Uses front tire 26×2.5; rear size isn’t listed.
Velopedia Bicycle Archive
2008 Mongoose Black Diamond Triple
Original specifications: SRAM X9 · 9-speed · mechanical rear derailleur · 26" wheels.
Planning to sell? Draft your listing
No archive photo is available for this record.
At a glance
Archive #13389- Model year
- 2008
- Category
- Mountain
- Original MSRP
- $2,999.99
- Sizes
- S, M, L
- Colors
- Dirty Raw
- In this record
- 25 specifications · original MSRP
Model history 2 other years
Browse other years
Compare side by side
Identification clues
2008 archived details
- Published colors
- Dirty Raw
- Frame
- Aluminum
- Original equipment
- Downhill Mix
Clues, not proof of model year. Colors vary and components may have been replaced.
Original buildAluminum · Downhill Mix · 26" wheels
Frameset
| Frame Construction | TIG-welded |
|---|---|
| Frame Material | Aluminum |
| Fork | Marzocchi 66 RC3, 180mm travel |
| Fork Material | Single |
| Rear Shock | Marzocchi Roco TST R, 170 - 190mm adjustable travel |
Drivetrain
| Component Group | Downhill Mix |
|---|---|
| Shifters | SRAM X.9 Trigger |
| Rear Derailleur | SRAM X.9 |
| Crankset | FSA Gravity, 36 teeth |
| Bottom Bracket | FSA Mega EXO |
| Cassette | SRAM PG-990 |
| Rear Cogs | 9-speed, 11 - 34 teeth |
| Chain | KMC Z9900, 1/2 x 3/32" |
| Pedals | FUNN Soljam Viper |
Brakes
| Brakes | Formula Oro k24 w/203mm Rotor brakes, Formula K24 hydraulic levers |
|---|
Cockpit & Contact Points
| Headset | 1 1/2" to 1 1/8" FSA Orbit Z |
|---|---|
| Handlebar | Funn Fatboy |
| Stem | Funn Rippa |
| Saddle | SDG Bel Air |
| Seatpost | Titec Knock Scoper I-Beam Telescopic |
Wheels & Tires
| Hubs | Front: WTB Laser Disc Super Duty 20mm, Rear: WTB Laser Disc Super Duty 150x12mm |
|---|---|
| Rims | WTB Laser Disc FR |
| Spokes | WTB stainless steel |
| Front Tire | 26 x 2.50" Kenda Nevagal |
| Wheel Size | 26" wheels |
No specifications match. Try a component name or clear your search.
Gearing
Lower gears help on climbs. Higher gears suit higher speeds.
RPM = pedal turns per minute.
How it works
Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.
Speeds are estimates from tire size and pedal cadence. Actual speeds vary.
Try your current gearingChanged tires or gears? Calculate your setup.
Your changes apply to this calculation. The archived build stays unchanged.
Gearing results
| Measure | Original | Your setup |
|---|---|---|
| Lowest ratio | — | — |
| Highest ratio | — | — |
| Total range | — | — |
| Lowest-gear speed | — | — |
| Highest-gear speed | — | — |
Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.
Parts & serviceability
Find replacement parts
Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.
More parts (6)Fewer parts
36 teeth
Based on the original build. Check fit and installed parts before ordering.
Parts and service referenceQuick reference before buying parts
Archived specifications for reference. Check the fitted parts before ordering.
- Front tire
- 26 x 2.50" Kenda Nevagal
- Drivetrain
- 9-speed
- Bottom bracket / shell
- FSA Mega EXO
Equipment inspection checks 13 checks based on 6 archived component groups Open equipment checksClose equipment checks
Checks selected from the archived equipment. Confirm what is fitted today. This is not a complete safety inspection; use the full inspection guide before test riding.
Full used-bike inspection guide →
Frame and fork
Inspect the frame and fork →Archived: Frame: TIG-welded · Fork: Marzocchi 66 RC3, 180mm travel · Single
Suspension
Evaluate the suspension →Archived: Fork: Marzocchi 66 RC3, 180mm travel · Rear shock: Marzocchi Roco TST R, 170 - 190mm adjustable travel
Drivetrain
Check drivetrain wear →Archived: Group: Downhill Mix · Shifters: SRAM X.9 Trigger · Rear derailleur: SRAM X.9 · Crankset: FSA Gravity, 36 teeth · Bottom bracket: FSA Mega EXO · Cassette: SRAM PG-990 · Rear cogs: 9-speed, 11 - 34 teeth · Chain: KMC Z9900, 1/2 x 3/32"
Brakes
Inspect the brakes →Archived: Brakes: Formula Oro k24 w/203mm Rotor brakes, Formula K24 hydraulic levers
Wheels and tires
Check wheels and tires →Archived: Wheel size: 26" wheels · Rims: WTB Laser Disc FR · Hubs: Front: WTB Laser Disc Super Duty 20mm, Rear: WTB Laser Disc Super Duty 150x12mm · Front tire: 26 x 2.50" Kenda Nevagal
Controls and contact points
Archived: Headset: 1 1/2" to 1 1/8" FSA Orbit Z · Handlebar: Funn Fatboy · Stem: Funn Rippa · Seatpost: Titec Knock Scoper I-Beam Telescopic · Saddle: SDG Bel Air · Pedals: FUNN Soljam Viper
