2010 Raleigh Route 4.0

Original specifications: Shimano Acera · 8-speed rear derailleur · 700c wheels.

Share owner experience

Planning to sell? Draft your listing

At a glance

Archive #21012
Model year
2010
Category
Hybrid
Sizes
15", 17", 19", 21", 23"
Colors
Dark Silver, Dark Ocean Blue
In this record
26 specifications · archived image
Model history 5 other years

Browse other years

Compare side by side

Identification clues

2010 archived details

Published colors
Dark Silver, Dark Ocean Blue
Frame
Atomic 13 Aluminum
Original equipment
Hybrid Mix

Clues, not proof of model year. Colors vary and components may have been replaced.

Campaign
Original buildAtomic 13 Aluminum · Hybrid Mix · 700c wheels

Historical catalog variants

Archived sizes and colors

10 item records

Item-level catalog entries recovered from Velopedia’s original bicycle archive. They document how this model was listed historically; they do not identify the frame size associated with legacy reference geometry or indicate current availability.

Published sizes

15"17"19"21"23"

Published colors

Dark SilverDark Ocean Blue
View 10 archived size/color combinations
SizeColor
15"Dark Silver
17"Dark Silver
19"Dark Silver
21"Dark Silver
23"Dark Silver
15"Dark Ocean Blue
17"Dark Ocean Blue
19"Dark Ocean Blue
21"Dark Ocean Blue
23"Dark Ocean Blue

Historical catalog evidence. Exact specifications and naming may vary by market, production run or manufacturer revision.

Frameset

Frame ConstructionTIG-welded
Frame MaterialAtomic 13 Aluminum
ForkSR Suntour NEX-4110, 63mm travel
Fork MaterialSingle

Drivetrain

Component GroupHybrid Mix
ShiftersShimano EF-50
Front DerailleurShimano C50
Rear DerailleurShimano Acera
CranksetShimano FC-191, 28/38/48 teeth
Bottom BracketSealed cartridge
CassetteSRAM PG-830
Rear Cogs8-speed, 11 - 32 teeth
ChainKMC HG40
PedalsAvenir Comfort Platform

Brakes

BrakesTektro V-brake brakes, Shimano EF-50 levers

Cockpit & Contact Points

Headset1 1/8" threaded
HandlebarSteel 50mm Rise x 630mm
Handlebar ExtensionsNot included
StemAlloy Adjustable Quill
SaddleAvenir Deluxe Comfort
SeatpostAlloy Micro Adjust Bootless Suspension, 27.2mm diameter

Wheels & Tires

HubsFront: Joytech Alloy QR, Rear: Shimano RM30
RimsWeinmann XC-260, 36-hole
SpokesStainless, 14ga. (2.0mm)
Front Tire700 x 40c Kenda K-192 w/K-shield
Wheel Size700c wheels

Gearing

Lower gears help on climbs. Higher gears suit higher speeds.

RPM

RPM = pedal turns per minute.

All published sizes48/38/28T · 11–32T · 8-speed
Lowest0.88:1 Highest4.36:1 Total range499%
Estimated speed At 90 RPM Lowest gear6.5 mph Highest gear32.3 mph

Uses front tire 700C×40; rear size isn’t listed.

How it works

Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.

Speeds are estimates from tire size and pedal cadence. Actual speeds vary.

Try other gearing

Try your current gearingChanged tires or gears? Calculate your setup.

Your changes apply to this calculation. The archived build stays unchanged.

Your gearing setup
Gears

Use up to three front tooth counts, separated by /. For one rear sprocket, enter the same count twice.

Rear tire

Apply the marking on your rear tire or edit its dimensions below. Older or fractional inch sizes need the ISO marking (e.g. 37-590).

For 32-622, width is 32 mm and rim diameter is 622 mm. Use the rear tire on mixed-wheel bikes. Leave both fields empty to compare ratios only.

Gear, dimension and cadence changes update results automatically.

Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.

Parts & serviceability

Find replacement parts

Original specifications
Chain · Original
KMC HG40
Search Amazon Search eBay
Retailer offers
Front tire · Original
700 x 40c Kenda K-192 w/K-shield
Search Amazon Search eBay
Retailer offers

WTB Vulpine Tire - Tubeless Black, 700x40mm, TCS, Light/Fast Rolling, 60tpi, Dual DNA

700x40c, TCS, Light/Fast Rolling, 60tpi, Dual DNA

Replacement option

Other replacement options (1)

Challenge Getaway Race Vulcanized Tubeless Tire Black, 700x40

700x40c

Replacement option

Seatpost · Original
Alloy Micro Adjust Bootless Suspension

27.2mm diameter

Search Amazon Search eBay
Retailer offers
More parts (4)Fewer parts
Cassette · Original
SRAM PG-830
Search Amazon Search eBay
Brake pads · Original
Tektro V-brake brakes

Shimano EF-50 levers

Search Amazon Search eBay
Crankset · Original
Shimano FC-191

28/38/48 teeth

Search eBay
Rear derailleur · Original
Shimano Acera
Search eBay

Based on the original build. Check fit and installed parts before ordering. Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.

Parts and service referenceQuick reference before buying parts

Archived specifications for reference. Check the fitted parts before ordering.

Front tire
700 x 40c Kenda K-192 w/K-shield
Drivetrain
8-speed
Seatpost diameter
27.2 mm
Bottom bracket / shell
Sealed cartridge
Equipment inspection checks 11 checks based on 6 archived component groups Open equipment checksClose equipment checks
0 of 11 checked Progress stays in this browser for this record.

Checks selected from the archived equipment. Confirm what is fitted today. This is not a complete safety inspection; use the full inspection guide before test riding.

Full used-bike inspection guide →

Frame and fork

Inspect the frame and fork →

Archived: Frame: TIG-welded · Fork: SR Suntour NEX-4110, 63mm travel · Single

Suspension

Evaluate the suspension →

Archived: Fork: SR Suntour NEX-4110, 63mm travel

Drivetrain

Check drivetrain wear →

Archived: Group: Hybrid Mix · Shifters: Shimano EF-50 · Front derailleur: Shimano C50 · Rear derailleur: Shimano Acera · Crankset: Shimano FC-191, 28/38/48 teeth · Bottom bracket: Sealed cartridge · Cassette: SRAM PG-830 · Rear cogs: 8-speed, 11 - 32 teeth · Chain: KMC HG40

Brakes

Inspect the brakes →

Archived: Brakes: Tektro V-brake brakes, Shimano EF-50 levers

Wheels and tires

Check wheels and tires →

Archived: Wheel size: 700c wheels · Rims: Weinmann XC-260, 36-hole · Hubs: Front: Joytech Alloy QR, Rear: Shimano RM30 · Front tire: 700 x 40c Kenda K-192 w/K-shield

Controls and contact points

Archived: Headset: 1 1/8" threaded · Handlebar: Steel 50mm Rise x 630mm · Stem: Alloy Adjustable Quill · Seatpost: Alloy Micro Adjust Bootless Suspension, 27.2mm diameter · Saddle: Avenir Deluxe Comfort · Pedals: Avenir Comfort Platform
