Velopedia Bicycle Archive
2009 Norco Storm
Mountain bike, front suspension bicycle from the Velopedia historical specification archive.
- Original MSRP
- $0.00
- Sizes
- 12.5", 15", 17", 18.5", 20", 22"
- Colors
- Black/White
- Archive ID
- 16754
Frameset
| Frame Construction | TIG-welded |
|---|---|
| Frame Material | Hydraformed Aluminum |
| Fork | RockShox Dart 2, 100mm travel |
| Fork Material | Single |
| Rear Shock | N/A |
Drivetrain
| Component Group | Mountain Mix |
|---|---|
| Shifters | Shimano Alivio |
| Front Derailleur | Shimano Alivio, 31.8mm clamp |
| Rear Derailleur | Shimano Deore |
| Crankset | Shimano Alivio, 22/32/42 teeth |
| Bottom Bracket | Shimano ES25 |
| Cassette | Shimano HG30 |
| Rear Cogs | 8-speed, 11 - 32 teeth |
| Chain | KMC Z72, 1/2 x 3/32" |
| Pedals | Not included |
Brakes
| Brakes | Avid Juicy 3 w/ 6" rotor brakes, Avid Juicy 3 levers |
|---|
Cockpit & Contact Points
| Headset | 1 1/8" threadless CH-918 |
|---|---|
| Handlebar | Ritchey MTN |
| Handlebar Extensions | Not included |
| Stem | Ritchey |
| Saddle | WTB Silverado Comp |
| Seatpost | Ritchey, 27.2mm diameter |
Wheels & Tires
| Hubs | Shimano M475 |
|---|---|
| Rims | WTB SX-24, 32-hole |
| Spokes | Stainless, straight gauge |
| Front Tire | 26 x 2.10" Continental Speed King |
| Wheel Size | 26" wheels |
Historical specifications are presented as an archival reference. Component specifications may have varied by market, size, or production run.
