2012 Masi Vincere

Original specifications.

Share owner experience

Planning to sell? Draft your listing

At a glance

Archive #3062577
Model year
2012
Category
Road
Sizes
49cm, 51cm, 53cm, 56cm, 58cm, 60cm
Colors
White/Red/Black
In this record
17 specifications · archived image
Model history 8 other years

Browse other years

Compare side by side

Identification clues

2012 archived details

Published colors
White/Red/Black
Frame
Masi double-butted alloy

Clues, not proof of model year. Colors vary and components may have been replaced.

Sponsored affiliate link
Original buildMasi double-butted alloy

Manufacturer catalog

Published sizes and colors

6 sizes · 1 color

Manufacturer-published sizes and colors; availability and exact size/color pairings may vary by market or production run.

Published sizes

49cm51cm53cm56cm58cm60cm

Published colors

White/Red/Black

Frameset

Frame MaterialMasi double-butted alloy
ForkMasi Elite Carbon

Drivetrain

ShiftersShimano Tiagra 10spd
Front DerailleurShimano Tiagra
Rear DerailleurShimano Tiagra
CranksetTruvativ Vero C2.1 50/34
Bottom BracketTruvativ cartridge bearing
CassetteShimano Tiagra 10spd 12-28t
ChainShimano Tiagra

Brakes

BrakesShimano Tiagra

Cockpit & Contact Points

HeadsetFsa
HandlebarMasi
StemMasi
SaddleMasi
SeatpostMasi

Wheels & Tires

RimsRitchey Pro DS
Front TireKenda Kotender 700 X 23c

Gearing

Lower gears help on climbs. Higher gears suit higher speeds.

All published sizes50/34T · 12–28T · 10-speed
Lowest1.21:1 Highest4.17:1 Total range343%

Speed unavailable: wheel or tire size is missing or unclear.

Add your rear tire size to calculate speed
How it works

Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.

Speeds are estimates from tire size and pedal cadence. Actual speeds vary.

Try other gearing

Try your current gearingChanged tires or gears? Calculate your setup.

Your changes apply to this calculation. The archived build stays unchanged.

Your gearing setup
Gears

Use up to three front tooth counts, separated by /. For one rear sprocket, enter the same count twice.

Rear tire

Apply the marking on your rear tire or edit its dimensions below. Older or fractional inch sizes need the ISO marking (e.g. 37-590).

For 32-622, width is 32 mm and rim diameter is 622 mm. Use the rear tire on mixed-wheel bikes. Leave both fields empty to compare ratios only.

Gear, dimension and cadence changes update results automatically.

Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.

Parts & serviceability

Find replacement parts

Original specifications

Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.

Front tire · Original
Kenda Kotender 700 X 23c
Retailer offers
Chain · Original
Shimano Tiagra
Cassette · Original
Shimano Tiagra 10spd 12-28t
More parts (4)Fewer parts
Front derailleur · Original
Shimano Tiagra
Rear derailleur · Original
Shimano Tiagra
Shifters · Original
Shimano Tiagra 10spd
Rims · Original
Ritchey Pro DS

Based on the original build. Check fit and installed parts before ordering.

Parts and service referenceQuick reference before buying parts

Archived specifications for reference. Check the fitted parts before ordering.

Front tire
Kenda Kotender 700 X 23c
Drivetrain
10-speed
Bottom bracket / shell
Truvativ cartridge bearing
Equipment inspection checks 10 checks based on 5 archived component groups Open equipment checksClose equipment checks
0 of 10 checked Progress stays in this browser for this record.

Checks selected from the archived equipment. Confirm what is fitted today. This is not a complete safety inspection; use the full inspection guide before test riding.

Full used-bike inspection guide →

Archived: Frame: Masi double-butted alloy · Fork: Masi Elite Carbon

Archived: Shifters: Shimano Tiagra 10spd · Front derailleur: Shimano Tiagra · Rear derailleur: Shimano Tiagra · Crankset: Truvativ Vero C2.1 50/34 · Bottom bracket: Truvativ cartridge bearing · Cassette: Shimano Tiagra 10spd 12-28t · Chain: Shimano Tiagra

Archived: Brakes: Shimano Tiagra

Archived: Rims: Ritchey Pro DS · Front tire: Kenda Kotender 700 X 23c

Controls and contact points

Archived: Headset: FSA · Handlebar: Masi · Stem: Masi · Seatpost: Masi · Saddle: Masi
