Lowest0.73:1
Highest3.82:1
Total range521%
Estimated speed At 90 RPM
Lowest gear
Highest gear
Uses front tire 26×1.95; rear size isn’t listed.
Velopedia Bicycle Archive
2002 Raleigh M50
Original specifications: Shimano Acera · 8-speed · mechanical rear derailleur · 26" wheels · legacy reference geometry.
Planning to sell? Draft your listing
At a glance
Archive #91271- Model year
- 2002
- Category
- Mountain
- Original MSRP
- $329.99
- Sizes
- 14", 16", 18", 20", 22", 24"
- Colors
- Blue, Orange
- Geometry
- Legacy reference
- In this record
- 27 specifications · archived image · original MSRP · geometry
Model history 8 other years
Browse other years
Compare side by side
Identification clues
2002 archived details
- Published colors
- Blue, Orange
- Frame
- 6061 T6 aluminum
- Original equipment
- Mountain Mix
Clues, not proof of model year. Colors vary and components may have been replaced.
Original build6061 T6 aluminum · Mountain Mix · 26" wheels
Frameset
| Frame Construction | TIG-welded |
|---|---|
| Frame Material | 6061 T6 aluminum |
| Fork | Sakae XCR-E, 3.0" travel |
| Fork Material | Aluminum, single triple-clamp crown |
Drivetrain
| Component Group | Mountain Mix |
|---|---|
| Shifters | Shimano Acera EZ Fire Plus |
| Front Derailleur | Shimano Acera, bottom-pull/clamp-on 31.8mm |
| Rear Derailleur | Shimano Acera |
| Crankset | Shimano Alivio FC-MC19-L, 22/32/42 teeth |
| Bottom Bracket | Chin Haur CH-52, 111mm spindle |
| BB Shell Width | 68mm English |
| Rear Cogs | 8-speed, 11 - 30 teeth |
| Chain | Shimano CN-IG31, 1/2 x 3/32" |
| Pedals | MTB nylon |
Brakes
| Brakes | Tektro 832A linear pull brakes, Shimano Acera levers |
|---|
Cockpit & Contact Points
| Headset | 1 1/8" Tien Hsin TH-888 |
|---|---|
| Handlebar | Aluminum |
| Handlebar Extensions | Not included |
| Stem | Aluminum |
| Saddle | Velo |
| Seatpost | Aluminum, 27.2mm diameter |
Wheels & Tires
| Hubs | Joy Tech aluminum, Q/R |
|---|---|
| Rims | Weinmann CN-520, 36-hole |
| Spokes | Sha-Dar stainless steel, 14ga. (2.0mm) straight gauge |
| Spoke Nipples | Brass nipples |
| Front Tire | 26 x 1.95" Kenda K-850 |
| Wheel Size | 26" wheels |
No specifications match. Try a component name or clear your search.
Geometry
Historical measurements. Frame size unknown.
Reference drawing
Size
Measurement
Measurement
—
Select an available measurement to locate it on the frame.
All geometry measurementsLegacy reference · 6 measurements
| Measurement | Legacy reference |
|---|---|
| Top tube | 584.2 mm |
| Head-tube angle | 71° |
| Seat-tube angle | 73° |
| Chainstay / rear center | 424.2 mm |
| Wheelbase | 1056.6 mm |
| Fork offset / rake | 40.6 mm |
Frame size not recorded.
Gearing
Lower gears help on climbs. Higher gears suit higher speeds.
RPM
RPM = pedal turns per minute.
How it works
Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.
Speeds are estimates from tire size and pedal cadence. Actual speeds vary.
Try your current gearingChanged tires or gears? Calculate your setup.
Your changes apply to this calculation. The archived build stays unchanged.
Gearing results
| Measure | Original | Your setup |
|---|---|---|
| Lowest ratio | — | — |
| Highest ratio | — | — |
| Total range | — | — |
| Lowest-gear speed | — | — |
| Highest-gear speed | — | — |
Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.
Parts & serviceability
Find replacement parts
Shimano CN-IG31
1/2 x 3/32"
Retailer offers
SRAM PC-830 Chain One Color, 8 Speed
Replacement option
Shimano CN-IG31 on eBaySponsored links
Aluminum
27.2mm diameter
Retailer offers
Race Face Ride XC Seatpost Black, 27.2x375mm
Replacement option
26 x 1.95" Kenda K-850
Replacement search: 26x1.95 bicycle tire Before ordering: Check rim type and tire clearance.
More parts (4)Fewer parts
Tektro 832A linear pull brakes
Shimano Acera levers
Shimano Alivio FC-MC19-L
22/32/42 teeth
Shimano Acera
Shimano Acera EZ Fire Plus
Based on the original build. Check fit and installed parts before ordering. Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.
Parts and service referenceQuick reference before buying parts
Archived specifications for reference. Check the fitted parts before ordering.
- Front tire
- 26 x 1.95" Kenda K-850
- Drivetrain
- 8-speed
- Seatpost diameter
- 27.2 mm
- Bottom bracket / shell
- Chin Haur CH-52, 111mm spindle · 68mm English
Equipment inspection checks 11 checks based on 6 archived component groups Open equipment checksClose equipment checks
Checks selected from the archived equipment. Confirm what is fitted today. This is not a complete safety inspection; use the full inspection guide before test riding.
Full used-bike inspection guide →
Frame and fork
Inspect the frame and fork →Archived: Frame: TIG-welded · Fork: Sakae XCR-E, 3.0" travel · Aluminum, single triple-clamp crown
Suspension
Evaluate the suspension →Archived: Fork: Sakae XCR-E, 3.0" travel
Drivetrain
Check drivetrain wear →Archived: Group: Mountain Mix · Shifters: Shimano Acera EZ Fire Plus · Front derailleur: Shimano Acera, bottom-pull/clamp-on 31.8mm · Rear derailleur: Shimano Acera · Crankset: Shimano Alivio FC-MC19-L, 22/32/42 teeth · Bottom bracket: Chin Haur CH-52, 111mm spindle · Rear cogs: 8-speed, 11 - 30 teeth · Chain: Shimano CN-IG31, 1/2 x 3/32"
Brakes
Inspect the brakes →Archived: Brakes: Tektro 832A linear pull brakes, Shimano Acera levers
Wheels and tires
Check wheels and tires →Archived: Wheel size: 26" wheels · Rims: Weinmann CN-520, 36-hole · Hubs: Joy Tech aluminum, Q/R · Front tire: 26 x 1.95" Kenda K-850
Controls and contact points
Archived: Headset: 1 1/8" Tien Hsin TH-888 · Handlebar: Aluminum · Stem: Aluminum · Seatpost: Aluminum, 27.2mm diameter · Saddle: Velo · Pedals: MTB nylon
Have you owned this model?Help preserve its real-world history by sharing your owner experience.
Share the details that would help another rider understand how this model fits, rides and holds up over time. Velopedia reviews every contribution before publication.
Already contributed? Send me a fresh private edit link
For privacy, Velopedia shows the same confirmation whether or not an experience exists.
No recent price sample is available for this bike. Check eBay for matching listings.
Find this bike on eBay
Search eBay US; check the model year, size and installed components. We may earn a commission from purchases.
Specifications are presented as a reference. Components may vary by market, size, production run, or later manufacturer revisions.
