Velopedia Bicycle Archive
2009 Redline Proline Pitboss
BMX bicycle from the Velopedia specification archive.
- Original MSRP
- $0.00
- Colors
- Silver
- Weight
- 15.4
- Archive ID
- 15919
Current market
Checking current listings…Frameset
| Frame Construction | TIG-welded |
|---|
| Frame Material | 6061 T6 aluminum |
|---|
| Fork | Redline |
|---|
| Fork Material | Chromoly, unicrown crown |
|---|
| Rear Shock | N/A |
|---|
Drivetrain
| Component Group | BMX |
|---|
| Shifters | N/A |
|---|
| Front Derailleur | N/A |
|---|
| Rear Derailleur | N/A |
|---|
| Crankset | AC MiniLE 3-Piece, 36 teeth |
|---|
| Bottom Bracket | VP Euro Cartridge |
|---|
| Cassette | Freewheel |
|---|
| Rear Cogs | 1-speed, 16 teeth |
|---|
| Chain | KMC Z30 |
|---|
| Pedals | Redline Jr. Aluminum |
|---|
Brakes
| Brakes | Tektro BX-1V V-type rear brakes, Tektro 317A rear levers |
|---|
Cockpit & Contact Points
| Headset | VP |
|---|
| Handlebar | Redline Aluminum |
|---|
| Handlebar Extensions | Not included |
|---|
| Stem | Redline Proline Mini |
|---|
| Saddle | Redline Microline Mini |
|---|
| Seatpost | Integrated Aluminum Post, 22.2mm (7/8 inch) diameter |
|---|
Wheels & Tires
| Hubs | Front: Redline aluminum, Rear: Redline Aluminum Flip-Flop |
|---|
| Rims | Alex C-1000 |
|---|
| Spokes | Stainless steel |
|---|
| Front Tire | 16 x 1.75" |
|---|
| Wheel Size | 16" wheels |
|---|
Specifications are presented as a reference. Components may vary by market, size, production run, or later manufacturer revisions.
