2000 Redline Signature Junior

Original specifications: 20" wheels.

Share owner experience

Planning to sell? Draft your listing

No archive photo is available for this record.

At a glance

Archive #46756
Model year
2000
Category
BMX
Sizes
Junior
Colors
Arctic White, Chrome Plated
In this record
22 specifications
Model history 3 other years

Browse other years

Compare side by side

Identification clues

2000 archived details

Published colors
Arctic White, Chrome Plated
Frame
4130 chromoly
Original equipment
N/A

Clues, not proof of model year. Colors vary and components may have been replaced.

Sponsored affiliate link
Original build4130 chromoly · 20" wheels

Manufacturer catalog

Published sizes and colors

1 size · 2 colors

Manufacturer-published sizes and colors; availability and exact size/color pairings may vary by market or production run.

Published sizes

Junior

Published colors

Arctic WhiteChrome Plated

Frameset

Frame ConstructionTIG-welded
Frame Material4130 chromoly
ForkRedline
Fork MaterialChromoly, unicrown crown

Drivetrain

CranksetRedline forged alloy, 165mm, 40 teeth
Bottom BracketSealed
Rear Cogs1-speed, 17 teeth
ChainKMC, 1/2 x 3/32"
PedalsRedline mini cage alloy

Brakes

BrakesTektro 917A (Mini V-type brake) rear brakes, Tektro (316A mini) rear levers

Cockpit & Contact Points

Headset1" threadless Tioga
HandlebarRedline alloy mini
Handlebar ExtensionsNot included
StemRedline mini
SaddleRedline mini
SeatpostUni style

Wheels & Tires

HubsRedline Flight
RimsAlex VP-15F, 32-hole
SpokesStainless steel, 2.0mm straight gauge
Spoke NipplesBrass nipples
Front Tire20 x 1 3/8" Tioga Comp III
Wheel Size20" wheels

Gearing

Lower gears help on climbs. Higher gears suit higher speeds.

Published build40T · 17T · 1-speed
Ratio2.35:1

Speed unavailable: wheel or tire size is missing or unclear.

Add your rear tire size to calculate speed
How it works

Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.

Speeds are estimates from tire size and pedal cadence. Actual speeds vary.

Try other gearing

Try your current gearingChanged tires or gears? Calculate your setup.

Your changes apply to this calculation. The archived build stays unchanged.

Your gearing setup
Gears

Use up to three front tooth counts, separated by /. For one rear sprocket, enter the same count twice.

Rear tire

Apply the marking on your rear tire or edit its dimensions below. Older or fractional inch sizes need the ISO marking (e.g. 37-590).

For 32-622, width is 32 mm and rim diameter is 622 mm. Use the rear tire on mixed-wheel bikes. Leave both fields empty to compare ratios only.

Gear, dimension and cadence changes update results automatically.

Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.

Parts & serviceability

Find replacement parts

Original specifications

Affiliate links may earn Velopedia a commission.

Rims · Original
Alex VP-15F

32-hole

Based on the original build. Check fit and installed parts before ordering.

Parts and service referenceQuick reference before buying parts

Archived specifications for reference. Check the fitted parts before ordering.

Front tire
20 x 1 3/8" Tioga Comp III
Drivetrain
1-speed
Bottom bracket / shell
Sealed
Sponsored affiliate link
Equipment inspection checks 10 checks based on 5 archived component groups Open equipment checksClose equipment checks
0 of 10 checked Progress stays in this browser for this record.

Checks selected from the archived equipment. Confirm what is fitted today. This is not a complete safety inspection; use the full inspection guide before test riding.

Full used-bike inspection guide →

Archived: Frame: TIG-welded · Fork: Redline · Chromoly, unicrown crown

Archived: Crankset: Redline forged alloy, 165mm, 40 teeth · Bottom bracket: Sealed · Rear cogs: 1-speed, 17 teeth · Chain: KMC, 1/2 x 3/32"

Archived: Brakes: Tektro 917A (Mini V-type brake) rear brakes, Tektro (316A mini) rear levers

Archived: Wheel size: 20" wheels · Rims: Alex VP-15F, 32-hole · Hubs: Redline Flight · Front tire: 20 x 1 3/8" Tioga Comp III

Controls and contact points

Archived: Headset: 1" threadless Tioga · Handlebar: Redline alloy mini · Stem: Redline mini · Seatpost: Uni style · Saddle: Redline mini · Pedals: Redline mini cage alloy
