Uses front tire 700C×38; rear size isn’t listed.
Velopedia Bicycle Archive
1999 Norco Monterey
Original specifications: Shimano Nexave 300 drivetrain · 700c wheels · legacy reference geometry.
Planning to sell? Draft your listing
At a glance
Archive #88501- Model year
- 1999
- Category
- Hybrid
- Original MSRP
- $399.00
- Sizes
- 16", 18", 20", 22", womens 17", womens 19"
- Colors
- Bright Red
- Geometry
- Legacy reference
- In this record
- 27 specifications · archived image · original MSRP · geometry
Model history 13 other years
Browse other years
Compare side by side
Identification clues
1999 archived details
- Published colors
- Bright Red
- Frame
- 4130 chromoly
- Original equipment
- Shimano Nexave 300
Clues, not proof of model year. Colors vary and components may have been replaced.
Original build4130 chromoly · Shimano Nexave 300 · 700c wheels
Frameset
| Frame Construction | TIG-welded |
|---|---|
| Frame Material | 4130 chromoly |
| Fork | Norco |
| Fork Material | 4130 chromoly, unicrown crown |
Drivetrain
| Component Group | Shimano Nexave 300 |
|---|---|
| Shifters | Shimano Nexave 300 |
| Front Derailleur | Shimano Nexave top-swing, clamp-on 31.8mm |
| Rear Derailleur | Shimano Nexave 400 |
| Crankset | Shimano Nexave 300, 28/38/48 teeth |
| Bottom Bracket | Shimano BB-CS15, 122mm spindle |
| BB Shell Width | 68mm English |
| Rear Cogs | 7-speed, 11 - 34 teeth |
| Chain | KMC Z-72, 1/2 x 3/32" |
| Pedals | Victor |
Brakes
| Brakes | Shimano Nexave modulated V brakes, Shimano Nexave 300 levers |
|---|
Cockpit & Contact Points
| Headset | 1" YST steel |
|---|---|
| Handlebar | Hsin Lung aluminum |
| Handlebar Extensions | Not included |
| Stem | Hsin Lung adjustable |
| Saddle | Velo VL-323 |
| Seatpost | JD Components JD-515 suspension, 27.2mm diameter |
Wheels & Tires
| Hubs | Front: Formula FM 11 Q/R, Rear: Shimano AceraX |
|---|---|
| Rims | Alex X-202, 36-hole |
| Spokes | Chung Nan steel, 2.0mm straight gauge |
| Spoke Nipples | Brass nipples |
| Front Tire | 700 x 38c Kenda K-830 |
| Wheel Size | 700c wheels |
No specifications match. Try a component name or clear your search.
Geometry
Historical measurements. Frame size unknown.
Reference drawing
Select an available measurement to locate it on the frame.
All geometry measurementsLegacy reference · 6 measurements
| Measurement | Legacy reference |
|---|---|
| Top tube | 549 mm |
| Head-tube angle | 70° |
| Seat-tube angle | 74° |
| Chainstay / rear center | 430 mm |
| Wheelbase | 1060 mm |
| Fork offset / rake | 45 mm |
Frame size not recorded.
Gearing
Lower gears help on climbs. Higher gears suit higher speeds.
RPM = pedal turns per minute.
How it works
Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.
Speeds are estimates from tire size and pedal cadence. Actual speeds vary.
Try your current gearingChanged tires or gears? Calculate your setup.
Your changes apply to this calculation. The archived build stays unchanged.
Gearing results
| Measure | Original | Your setup |
|---|---|---|
| Lowest ratio | — | — |
| Highest ratio | — | — |
| Total range | — | — |
| Lowest-gear speed | — | — |
| Highest-gear speed | — | — |
Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.
Parts & serviceability
Find replacement parts
27.2mm diameter
More parts (4)Fewer parts
Shimano Nexave 300 levers
122mm spindle
28/38/48 teeth
36-hole
Based on the original build. Check fit and installed parts before ordering. Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.
Parts and service referenceQuick reference before buying parts
Archived specifications for reference. Check the fitted parts before ordering.
- Front tire
- 700 x 38c Kenda K-830
- Drivetrain
- 7-speed
- Seatpost diameter
- 27.2 mm
- Bottom bracket / shell
- Shimano BB-CS15, 122mm spindle · 68mm English
Equipment inspection checks 10 checks based on 5 archived component groups Open equipment checksClose equipment checks
Checks selected from the archived equipment. Confirm what is fitted today. This is not a complete safety inspection; use the full inspection guide before test riding.
Full used-bike inspection guide →
Frame and fork
Inspect the frame and fork →Archived: Frame: TIG-welded · Fork: Norco · 4130 chromoly, unicrown crown
Drivetrain
Check drivetrain wear →Archived: Group: Shimano Nexave 300 · Shifters: Shimano Nexave 300 · Front derailleur: Shimano Nexave top-swing, clamp-on 31.8mm · Rear derailleur: Shimano Nexave 400 · Crankset: Shimano Nexave 300, 28/38/48 teeth · Bottom bracket: Shimano BB-CS15, 122mm spindle · Rear cogs: 7-speed, 11 - 34 teeth · Chain: KMC Z-72, 1/2 x 3/32"
Brakes
Inspect the brakes →Archived: Brakes: Shimano Nexave modulated V brakes, Shimano Nexave 300 levers
Wheels and tires
Check wheels and tires →Archived: Wheel size: 700c wheels · Rims: Alex X-202, 36-hole · Hubs: Front: Formula FM 11 Q/R, Rear: Shimano AceraX · Front tire: 700 x 38c Kenda K-830
Controls and contact points
Archived: Headset: 1" YST steel · Handlebar: Hsin Lung aluminum · Stem: Hsin Lung adjustable · Seatpost: JD Components JD-515 suspension, 27.2mm diameter · Saddle: Velo VL-323 · Pedals: Victor
Have you owned this model?Help preserve its real-world history by sharing your owner experience.
Share the details that would help another rider understand how this model fits, rides and holds up over time. Velopedia reviews every contribution before publication.
Already contributed? Send me a fresh private edit link
For privacy, Velopedia shows the same confirmation whether or not an experience exists.
No recent price sample is available for this bike. Check eBay for matching listings.
Find this bike on eBay
Search eBay US; check the model year, size and installed components. We may earn a commission from purchases.
Specifications are presented as a reference. Components may vary by market, size, production run, or later manufacturer revisions.
