Velopedia Bicycle Archive
2003 Redline Signature Mini
BMX bicycle from the Velopedia specification archive.
- Original MSRP
- $239.99
- Sizes
- Mini
- Colors
- Black/Red, Blue/White
- Archive ID
- 39413
Current market
Checking current listings…Frameset
| Frame Construction | TIG-welded |
|---|---|
| Frame Material | 4130 chromoly |
| Fork | Redline |
| Fork Material | Chromoly, double butted, unicrown crown |
| Rear Shock | N/A |
Drivetrain
| Component Group | N/A |
|---|---|
| Shifters | N/A |
| Front Derailleur | N/A |
| Rear Derailleur | N/A |
| Crankset | Redline Light Flight 155mm, 40 teeth |
| Bottom Bracket | Loose ball |
| Rear Cogs | 1-speed, 17 teeth |
| Chain | KMC Z30, 1/2 x 3/32" |
| Pedals | Redline aluminum |
Brakes
| Brakes | ProMax mini-V rear brakes, Promax alloy rear levers |
|---|
Cockpit & Contact Points
| Headset | 1" threadless steel threadless |
|---|---|
| Handlebar | Redline alloy rise |
| Handlebar Extensions | Not included |
| Stem | Redline Proline Mini |
| Saddle | Redline mini |
| Seatpost | Aluminum |
Wheels & Tires
| Hubs | Redline alloy |
|---|---|
| Rims | Alex DR-13, 28-hole/32-hole |
| Spokes | Stainless steel |
| Front Tire | 20 x 1 1/8" Tioga Comp III |
| Wheel Size | 20" wheels |
Specifications are presented as a reference. Components may vary by market, size, production run, or later manufacturer revisions.
