Velopedia Bicycle Archive

1997 Raleigh Rowdy

Original specifications: Shimano Tourney TY-22 drivetrain · 20" wheels.

Share owner experience

No archive photo is available for this record.

At a glance

Archive #62686

Model year: 1997
Category: Kids
Original MSRP: $179.99
Sizes: Boys
Colors: Black
In this record: 25 specifications · original MSRP

Model history 13 other years

Browse other years

Compare side by side

Identification clues

1997 archived details

Published colors: Black
Frame: Hi-tensile steel
Original equipment: Shimano Tourney TY-22

Clues, not proof of model year. Colors vary and components may have been replaced.

Original buildHi-tensile steel · Shimano Tourney TY-22 · 20" wheels

Manufacturer catalog

Published sizes and colors

1 size · 1 color

Manufacturer-published sizes and colors; availability and exact size/color pairings may vary by market or production run.

Published sizes

Boys

Published colors

Black

Frameset

Frame Construction	TIG-welded
Frame Material	Hi-tensile steel
Fork	Raleigh
Fork Material	Hi-tensile steel, unicrown crown

Drivetrain

Component Group	Shimano Tourney TY-22
Shifters	Grip Shift MRX-170
Rear Derailleur	Shimano Tourney TY-22
Crankset	1-piece 5 1/2", 44 teeth
Bottom Bracket	One piece
BB Shell Width	American 24tpi
Rear Cogs	6-speed, 14 - 28 teeth
Chain	KMC UG-50, 1/2 x 3/32"
Pedals	Resin

Brakes

Brakes	Aluminum cantilever brakes, aluminum levers

Cockpit & Contact Points

Headset	1" steel
Handlebar	Steel
Stem	Steel
Saddle	Raleigh padded
Seatpost	Steel, 25.6 mm diameter

Wheels & Tires

Hubs	Steel, nutted
Rims	Araya VP-20, 36-hole
Spokes	Steel, 2.0mm straight gauge
Spoke Nipples	Brass nipples
Front Tire	20 x 2.00" multi-terrain
Wheel Size	20" wheels

Gearing

Lower gears help on climbs. Higher gears suit higher speeds.

Pedal cadence

RPM

Speed units

RPM = pedal turns per minute.

Published build44T · 14–28T · 6-speed

Lowest1.57:1 Highest3.14:1 Total range200%

Estimated speed At 90 RPM Lowest gear8.4 mph Highest gear16.8 mph

Uses front tire 20×2; rear size isn’t listed.

How it works

Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.

Speeds are estimates from tire size and pedal cadence. Actual speeds vary.

Try other gearing

Try your current gearingChanged tires or gears? Calculate your setup.

Your changes apply to this calculation. The archived build stays unchanged.

Gears Drivetrain

Front teeth Smallest rear teeth Largest rear teeth

Use up to three front tooth counts, separated by /. For one rear sprocket, enter the same count twice.

Rear tire

Rear tire marking

Apply the marking on your rear tire or edit its dimensions below. Older or fractional inch sizes need the ISO marking (e.g. 37-590).

Rim diameter (BSD, mm) Tire width (mm)

For 32-622, width is 32 mm and rim diameter is 622 mm. Use the rear tire on mixed-wheel bikes. Leave both fields empty to compare ratios only.

Cadence (RPM) Speed units

Gear, dimension and cadence changes update results automatically.

Gearing comparison
Measure	Original	Your setup
Lowest ratio	—	—
Highest ratio	—	—
Total range	—	—
Lowest-gear speed	—	—
Highest-gear speed	—	—

Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.

Parts & serviceability

Find replacement parts

Original specifications

Front tire · Original

20 x 2.00" multi-terrain Replacement search: 20x2 bicycle tire Before ordering: Check rim type and tire clearance.

Search Amazon Search eBay

Rear derailleur · Original

Shimano Tourney TY-22

Search eBay

Seatpost · Original

Steel

25.6 mm diameter

Search Amazon Search eBay

Based on the original build. Check fit and installed parts before ordering. Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.

Parts and service referenceQuick reference before buying parts

Archived specifications for reference. Check the fitted parts before ordering.

Front tire: 20 x 2.00" multi-terrain
Drivetrain: 6-speed
Seatpost diameter: 25.6 mm
Bottom bracket / shell: One piece · American 24tpi
