturer.
