2014 Raleigh Venture 4.0 Womens

Original specifications.

Share owner experience

At a glance

Archive #9257880

Model year: 2014
Original MSRP: $550.00
Sizes: 14" WSM, 16" WMD, 19" WLG
Colors: Green, Light Purple
In this record: 16 specifications · archived image · original MSRP

Model history 1 other year

Browse other years

Compare side by side

Identification clues

2014 archived details

Published colors: Green, Light Purple
Frame: 6061 Aluminum

Clues, not proof of model year. Colors vary and components may have been replaced.

Original build6061 Aluminum

Manufacturer catalog

Published sizes and colors

3 sizes · 2 colors

Manufacturer-published sizes and colors; availability and exact size/color pairings may vary by market or production run.

Published sizes

14" WSM16" WMD19" WLG

Published colors

GreenLight Purple

Frameset

Frame Material	6061 Aluminum
Fork	SR NEX 100mm w/Preload Adjust

Drivetrain

Shifters	Shimano EF-51
Front Derailleur	Shimano TX-51
Rear Derailleur	Shimano Altus
Crankset	Shimano FC-M171 48/38/28t
Bottom Bracket	Sealed Cartridge 68/122
Cassette	SRAM PG830 8spd (11-32t)
Chain	KMC 8sp

Brakes

Brakes	Promax Alloy V-Brake V-Brake

Cockpit & Contact Points

Headset	Threaded 1-1/8"
Handlebar	Steel Comfort Riser
Stem	Alloy Adjust Quill
Saddle	Selle Royal Lookin Comfort
Seatpost	Alloy

Wheels & Tires

Front Tire	Kenda K841A w/Kshield 26x1.95

Gearing

Lower gears help on climbs. Higher gears suit higher speeds.

Published build48/38/28T · 11–32T · 8-speed

Lowest0.88:1 Highest4.36:1 Total range499%

Speed unavailable: wheel or tire size is missing or unclear.

Add your rear tire size to calculate speed

How it works

Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.

Speeds are estimates from tire size and pedal cadence. Actual speeds vary.

Try other gearing

Try your current gearingChanged tires or gears? Calculate your setup.

Your changes apply to this calculation. The archived build stays unchanged.

Gears Drivetrain

Front teeth Smallest rear teeth Largest rear teeth

Use up to three front tooth counts, separated by /. For one rear sprocket, enter the same count twice.

Rear tire

Rear tire marking

Apply the marking on your rear tire or edit its dimensions below. Older or fractional inch sizes need the ISO marking (e.g. 37-590).

Rim diameter (BSD, mm) Tire width (mm)

For 32-622, width is 32 mm and rim diameter is 622 mm. Use the rear tire on mixed-wheel bikes. Leave both fields empty to compare ratios only.

Cadence (RPM) Speed units

Gear, dimension and cadence changes update results automatically.

Gearing comparison
Measure	Original	Your setup
Lowest ratio	—	—
Highest ratio	—	—
Total range	—	—
Lowest-gear speed	—	—
Highest-gear speed	—	—

Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.

Parts & serviceability

Find replacement parts

Original specifications

Chain · Original

KMC 8sp Replacement search: 8-speed bicycle chain Before ordering: Check chain width and length.

Search Amazon Search eBay

Cassette · Original

SRAM PG830 8spd (11-32t)

Search Amazon Search eBay

Front tire · Original

Kenda K841A w/Kshield 26x1.95

Search Amazon Search eBay

More parts (4)Fewer parts

Brake pads · Original

Promax Alloy V-Brake V-Brake

Search Amazon Search eBay

Saddle · Original

Selle Royal Lookin Comfort

Search Amazon Search eBay

Crankset · Original

Shimano FC-M171 48/38/28t

Search Amazon Search eBay

Rear derailleur · Original

Shimano Altus

Search Amazon Search eBay

Based on the original build. Check fit and installed parts before ordering. Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.

Parts and service referenceQuick reference before buying parts

Archived specifications for reference. Check the fitted parts before ordering.

Front tire: Kenda K841A w/Kshield 26x1.95
Drivetrain: 8-speed
Bottom bracket / shell: Sealed Cartridge 68/122

Equipment inspection checks 8 checks based on 4 archived component groups Open equipment checksClose equipment checks

Checks selected from the archived equipment. Confirm what is fitted today. This is not a complete safety inspection; use the full inspection guide before test riding.

Full used-bike inspection guide →

Frame and fork

Inspect the frame and fork →

Archived: Frame: 6061 Aluminum · Fork: SR NEX 100mm w/Preload Adjust

Look for dents or shape changes and inspect the edges of welds around the head tube, bottom bracket, seat cluster and suspension mounts for hairline cracks.
Inspect the fork crown, blades, dropouts and visible steerer area. Check that it is straight, securely installed and free of cracks or impact damage.

Drivetrain

Check drivetrain wear →

Archived: Shifters: Shimano EF-51 · Front derailleur: Shimano TX-51 · Rear derailleur: Shimano Altus · Crankset: Shimano FC-M171 48/38/28t · Bottom bracket: Sealed Cartridge 68/122 · Cassette: SRAM PG830 8spd (11-32t) · Chain: KMC 8sp

Shift through every available gear under light load. Hesitation, skipping or inconsistent indexing can reflect wear, damage, poor adjustment or mismatched replacement parts.
Measure chain wear with a compatible gauge and inspect chainring, cassette or freewheel teeth. A new chain does not rule out wear in the remaining drivetrain.
Turn the cranks slowly, feel for rough bearings and check for side-to-side play. Inspect crank arms, chainring bolts and pedal threads for looseness or damage.

Brakes

Inspect the brakes →

Archived: Brakes: Promax Alloy V-Brake V-Brake

Inspect pads, cables and housings, then examine both rim braking surfaces for concavity, cracking or heavy wear. Confirm each caliper returns and centers correctly.

Controls and contact points

Archived: Headset: Threaded 1-1/8" · Handlebar: Steel Comfort Riser · Stem: Alloy Adjust Quill · Seatpost: Alloy · Saddle: Selle Royal Lookin Comfort

Apply the front brake and rock the bike to check for headset play or notchiness. Inspect the stem, handlebar and clamp zones, then confirm every fastener and control is secure.
Check that the seatpost moves for adjustment and that the saddle, post and clamp hold securely without cracks, severe corrosion or damaged hardware.
