Lowest1.00:1
Highest3.29:1
Total range329%
Estimated speed At 90 RPM
Lowest gear
Highest gear
Uses front tire 24×1.95; rear size isn’t listed.
Velopedia Bicycle Archive
1998 Raleigh Mountain Scout
Original specifications: Shimano Tourney drivetrain · 24" wheels · 29 lb published weight.
Planning to sell? Draft your listing
At a glance
Archive #79260- Model year
- 1998
- Category
- Kids
- Original MSRP
- $219.99
- Sizes
- Boys 12", girls 11"
- Colors
- 911 Red, Vivid Teal
- Weight
- 29 lb
- Geometry
- Legacy reference
- In this record
- 27 specifications · archived image · original MSRP · geometry
Model history 5 other years
Browse other years
Compare side by side
Identification clues
1998 archived details
- Published colors
- 911 Red, Vivid Teal
- Frame
- Hi-tensile steel
- Original equipment
- Shimano Tourney
Clues, not proof of model year. Colors vary and components may have been replaced.
Original buildHi-tensile steel · Shimano Tourney · 24" wheels
Frameset
| Frame Construction | TIG-welded |
|---|---|
| Frame Material | Hi-tensile steel |
| Fork | Raleigh Jr. ATB |
| Fork Material | Hi-tensile steel, unicrown crown |
Drivetrain
| Component Group | Shimano Tourney |
|---|---|
| Shifters | Grip Shift MRX-170 |
| Front Derailleur | Shimano Tourney TY-32, bottom-pull/clamp-on 28.6mm |
| Rear Derailleur | Shimano Tourney TY-22 |
| Crankset | Prowheel S-304P w/chainguard, 28/38/46 teeth |
| Bottom Bracket | Victor VPB-33, 126.5mm spindle |
| BB Shell Width | 68mm English |
| Rear Cogs | 6-speed, 14 - 28 teeth |
| Chain | KMC Z-51, 1/2 x 3/32" |
| Pedals | Resin |
Brakes
| Brakes | Aluminum brakes, resin/aluminum levers |
|---|
Cockpit & Contact Points
| Headset | 1" Victor VP-H67 |
|---|---|
| Handlebar | Steel |
| Handlebar Extensions | Not included |
| Stem | Steel |
| Saddle | Velo VL-195 |
| Seatpost | Pillar, steel, 25.6mm diameter |
Wheels & Tires
| Hubs | Joy Tech Big steel, nutted |
|---|---|
| Rims | Weinmann 519, 36-hole |
| Spokes | Chung Nan UCP, 2.0mm straight gauge |
| Spoke Nipples | Brass nipples |
| Front Tire | 24 x 1.95" multi-terrain |
| Wheel Size | 24" wheels |
No specifications match. Try a component name or clear your search.
Geometry
Historical measurements. Frame size unknown.
Reference drawing
Size
Measurement
Measurement
—
Select an available measurement to locate it on the frame.
All geometry measurementsLegacy reference · 6 measurements
| Measurement | Legacy reference |
|---|---|
| Top tube | 473.7 mm |
| Head-tube angle | 69° |
| Seat-tube angle | 71° |
| Chainstay / rear center | 410.2 mm |
| Wheelbase | 971.5 mm |
| Fork offset / rake | 50.8 mm |
Frame size not recorded.
Gearing
Lower gears help on climbs. Higher gears suit higher speeds.
RPM
RPM = pedal turns per minute.
How it works
Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.
Speeds are estimates from tire size and pedal cadence. Actual speeds vary.
Try your current gearingChanged tires or gears? Calculate your setup.
Your changes apply to this calculation. The archived build stays unchanged.
Gearing results
| Measure | Original | Your setup |
|---|---|---|
| Lowest ratio | — | — |
| Highest ratio | — | — |
| Total range | — | — |
| Lowest-gear speed | — | — |
| Highest-gear speed | — | — |
Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.
Parts & serviceability
Find replacement parts
24 x 1.95" multi-terrain
Replacement search: 24x1.95 bicycle tire Before ordering: Check rim type and tire clearance.
Shimano Tourney TY-22
More parts (1)Fewer parts
Pillar
steel, 25.6mm diameter
Based on the original build. Check fit and installed parts before ordering. Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.
Parts and service referenceQuick reference before buying parts
Archived specifications for reference. Check the fitted parts before ordering.
- Front tire
- 24 x 1.95" multi-terrain
- Drivetrain
- 6-speed
- Seatpost diameter
- 25.6 mm
- Bottom bracket / shell
- Victor VPB-33, 126.5mm spindle · 68mm English
Equipment inspection checks 10 checks based on 5 archived component groups Open equipment checksClose equipment checks
Checks selected from the archived equipment. Confirm what is fitted today. This is not a complete safety inspection; use the full inspection guide before test riding.
Full used-bike inspection guide →
Frame and fork
Inspect the frame and fork →Archived: Frame: TIG-welded · Fork: Raleigh Jr. ATB · Hi-tensile steel, unicrown crown
Drivetrain
Check drivetrain wear →Archived: Group: Shimano Tourney · Shifters: Grip Shift MRX-170 · Front derailleur: Shimano Tourney TY-32, bottom-pull/clamp-on 28.6mm · Rear derailleur: Shimano Tourney TY-22 · Crankset: Prowheel S-304P w/chainguard, 28/38/46 teeth · Bottom bracket: Victor VPB-33, 126.5mm spindle · Rear cogs: 6-speed, 14 - 28 teeth · Chain: KMC Z-51, 1/2 x 3/32"
Brakes
Inspect the brakes →Archived: Brakes: Aluminum brakes, resin/aluminum levers
Wheels and tires
Check wheels and tires →Archived: Wheel size: 24" wheels · Rims: Weinmann 519, 36-hole · Hubs: Joy Tech Big steel, nutted · Front tire: 24 x 1.95" multi-terrain
Controls and contact points
Archived: Headset: 1" Victor VP-H67 · Handlebar: Steel · Stem: Steel · Seatpost: Pillar, steel, 25.6mm diameter · Saddle: Velo VL-195 · Pedals: Resin
