2003 Rans Velocity Squared XL
Recumbent bicycle from the Velopedia specification archive.
- Original MSRP
- $1,299.00
- Sizes
- Fits 40" to 50"
- Colors
- Red
- Weight
- 31
- Archive ID
- 30674
Image not yet recovered
Current market
Checking current listings…Frameset
| Frame Construction | TIG-welded |
|---|---|
| Frame Material | 4130 chromoly |
| Fork Material | 4130 chromoly, unicrown crown |
| Rear Shock | N/A |
Drivetrain
| Component Group | Recumbent Mix |
|---|---|
| Shifters | SRAM 7.0 |
| Front Derailleur | Shimano 105 Triple |
| Rear Derailleur | SRAM ESP 7.0 |
| Crankset | TruVativ Elita, 32/42/52 teeth |
| Bottom Bracket | TruVativ ISIS Drive |
| Rear Cogs | 9-speed, 11 - 32 teeth |
| Chain | KMC HG-50, 1/2 x 3/32" |
| Pedals | Wellgo LU-897 |
Brakes
| Brakes | SRAM 7.0 brakes, SRAM 7.0 levers |
|---|
Cockpit & Contact Points
| Headset | 1" threadless FSA TH-865 Semi Cartridge |
|---|---|
| Handlebar | RANS Top Loader |
| Handlebar Extensions | N/A |
| Seatpost | N/A |
Wheels & Tires
| Hubs | Shimano Deore |
|---|---|
| Rims | Alex DA-16, 36-hole |
| Spokes | Stainless steel, 14ga. (2.0mm) straight gauge |
| Spoke Nipples | Brass nipples |
| Front Tire | 20 x 1.75" Primo Comet |
| Wheel Size | 20" wheels |
Specifications are presented as a reference. Components may vary by market, size, production run, or later manufacturer revisions.
