Uses front tire 700C×25; rear size isn’t listed.
Velopedia Bicycle Archive
2008 Redline R550
Original specifications: Shimano Sora · 9-speed · mechanical rear derailleur · 700c wheels.
Planning to sell? Draft your listing
No archive photo is available for this record.
At a glance
Archive #14210- Model year
- 2008
- Category
- Road
- Original MSRP
- $749.99
- Sizes
- XS, S, M, M/L, L, XL
- Colors
- Silver, Black, Red
- In this record
- 25 specifications · original MSRP
Original build6061 Alloy Double Butted · Road Mix · 700c wheels
Frameset
| Frame Construction | TIG-welded |
|---|---|
| Frame Material | 6061 Alloy Double Butted |
| Fork | Redline RCT |
| Fork Material | Carbon fiber/aluminum steerer, aero crown |
Drivetrain
| Component Group | Road Mix |
|---|---|
| Shifters | Shimano |
| Front Derailleur | Shimano Sora |
| Rear Derailleur | Shimano Sora |
| Crankset | FSA, 30/39/50 teeth |
| Bottom Bracket | FSA square taper, 116mm spindle |
| BB Shell Width | 68mm |
| Cassette | SRAM 950 |
| Rear Cogs | 9-speed, 11 - 26 teeth |
| Pedals | Alloy road w/ toe clips and strap |
Brakes
| Brakes | Tektro 730 dual pivot brakes, Tektro levers |
|---|
Cockpit & Contact Points
| Headset | 1 1/8" FSA Integrated |
|---|---|
| Handlebar | Redline flat |
| Handlebar Extensions | Not included |
| Stem | Redline Alloy |
| Saddle | Velo Plush |
| Seatpost | Redline Alloy, 27.2mm diameter |
Wheels & Tires
| Hubs | Alex AKX R1.0 |
|---|---|
| Rims | Alex AKX R1.0, 28-hole/32-hole |
| Front Tire | 700 x 25c Kenda Kwest |
| Wheel Size | 700c wheels |
No specifications match. Try a component name or clear your search.
Gearing
Lower gears help on climbs. Higher gears suit higher speeds.
RPM = pedal turns per minute.
How it works
Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.
Speeds are estimates from tire size and pedal cadence. Actual speeds vary.
Try your current gearingChanged tires or gears? Calculate your setup.
Your changes apply to this calculation. The archived build stays unchanged.
Gearing results
| Measure | Original | Your setup |
|---|---|---|
| Lowest ratio | — | — |
| Highest ratio | — | — |
| Total range | — | — |
| Lowest-gear speed | — | — |
| Highest-gear speed | — | — |
Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.
Parts & serviceability
Find replacement parts
Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.

Vittoria Zaffiro Pro V Clincher Tire Black, 700x25
700x25c
Replacement option
27.2mm diameter

Race Face Ride XC Seatpost Black, 27.2x375mm
Replacement option
More parts (2)Fewer parts
Based on the original build. Check fit and installed parts before ordering.
Parts and service referenceQuick reference before buying parts
Archived specifications for reference. Check the fitted parts before ordering.
- Front tire
- 700 x 25c Kenda Kwest
- Drivetrain
- 9-speed
- Seatpost diameter
- 27.2 mm
- Bottom bracket / shell
- FSA square taper, 116mm spindle · 68mm
Equipment inspection checks 10 checks based on 5 archived component groups Open equipment checksClose equipment checks
Checks selected from the archived equipment. Confirm what is fitted today. This is not a complete safety inspection; use the full inspection guide before test riding.
Full used-bike inspection guide →
Frame and fork
Inspect the frame and fork →Archived: Frame: TIG-welded · Fork: Redline RCT · Carbon fiber/aluminum steerer, aero crown
Drivetrain
Check drivetrain wear →Archived: Group: Road Mix · Shifters: Shimano · Front derailleur: Shimano Sora · Rear derailleur: Shimano Sora · Crankset: FSA, 30/39/50 teeth · Bottom bracket: FSA square taper, 116mm spindle · Cassette: SRAM 950 · Rear cogs: 9-speed, 11 - 26 teeth
Brakes
Inspect the brakes →Archived: Brakes: Tektro 730 dual pivot brakes, Tektro levers
Wheels and tires
Check wheels and tires →Archived: Wheel size: 700c wheels · Rims: Alex AKX R1.0, 28-hole/32-hole · Hubs: Alex AKX R1.0 · Front tire: 700 x 25c Kenda Kwest
Controls and contact points
Archived: Headset: 1 1/8" FSA Integrated · Handlebar: Redline flat · Stem: Redline Alloy · Seatpost: Redline Alloy, 27.2mm diameter · Saddle: Velo Plush · Pedals: Alloy road w/ toe clips and strap
