2024 Norco 2024 Sight C1
Original specifications: 29"; 29"/27.5" wheels · 15.9 kg (35.1 lbs) published weight · geometry for 5 published sizes.
Planning to sell? Draft your listing
At a glance
Archive #900001355- Model year
- 2024
- Category
- Mountain
- Original MSRP
- $7,499.00
- Sizes
- 1, 2, 3, 4, 5
- Colors
- White/Olive
- Weight
- 15.9 kg (35.1 lbs)
- Geometry
- 5 manufacturer sizes
- In this record
- 21 specifications · 4 archived images · original MSRP · geometry
Original buildCarbon Fiber · 29"; 29"/27.5"
Frameset
| Frame Construction | Sight Carbon, VPS HP, 150mm Travel, UDH Compatible |
|---|---|
| Frame Material | Carbon Fiber |
| Fork | Fox Factory FLOAT 36, HSC / LSC / LSR, GRIP2, 160mm, 44mm Offset |
| Rear Shock | Fox Factory DHX2 Coil, HSC/LSC, HSR/LSR 2 pos., 60x205mm Trunnion, Sprindex Spring |
Drivetrain
| Shifters | SRAM Pod Ultimate Controller |
|---|---|
| Rear Derailleur | SRAM GX Eagle AXS T-Type |
| Crankset | SRAM GX Eagle T-Type 30T, 170mm |
| Bottom Bracket | SRAM DUB BSA Threaded |
| Cassette | SRAM Eagle T-Type 1275 10-52T |
| Chain | SRAM GX Eagle T-Type |
Brakes
| Brakes | (F) SRAM Code Silver Stealth, 4-Piston, Sintered Pads / (R) SRAM Code Silver Stealth, 4-Piston, Sintered Pads; Rotors: (F) SRAM Centerline 200mm / (R) SRAM Centerline 180mm; Levers: SRAM Code Silver Stealth |
|---|
Cockpit & Contact Points
| Headset | FSA #57 E Sealed Bearing |
|---|---|
| Handlebar | Deity Ridgeline 35, 800mm, 25mm Rise |
| Stem | Alloy CNC, 40mm Length. 35mm Clamp |
| Saddle | SDG Bel Air V3 |
| Seatpost | One Up adjustable dropper, 34.9mm, 150mm (1), 180mm (2), 210mm (3, 4), 240mm (5) |
Wheels & Tires
| Hubs | (F) Race Face Vault 15x110mm Boost, 6-Bolt / (R) Race Face Vault 12x148mm Boost, XD, 6-Bolt |
|---|---|
| Rims | Stan's Flow S2, Black 32H, 29"/29" |
| Front Tire | Maxxis Minion DHF 2.5", 3C, MaxxTerra / EXO+ / TR, Folding |
| Rear Tire | Maxxis Minion DHR II 2.4" WT, 3C, MaxxTerra / EXO+ / TR, Folding |
| Wheel Size | 29"; 29"/27.5" |
No specifications match. Try a component name or clear your search.
Geometry
Frame measurements by size.
Frame diagram
Select an available measurement to locate it on the frame.
All geometry measurements10 size / setup combinations · 17 measurements
| Measurement | 1 · 29" | 2 · 29" | 3 · 29" | 4 · 29" | 5 · 29" | 1 · 29"/27.5" | 2 · 29"/27.5" | 3 · 29"/27.5" | 4 · 29"/27.5" | 5 · 29"/27.5" |
|---|---|---|---|---|---|---|---|---|---|---|
| Seat tube | 350 mm | 370 mm | 385 mm | 430 mm | 445 mm | 350 mm | 370 mm | 385 mm | 430 mm | 445 mm |
| Effective top tube | 565 mm | 589 mm | 613 mm | 637 mm | 661 mm | 565 mm | 589 mm | 613 mm | 637 mm | 661 mm |
| Head tube | 105 mm | 115 mm | 125 mm | 135 mm | 145 mm | 105 mm | 115 mm | 125 mm | 135 mm | 145 mm |
| Head-tube angle | 64° | 64° | 64° | 64° | 64° | 64° | 64° | 64° | 64° | 64° |
| Seat-tube angle | 77° | 77.25° | 77.5° | 77.75° | 78° | 77° | 77.25° | 77.5° | 77.75° | 78° |
| Chainstay / rear center | 426 mm | 430 mm | 434 mm | 438 mm | 442 mm | 420 mm | 424 mm | 428 mm | 432 mm | 436 mm |
| Wheelbase | 1186 mm | 1219 mm | 1253 mm | 1286 mm | 1319 mm | 1181 mm | 1214 mm | 1247 mm | 1281 mm | 1314 mm |
| Bottom-bracket drop | 25/25 | 25/25 | 25/25 | 25/25 | 25/25 | 25/4 | 25/4 | 25/4 | 25/4 | 25/4 |
| Bottom-bracket height | 353 mm | 353 mm | 353 mm | 353 mm | 353 mm | 353 mm | 353 mm | 353 mm | 353 mm | 353 mm |
| Reach | 422.5 mm | 447.5 mm | 472.5 mm | 497.5 mm | 522.5 mm | 422.5 mm | 447.5 mm | 472.5 mm | 497.5 mm | 522.5 mm |
| Stack | 618 mm | 627 mm | 636 mm | 645 mm | 654 mm | 618 mm | 627 mm | 636 mm | 645 mm | 654 mm |
| Standover height | 673 mm | 679 mm | 685 mm | 708 mm | 720 mm | 673 mm | 679 mm | 685 mm | 708 mm | 720 mm |
| Fork offset / rake | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 135 mm | 135 mm | 135 mm | 135 mm | 135 mm | 135 mm | 135 mm | 135 mm | 135 mm | 135 mm |
| Crank length | 170 mm | 170 mm | 170 mm | 170 mm | 170 mm | 170 mm | 170 mm | 170 mm | 170 mm | 170 mm |
| Stem length | 40 mm | 40 mm | 40 mm | 40 mm | 40 mm | 40 mm | 40 mm | 40 mm | 40 mm | 40 mm |
| Wheel size | 29" | 29" | 29" | 29" | 29" | 29"/27.5" | 29"/27.5" | 29"/27.5" | 29"/27.5" | 29"/27.5" |
Dimensions as recorded.
Gearing
Lower gears help on climbs. Higher gears suit higher speeds.
RPM = pedal turns per minute.
Speed unavailable: wheel or tire size is missing or unclear.
Add your rear tire size to calculate speedHow it works
Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.
Speeds are estimates from tire size and pedal cadence. Actual speeds vary.
Try your current gearingChanged tires or gears? Calculate your setup.
Your changes apply to this calculation. The archived build stays unchanged.
Gearing results
| Measure | Original | Your setup |
|---|---|---|
| Lowest ratio | — | — |
| Highest ratio | — | — |
| Total range | — | — |
| Lowest-gear speed | — | — |
| Highest-gear speed | — | — |
Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.
Parts & serviceability
Find replacement parts
Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.
More parts (5)Fewer parts
170mm
34.9mm, 150mm (1), 180mm (2), 210mm (3, 4), 240mm (5)
Black 32H, 29"/29"
Based on the original build. Check fit and installed parts before ordering.
Parts and service referenceQuick reference before buying parts
Archived specifications for reference. Check the fitted parts before ordering.
- Front tire
- Maxxis Minion DHF 2.5", 3C, MaxxTerra / EXO+ / TR, Folding
- Rear tire
- Maxxis Minion DHR II 2.4" WT, 3C, MaxxTerra / EXO+ / TR, Folding
- Seatpost diameter
- 34.9 mm
- Bottom bracket / shell
- SRAM DUB BSA Threaded
Equipment inspection checks 13 checks based on 6 archived component groups Open equipment checksClose equipment checks
Checks selected from the archived equipment. Confirm what is fitted today. This is not a complete safety inspection; use the full inspection guide before test riding.
Full used-bike inspection guide →
Frame and fork
Inspect the frame and fork →Archived: Frame: Sight Carbon, VPS HP, 150mm Travel, UDH Compatible · Fork: Fox Factory FLOAT 36, HSC / LSC / LSR, GRIP2, 160mm, 44mm Offset
Suspension
Evaluate the suspension →Archived: Fork: Fox Factory FLOAT 36, HSC / LSC / LSR, GRIP2, 160mm, 44mm Offset · Rear shock: Fox Factory DHX2 Coil, HSC/LSC, HSR/LSR 2 pos., 60x205mm Trunnion, Sprindex Spring
Drivetrain
Check drivetrain wear →Archived: Shifters: SRAM Pod Ultimate Controller · Rear derailleur: SRAM GX Eagle AXS T-Type · Crankset: SRAM GX Eagle T-Type 30T, 170mm · Bottom bracket: SRAM DUB BSA Threaded · Cassette: SRAM Eagle T-Type 1275 10-52T · Chain: SRAM GX Eagle T-Type
Brakes
Inspect the brakes →Archived: Brakes: (F) SRAM Code Silver Stealth, 4-Piston, Sintered Pads / (R) SRAM Code Silver Stealth, 4-Piston, Sintered Pads; Rotors: (F) SRAM Centerline 200mm / (R) SRAM Centerline 180mm; Levers: SRAM Code Silver Stealth
Wheels and tires
Check wheels and tires →Archived: Wheel size: 29"; 29"/27.5" · Rims: Stan's Flow S2, Black 32H, 29"/29" · Hubs: (F) Race Face Vault 15x110mm Boost, 6-Bolt / (R) Race Face Vault 12x148mm Boost, XD, 6-Bolt · Front tire: Maxxis Minion DHF 2.5", 3C, MaxxTerra / EXO+ / TR, Folding · Rear tire: Maxxis Minion DHR II 2.4" WT, 3C, MaxxTerra / EXO+ / TR, Folding
Controls and contact points
Archived: Headset: FSA #57 E Sealed Bearing · Handlebar: Deity Ridgeline 35, 800mm, 25mm Rise · Stem: Alloy CNC, 40mm Length. 35mm Clamp · Seatpost: One Up adjustable dropper, 34.9mm, 150mm (1), 180mm (2), 210mm (3, 4), 240mm (5) · Saddle: SDG Bel Air V3
