Velopedia Bicycle Archive

1995 Raleigh M-50

Original specifications: Shimano Alivio drivetrain · 26" wheels · legacy reference geometry.

Share owner experience

No archive photo is available for this record.

At a glance

Archive #32604

Model year: 1995
Category: Mountain
Original MSRP: $339.99
Sizes: 14.5", 16.5", 18", 20", 22", womens 16", womens 19"
Colors: Blackend blue, Candy Magenta
Geometry: Legacy reference
In this record: 24 specifications · original MSRP · geometry

Model history 1 other year

Browse other years

Compare side by side

Identification clues

1995 archived details

Published colors: Blackend blue, Candy Magenta
Frame: Chromoly, oversize, main triangle
Original equipment: Shimano Alivio

Clues, not proof of model year. Colors vary and components may have been replaced.

Original buildChromoly, oversize, main triangle · Shimano Alivio · 26" wheels

Manufacturer catalog

Published sizes and colors

7 sizes · 2 colors

Manufacturer-published sizes and colors; availability and exact size/color pairings may vary by market or production run.

Published sizes

14.5"16.5"18"20"22"womens 16"womens 19"

Published colors

Blackend blueCandy Magenta

Frameset

Frame Construction	TIG-welded steel
Frame Material	Chromoly, oversize, main triangle
Fork Material	Hi-tensile steel / chromoly, unicrown crown

Drivetrain

Component Group	Shimano Alivio
Shifters	Shimano AceraX RapidFire TX
Front Derailleur	Shimano AceraX, top-pull/clamp-on 28.6 mm
Rear Derailleur	Shimano Alivio GS
Crankset	Shimano Alivio HyperDrive-C, 24/34/42 teeth
Rear Cogs	7-speed, 11 - 28 teeth
Chain	Shimano CN-UG50, 1/2 x 3/32"
Pedals	Wellgo Hi-Impact resin, toe-clip attachable

Brakes

Brakes	Shimano Altus C90 brakes, Shimano AceraX levers

Cockpit & Contact Points

Headset	1" Tien Hsin TH steel
Handlebar	Steel
Handlebar Extensions	Not included
Stem	Steel
Saddle	Vetta SE
Seatpost	Lee Chi alloy SP-204, 26.0 mm diameter

Wheels & Tires

Hubs	Shimano AceraX
Rims	Rodi Vuelta Strong Ti-Ano, 36-hole
Spokes	Stainless steel, 1.8 mm straight gauge
Spoke Nipples	Brass nipples
Front Tire	26 x 2.10" Kenda Multi-Terrain skinwall
Wheel Size	26" wheels

Geometry

Legacy reference · 6 measurements

Historical measurements. Frame size unknown.

All geometry measurementsLegacy reference · 6 measurements

Measurement	Legacy reference
Top tube	543.6 mm
Head-tube angle	71°
Seat-tube angle	73°
Chainstay / rear center	425.4 mm
Wheelbase	1043.9 mm
Fork offset / rake	44.4 mm

Frame size not recorded.

Gearing

Lower gears help on climbs. Higher gears suit higher speeds.

Pedal cadence

RPM

Speed units

RPM = pedal turns per minute.

Published build42/34/24T · 11–28T · 7-speed

Lowest0.86:1 Highest3.82:1 Total range445%

Estimated speed At 90 RPM Lowest gear6.0 mph Highest gear26.8 mph

Uses front tire 26×2.1; rear size isn’t listed.

How it works

Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.

Speeds are estimates from tire size and pedal cadence. Actual speeds vary.

Try other gearing

Try your current gearingChanged tires or gears? Calculate your setup.

Your changes apply to this calculation. The archived build stays unchanged.

Gears Drivetrain

Front teeth Smallest rear teeth Largest rear teeth

Use up to three front tooth counts, separated by /. For one rear sprocket, enter the same count twice.

Rear tire

Rear tire marking

Apply the marking on your rear tire or edit its dimensions below. Older or fractional inch sizes need the ISO marking (e.g. 37-590).

Rim diameter (BSD, mm) Tire width (mm)

For 32-622, width is 32 mm and rim diameter is 622 mm. Use the rear tire on mixed-wheel bikes. Leave both fields empty to compare ratios only.

Cadence (RPM) Speed units

Gear, dimension and cadence changes update results automatically.

Gearing comparison
Measure	Original	Your setup
Lowest ratio	—	—
Highest ratio	—	—
Total range	—	—
Lowest-gear speed	—	—
Highest-gear speed	—	—

Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.

Parts & serviceability

Find replacement parts

Original specifications

Chain · Original

Shimano CN-UG50

1/2 x 3/32"

Search Amazon Search eBay

Front tire · Original

26 x 2.10" Kenda Multi-Terrain skinwall

Search Amazon Search eBay

Pedals · Original

Wellgo Hi-Impact resin

toe-clip attachable

Search Amazon Search eBay

More parts (4)Fewer parts

Crankset · Original

Shimano Alivio HyperDrive-C

24/34/42 teeth

Search eBay

Rear derailleur · Original

Shimano Alivio GS

Search eBay

Seatpost · Original

Lee Chi alloy SP-204

26.0 mm diameter

Search Amazon Search eBay

Hubs · Original

Shimano AceraX

Search eBay

Based on the original build. Check fit and installed parts before ordering. Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.

Parts and service referenceQuick reference before buying parts

Archived specifications for reference. Check the fitted parts before ordering.

Front tire: 26 x 2.10" Kenda Multi-Terrain skinwall
Drivetrain: 7-speed
Seatpost diameter: 26 mm

Equipment inspection checks 9 checks based on 5 archived component groups Open equipment checksClose equipment checks

Checks selected from the archived equipment. Confirm what is fitted today. This is not a complete safety inspection; use the full inspection guide before test riding.

Full used-bike inspection guide →

Frame and fork

Inspect the frame and fork →

Archived: Frame: TIG-welded steel · Fork: · Hi-tensile steel / chromoly, unicrown crown

Check paint damage, vent holes and accessible internal surfaces for corrosion. Look for dents, bent tubes and cracking around welded or brazed joints.

Drivetrain

Check drivetrain wear →

Archived: Group: Shimano Alivio · Shifters: Shimano AceraX RapidFire TX · Front derailleur: Shimano AceraX, top-pull/clamp-on 28.6 mm · Rear derailleur: Shimano Alivio GS · Crankset: Shimano Alivio HyperDrive-C, 24/34/42 teeth · Rear cogs: 7-speed, 11 - 28 teeth · Chain: Shimano CN-UG50, 1/2 x 3/32"

Shift through every available gear under light load. Hesitation, skipping or inconsistent indexing can reflect wear, damage, poor adjustment or mismatched replacement parts.
Measure chain wear with a compatible gauge and inspect chainring, cassette or freewheel teeth. A new chain does not rule out wear in the remaining drivetrain.
Turn the cranks slowly, feel for rough bearings and check for side-to-side play. Inspect crank arms, chainring bolts and pedal threads for looseness or damage.

Brakes

Inspect the brakes →

Archived: Brakes: Shimano Altus C90 brakes, Shimano AceraX levers

Inspect pads and braking surfaces, check the complete cable or hose path, and confirm both controls feel consistent and return cleanly.

Wheels and tires

Check wheels and tires →

Archived: Wheel size: 26" wheels · Rims: Rodi Vuelta Strong Ti-Ano, 36-hole · Hubs: Shimano AceraX · Front tire: 26 x 2.10" Kenda Multi-Terrain skinwall

Spin both wheels and watch for side-to-side and vertical movement. Check spoke tension, rim condition and hub play.
Inspect both tire casings for cuts, cracking, plugs, bulges or exposed threads and confirm the installed sizes are safe for the rims and available frame and fork clearance.

Controls and contact points

Archived: Headset: 1" Tien Hsin TH steel · Handlebar: Steel · Stem: Steel · Seatpost: Lee Chi alloy SP-204, 26.0 mm diameter · Saddle: Vetta SE · Pedals: Wellgo Hi-Impact resin, toe-clip attachable

Apply the front brake and rock the bike to check for headset play or notchiness. Inspect the stem, handlebar and clamp zones, then confirm every fastener and control is secure.
Check that the seatpost moves for adjustment and that the saddle, post and clamp hold securely without cracks, severe corrosion or damaged hardware.
