Velopedia Bicycle Archive
2003 Redline Proline Team
Original specifications: 20" wheels · legacy reference geometry.
Planning to sell? Draft your listing
At a glance
Archive #39407- Model year
- 2003
- Category
- BMX
- Original MSRP
- $359.99
- Sizes
- Pro XL
- Colors
- White
- Geometry
- Legacy reference
- In this record
- 22 specifications · archived image · original MSRP · geometry
Model history 2 other years
Browse other years
Compare side by side
Identification clues
2003 archived details
- Published colors
- White
- Frame
- 6061 T6 aluminum
- Original equipment
- N/A
Clues, not proof of model year. Colors vary and components may have been replaced.
Original build6061 T6 aluminum · 20" wheels
Frameset
| Frame Construction | TIG-welded |
|---|---|
| Frame Material | 6061 T6 aluminum |
| Fork | Redline |
| Fork Material | Chromoly, double butted, unicrown crown |
Drivetrain
| Crankset | Redline Flight 3-piece 180mm, 44 teeth |
|---|---|
| Bottom Bracket | Sealed |
| Rear Cogs | 1-speed, 16 teeth |
| Chain | KMC Z30, 1/2 x 3/32" |
| Pedals | Redline aluminum |
Brakes
| Brakes | ProMax linear-pull rear brakes, ProMax linear-pull rear levers |
|---|
Cockpit & Contact Points
| Headset | 1 1/8" threadless VP |
|---|---|
| Handlebar | Redline Pro chromoly |
| Handlebar Extensions | Not included |
| Stem | Redline Flight stem |
| Saddle | Redline |
| Seatpost | Aluminum micro-adjust |
Wheels & Tires
| Hubs | Front: Redline Flight, Rear: Redline Flight flip-flop |
|---|---|
| Rims | Alex Supra B, 36-hole |
| Spokes | Stainless steel |
| Front Tire | 20 x 2.125" Tioga Comp III |
| Rear Tire | 20 x 1.75" Tioga Comp III |
| Wheel Size | 20" wheels |
No specifications match. Try a component name or clear your search.
Geometry
Historical measurements. Frame size unknown.
Reference drawing
Select an available measurement to locate it on the frame.
All geometry measurementsLegacy reference · 5 measurements
| Measurement | Legacy reference |
|---|---|
| Top tube | 546.1 mm |
| Head-tube angle | 74° |
| Seat-tube angle | 70° |
| Chainstay / rear center | 406.4 mm |
| Wheelbase | 971.5 mm |
Frame size not recorded.
Gearing
Lower gears help on climbs. Higher gears suit higher speeds.
RPM = pedal turns per minute.
How it works
Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.
Speeds are estimates from tire size and pedal cadence. Actual speeds vary.
Try your current gearingChanged tires or gears? Calculate your setup.
Your changes apply to this calculation. The archived build stays unchanged.
Gearing results
| Measure | Original | Your setup |
|---|---|---|
| Lowest ratio | — | — |
| Highest ratio | — | — |
| Total range | — | — |
| Lowest-gear speed | — | — |
| Highest-gear speed | — | — |
Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.
Parts & serviceability
Find replacement parts
Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.
1/2 x 3/32"
ProMax linear-pull rear levers
36-hole
Based on the original build. Check fit and installed parts before ordering.
Parts and service referenceQuick reference before buying parts
Archived specifications for reference. Check the fitted parts before ordering.
- Front tire
- Front: 20 x 2.125" Tioga Comp III, Rear: 20 x 1.75" Tioga Comp III
- Drivetrain
- 1-speed
- Bottom bracket / shell
- Sealed
Equipment inspection checks 10 checks based on 5 archived component groups Open equipment checksClose equipment checks
Checks selected from the archived equipment. Confirm what is fitted today. This is not a complete safety inspection; use the full inspection guide before test riding.
Full used-bike inspection guide →
Frame and fork
Inspect the frame and fork →Archived: Frame: TIG-welded · Fork: Redline · Chromoly, double butted, unicrown crown
Drivetrain
Check drivetrain wear →Archived: Crankset: Redline Flight 3-piece 180mm, 44 teeth · Bottom bracket: Sealed · Rear cogs: 1-speed, 16 teeth · Chain: KMC Z30, 1/2 x 3/32"
Brakes
Inspect the brakes →Archived: Brakes: ProMax linear-pull rear brakes, ProMax linear-pull rear levers
Wheels and tires
Check wheels and tires →Archived: Wheel size: 20" wheels · Rims: Alex Supra B, 36-hole · Hubs: Front: Redline Flight, Rear: Redline Flight flip-flop · Front tire: Front: 20 x 2.125" Tioga Comp III, Rear: 20 x 1.75" Tioga Comp III
Controls and contact points
Archived: Headset: 1 1/8" threadless VP · Handlebar: Redline Pro chromoly · Stem: Redline Flight stem · Seatpost: Aluminum micro-adjust · Saddle: Redline · Pedals: Redline aluminum
Have you owned this model?Help preserve its real-world history by sharing your owner experience.
Share the details that would help another rider understand how this model fits, rides and holds up over time. Velopedia reviews every contribution before publication.
Already contributed? Send me a fresh private edit link
For privacy, Velopedia shows the same confirmation whether or not an experience exists.
No recent price sample is available for this bike. Check eBay for matching listings.
Find this bike on eBay
Search eBay US; check the model year, size and installed components. We may earn a commission from purchases.
Specifications are presented as a reference. Components may vary by market, size, production run, or later manufacturer revisions.
