2013 Raleigh XXIX

Original specifications.

Share owner experience

At a glance

Archive #9220608

Model year: 2013
Category: Mountain
Original MSRP: $1,650.00
Sizes: S, M, L, XL
Colors: White
In this record: 14 specifications · archived image · original MSRP

Model history 7 other years

Browse other years

Compare side by side

Identification clues

2013 archived details

Published colors: White
Frame: Chromoly

Clues, not proof of model year. Colors vary and components may have been replaced.

Original buildChromoly

Manufacturer catalog

Published sizes and colors

4 sizes · 1 color

Manufacturer-published sizes and colors; availability and exact size/color pairings may vary by market or production run.

Published sizes

SMLXL

Published colors

White

Frameset

Frame Material	Chromoly
Fork	Fox 32 Float CTD 100mm

Drivetrain

Crankset	Alloy 46t
Bottom Bracket	Press Fit 30
Cassette	28t Belt
Rear Cogs	1x1 Speeds
Chain	Gates Belt

Brakes

Brakes	Shimano M505

Cockpit & Contact Points

Headset	1 1/8" Threadless
Handlebar	Avenir 200 Series Riser
Stem	Avenir 200 Series
Saddle	Avenir XM3
Seatpost	Avenir 200 Series

Wheels & Tires

Front Tire	Geax AKA 29x2.2

Gearing

Lower gears help on climbs. Higher gears suit higher speeds.

All published sizes46T front / 28T rear · Belt drive

Ratio1.64:1

Speed unavailable: wheel or tire size is missing or unclear.

Add your rear tire size to calculate speed

How it works

Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.

Speeds are estimates from tire size and pedal cadence. Actual speeds vary.

Try other gearing

Try your current gearingChanged tires or gears? Calculate your setup.

Your changes apply to this calculation. The archived build stays unchanged.

Gears Drivetrain

Front teeth Smallest rear teeth Largest rear teeth

Use up to three front tooth counts, separated by /. For one rear sprocket, enter the same count twice.

Rear tire

Rear tire marking

Apply the marking on your rear tire or edit its dimensions below. Older or fractional inch sizes need the ISO marking (e.g. 37-590).

Rim diameter (BSD, mm) Tire width (mm)

For 32-622, width is 32 mm and rim diameter is 622 mm. Use the rear tire on mixed-wheel bikes. Leave both fields empty to compare ratios only.

Cadence (RPM) Speed units

Gear, dimension and cadence changes update results automatically.

Gearing comparison
Measure	Original	Your setup
Lowest ratio	—	—
Highest ratio	—	—
Total range	—	—
Lowest-gear speed	—	—
Highest-gear speed	—	—

Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.

Parts & serviceability

Find replacement parts

Original specifications

Front tire · Original

Geax AKA 29x2.2 Replacement search: 29x2.2 bicycle tire Before ordering: Check rim type and tire clearance.

Search Amazon Search eBay

Based on the original build. Check fit and installed parts before ordering. Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.

Parts and service referenceQuick reference before buying parts

Archived specifications for reference. Check the fitted parts before ordering.

Front tire: Geax AKA 29x2.2
Bottom bracket / shell: Press Fit 30

Equipment inspection checks 9 checks based on 5 archived component groups Open equipment checksClose equipment checks

Checks selected from the archived equipment. Confirm what is fitted today. This is not a complete safety inspection; use the full inspection guide before test riding.

Full used-bike inspection guide →

Frame and fork

Inspect the frame and fork →

Archived: Frame: Chromoly · Fork: Fox 32 Float CTD 100mm

Check paint damage, vent holes and accessible internal surfaces for corrosion. Look for dents, bent tubes and cracking around welded or brazed joints.

Suspension

Evaluate the suspension →

Archived: Fork: Fox 32 Float CTD 100mm

Inspect the fork stanchions for scratches or coating wear, look for oil or dirt rings at the seals, and cycle the fork through its travel while checking for binding or bushing play.
Ask for dated fork-service records. A clean exterior does not establish the condition of internal seals, oil or bushings.

Drivetrain

Check drivetrain wear →

Archived: Crankset: Alloy 46t · Bottom bracket: Press Fit 30 · Cassette: 28t Belt · Rear cogs: 1x1 Speeds · Chain: Gates Belt

Shift through every available gear under light load. Hesitation, skipping or inconsistent indexing can reflect wear, damage, poor adjustment or mismatched replacement parts.
Inspect the belt teeth and edges for damage, verify alignment and tension, and check that any frame split or belt-tensioning hardware is secure.
Turn the cranks slowly, feel for rough bearings and check for side-to-side play. Inspect crank arms, chainring bolts and pedal threads for looseness or damage.

Brakes

Inspect the brakes →

Archived: Brakes: Shimano M505

Inspect pads and braking surfaces, check the complete cable or hose path, and confirm both controls feel consistent and return cleanly.

Controls and contact points

Archived: Headset: 1 1/8" Threadless · Handlebar: Avenir 200 Series Riser · Stem: Avenir 200 Series · Seatpost: Avenir 200 Series · Saddle: Avenir XM3

Apply the front brake and rock the bike to check for headset play or notchiness. Inspect the stem, handlebar and clamp zones, then confirm every fastener and control is secure.
Check that the seatpost moves for adjustment and that the saddle, post and clamp hold securely without cracks, severe corrosion or damaged hardware.
