2004 Norco Bushpilot

Original specifications: Shimano Alivio · 8-speed · mechanical rear derailleur · 26" wheels.

Share owner experience

Planning to sell? Draft your listing

At a glance

Archive #30768
Model year
2004
Category
Mountain
Sizes
12.5", 15", 17", 18.5", 20", 22"
Colors
Blue/Silver, Red/Titanium
In this record
26 specifications · archived image
Model history 11 other years

Browse other years

Compare side by side

Identification clues

2004 archived details

Published colors
Blue/Silver, Red/Titanium
Frame
Aluminum
Original equipment
Mountain Mix

Clues, not proof of model year. Colors vary and components may have been replaced.

Original buildAluminum · Mountain Mix · 26" wheels

Manufacturer catalog

Published sizes and colors

6 sizes · 2 colors

Manufacturer-published sizes and colors; availability and exact size/color pairings may vary by market or production run.

Published sizes

12.5"15"17"18.5"20"22"

Published colors

Blue/SilverRed/Titanium

Frameset

Frame ConstructionTIG-welded
Frame MaterialAluminum
ForkSR Suntour XC60, 75mm travel
Fork MaterialAluminum, single crown

Drivetrain

Component GroupMountain Mix
ShiftersShimano EF-35
Front DerailleurShimano Acera, top-pull/clamp-on 31.8mm
Rear DerailleurShimano Alivio
CranksetShimano FX-TX-70, 24/34/42 teeth
Bottom BracketChin Haur CH-52
Rear Cogs8-speed, 11 - 32 teeth
ChainKMC Z72, 1/2 x 3/32"
PedalsWellgo LU-207

Brakes

BrakesTektro 832A linear pull brakes, Shimano levers

Cockpit & Contact Points

Headset1 1/8" threadless CS-568
HandlebarAluminum
Handlebar ExtensionsNot included
StemAluminum threadless
SaddleVelo VL-3048
SeatpostLee Chi SP-243

Wheels & Tires

HubsFront: Formula FM-31, Rear: Formula FM-32-8
RimsAlex Ace 18, 36-hole
SpokesChun Nan stainless steel, 14ga. (2.0mm) straight gauge
Spoke NipplesBrass nipples
Front Tire26 x 2.10" Kenda Klaw XT
Wheel Size26" wheels

Gearing

Lower gears help on climbs. Higher gears suit higher speeds.

RPM

RPM = pedal turns per minute.

All published sizes42/34/24T · 11–32T · 8-speed
Lowest0.75:1 Highest3.82:1 Total range509%
Estimated speed At 90 RPM Lowest gear5.3 mph Highest gear26.8 mph

Uses front tire 26×2.1; rear size isn’t listed.

How it works

Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.

Speeds are estimates from tire size and pedal cadence. Actual speeds vary.

Try other gearing

Try your current gearingChanged tires or gears? Calculate your setup.

Your changes apply to this calculation. The archived build stays unchanged.

Your gearing setup
Gears

Use up to three front tooth counts, separated by /. For one rear sprocket, enter the same count twice.

Rear tire

Apply the marking on your rear tire or edit its dimensions below. Older or fractional inch sizes need the ISO marking (e.g. 37-590).

For 32-622, width is 32 mm and rim diameter is 622 mm. Use the rear tire on mixed-wheel bikes. Leave both fields empty to compare ratios only.

Gear, dimension and cadence changes update results automatically.

Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.

Parts & serviceability

Find replacement parts

Original specifications
Chain · Original
KMC Z72

1/2 x 3/32"

Front tire · Original
26 x 2.10" Kenda Klaw XT
Brake pads · Original
Tektro 832A linear pull brakes

Shimano levers

More parts (4)Fewer parts
Pedals · Original
Wellgo LU-207
Crankset · Original
Shimano FX-TX-70

24/34/42 teeth

Rear derailleur · Original
Shimano Alivio
Rims · Original
Alex Ace 18

36-hole

Based on the original build. Check fit and installed parts before ordering. Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.

Parts and service referenceQuick reference before buying parts

Archived specifications for reference. Check the fitted parts before ordering.

Front tire
26 x 2.10" Kenda Klaw XT
Drivetrain
8-speed
Bottom bracket / shell
Chin Haur CH-52
Equipment inspection checks 11 checks based on 6 archived component groups Open equipment checksClose equipment checks
0 of 11 checked Progress stays in this browser for this record.

Checks selected from the archived equipment. Confirm what is fitted today. This is not a complete safety inspection; use the full inspection guide before test riding.

Full used-bike inspection guide →

Archived: Frame: TIG-welded · Fork: SR Suntour XC60, 75mm travel · Aluminum, single crown

Archived: Fork: SR Suntour XC60, 75mm travel

Archived: Group: Mountain Mix · Shifters: Shimano EF-35 · Front derailleur: Shimano Acera, top-pull/clamp-on 31.8mm · Rear derailleur: Shimano Alivio · Crankset: Shimano FX-TX-70, 24/34/42 teeth · Bottom bracket: Chin Haur CH-52 · Rear cogs: 8-speed, 11 - 32 teeth · Chain: KMC Z72, 1/2 x 3/32"

Archived: Brakes: Tektro 832A linear pull brakes, Shimano levers

Archived: Wheel size: 26" wheels · Rims: Alex Ace 18, 36-hole · Hubs: Front: Formula FM-31, Rear: Formula FM-32-8 · Front tire: 26 x 2.10" Kenda Klaw XT

Controls and contact points

Archived: Headset: 1 1/8" threadless CS-568 · Handlebar: Aluminum · Stem: Aluminum threadless · Seatpost: Lee Chi SP-243 · Saddle: Velo VL-3048 · Pedals: Wellgo LU-207
