Velopedia Bicycle Archive
2001 Rocky Mountain Pipeline
Original specifications: Shimano Deore XT · 9-speed · mechanical rear derailleur · legacy reference geometry.
Planning to sell? Draft your listing
At a glance
Archive #35112- Model year
- 2001
- Category
- Mountain
- Original MSRP
- $2,490.00
- Sizes
- 16.5", 18", 19.5"
- Colors
- Grey and black
- Geometry
- Legacy reference
- In this record
- 26 specifications · archived image · original MSRP · geometry
Model history 3 other years
Browse other years
Compare side by side
Identification clues
2001 archived details
- Published colors
- Grey and black
- Frame
- Easton Custom DH
- Original equipment
- Mountain Mix
Clues, not proof of model year. Colors vary and components may have been replaced.
Original buildEaston Custom DH · Mountain Mix
Frameset
| Frame Construction | TIG-welded |
|---|---|
| Frame Material | Easton Custom DH |
| Fork | Marzocchi Bomber Z-3 Long Travel |
| Fork Material | Aluminum, triple-clamp crown |
| Rear Shock | Fox Vanilla R, 4" to 6" travel |
Drivetrain
| Component Group | Mountain Mix |
|---|---|
| Shifters | Shimano Deore LX RapidFire SL |
| Front Derailleur | Shimano Deore LX top-swing, top-pull/clamp-on 31.8mm |
| Rear Derailleur | Shimano Deore XT SGS |
| Crankset | Race Face Prodigy, 22/32/44 teeth |
| Bottom Bracket | Shimano BB-UN52 |
| BB Shell Width | 73mm English |
| Rear Cogs | 9-speed |
| Chain | SRAM, 1/2 x 3/32" |
| Pedals | Shimano PD-M424 SPD |
Brakes
| Brakes | Hayes Hydraulic Disc brakes, Hayes Hydraulic Disc levers |
|---|
Cockpit & Contact Points
| Headset | 1 1/8" threadless Rocky Mountain Pig DH |
|---|---|
| Handlebar | Rocky Mountain DH #1 riser |
| Handlebar Extensions | Not included |
| Stem | Rocky Mountain Pig DH |
| Saddle | Selle Italia XO |
| Seatpost | Race Face Prodigy, 26.8mm diameter |
Wheels & Tires
| Hubs | Rocky Mountain Disk |
|---|---|
| Rims | Sun Rims Rhyno Lite |
| Spokes | DT stainless steel |
| Front Tire | Maxxis Mobster |
No specifications match. Try a component name or clear your search.
Geometry
Historical measurements. Frame size unknown.
Reference drawing
Select an available measurement to locate it on the frame.
All geometry measurementsLegacy reference · 4 measurements
| Measurement | Legacy reference |
|---|---|
| Top tube | 590 mm |
| Seat-tube angle | 73.5° |
| Chainstay / rear center | 430 mm |
| Wheelbase | 1083 mm |
Frame size not recorded.
Gearing
Original gearing is incomplete. Enter your setup to calculate ratios and cadence speeds.
Try your current gearingChanged tires or gears? Calculate your setup.
Your changes apply to this calculation. The archived build stays unchanged.
Gearing results
| Measure | Original | Your setup |
|---|---|---|
| Lowest ratio | — | — |
| Highest ratio | — | — |
| Total range | — | — |
| Lowest-gear speed | — | — |
| Highest-gear speed | — | — |
Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.
Parts & serviceability
Find replacement parts
More parts (4)Fewer parts
22/32/44 teeth
26.8mm diameter
Based on the original build. Check fit and installed parts before ordering. Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.
Parts and service referenceQuick reference before buying parts
Archived specifications for reference. Check the fitted parts before ordering.
- Front tire
- Maxxis Mobster
- Drivetrain
- 9-speed
- Seatpost diameter
- 26.8 mm
- Bottom bracket / shell
- Shimano BB-UN52 · 73mm English
Equipment inspection checks 13 checks based on 6 archived component groups Open equipment checksClose equipment checks
Checks selected from the archived equipment. Confirm what is fitted today. This is not a complete safety inspection; use the full inspection guide before test riding.
Full used-bike inspection guide →
Frame and fork
Inspect the frame and fork →Archived: Frame: TIG-welded · Fork: Marzocchi Bomber Z-3 Long Travel · Aluminum, triple-clamp crown
Suspension
Evaluate the suspension →Archived: Fork: Marzocchi Bomber Z-3 Long Travel · Rear shock: Fox Vanilla R, 4" to 6" travel
Drivetrain
Check drivetrain wear →Archived: Group: Mountain Mix · Shifters: Shimano Deore LX RapidFire SL · Front derailleur: Shimano Deore LX top-swing, top-pull/clamp-on 31.8mm · Rear derailleur: Shimano Deore XT SGS · Crankset: Race Face Prodigy, 22/32/44 teeth · Bottom bracket: Shimano BB-UN52 · Rear cogs: 9-speed · Chain: SRAM, 1/2 x 3/32"
Brakes
Inspect the brakes →Archived: Brakes: Hayes Hydraulic Disc brakes, Hayes Hydraulic Disc levers
Wheels and tires
Check wheels and tires →Archived: Rims: Sun Rims Rhyno Lite · Hubs: Rocky Mountain Disk · Front tire: Maxxis Mobster
Controls and contact points
Archived: Headset: 1 1/8" threadless Rocky Mountain Pig DH · Handlebar: Rocky Mountain DH #1 riser · Stem: Rocky Mountain Pig DH · Seatpost: Race Face Prodigy, 26.8mm diameter · Saddle: Selle Italia XO · Pedals: Shimano PD-M424 SPD
Have you owned this model?Help preserve its real-world history by sharing your owner experience.
Share the details that would help another rider understand how this model fits, rides and holds up over time. Velopedia reviews every contribution before publication.
Already contributed? Send me a fresh private edit link
For privacy, Velopedia shows the same confirmation whether or not an experience exists.
No recent price sample is available for this bike. Check eBay for matching listings.
Find this bike on eBay
Search eBay US; check the model year, size and installed components. We may earn a commission from purchases.
Specifications are presented as a reference. Components may vary by market, size, production run, or later manufacturer revisions.
