Uses front tire 700C×28; rear size isn’t listed.
Velopedia Bicycle Archive
2010 Masi Caffe Racer Doppio
Original specifications: Shimano Ultegra · 10-speed rear derailleur · 700c wheels.
Planning to sell? Draft your listing
No archive photo is available for this record.
At a glance
Archive #19851- Model year
- 2010
- Category
- City & Commuter
- Original MSRP
- $1,090.00
- Sizes
- 49cm, 51cm, 53cm, 56cm, 58cm, 60cm
- Colors
- Battle Grey
- In this record
- 26 specifications · original MSRP
Model history 3 other years
Browse other years
Compare side by side
Identification clues
2010 archived details
- Published colors
- Battle Grey
- Frame
- 7005 T6 double butted aluminum
- Original equipment
- Commuter Mix
Clues, not proof of model year. Colors vary and components may have been replaced.
Original build7005 T6 double butted aluminum · Commuter Mix · 700c wheels
Frameset
| Frame Construction | TIG-welded |
|---|---|
| Frame Material | 7005 T6 double butted aluminum |
| Fork | Masi Elite/RS Carbon |
| Fork Material | Carbon fiber/aluminum steerer, aero crown |
Drivetrain
| Component Group | Commuter Mix |
|---|---|
| Shifters | Shimano 770 Flat Bar |
| Front Derailleur | Shimano 770 |
| Rear Derailleur | Shimano Ultegra 6700 |
| Crankset | TruVativ Elita C 2.2, 50/34 teeth |
| Bottom Bracket | TruVativ Giga X Pipe |
| Cassette | Shimano 105 |
| Rear Cogs | 10-speed, 11 - 27 teeth |
| Chain | Shimano 105 |
| Pedals | Alloy cage w/clips & straps |
Brakes
| Brakes | Shimano M442 brakes, Avid FR-5 front/Avid FR- 5 rear levers |
|---|
Cockpit & Contact Points
| Headset | 1 1/8" threadless Ritchey Logic V2 |
|---|---|
| Handlebar | Ritchey 6061 |
| Handlebar Extensions | Not included |
| Stem | Ritchey 6061 |
| Saddle | Masi SLS w/ Crmo Rails |
| Seatpost | Masi alloy w/taillight, 27.2mm diameter |
Wheels & Tires
| Hubs | Front: Formula, Rear: formula cassette |
|---|---|
| Rims | Alex R500 |
| Spokes | Stainless |
| Front Tire | 700 x 28c Kenda Kwick Trax |
| Wheel Size | 700c wheels |
No specifications match. Try a component name or clear your search.
Gearing
Lower gears help on climbs. Higher gears suit higher speeds.
RPM = pedal turns per minute.
How it works
Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.
Speeds are estimates from tire size and pedal cadence. Actual speeds vary.
Try your current gearingChanged tires or gears? Calculate your setup.
Your changes apply to this calculation. The archived build stays unchanged.
Gearing results
| Measure | Original | Your setup |
|---|---|---|
| Lowest ratio | — | — |
| Highest ratio | — | — |
| Total range | — | — |
| Lowest-gear speed | — | — |
| Highest-gear speed | — | — |
Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.
Parts & serviceability
Find replacement parts
Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.

Vittoria Zaffiro Pro V Clincher Tire Black, 700x28
700x28c
Replacement option
27.2mm diameter

Race Face Ride XC Seatpost Black, 27.2x375mm
Replacement option
More parts (3)Fewer parts
Based on the original build. Check fit and installed parts before ordering.
Parts and service referenceQuick reference before buying parts
Archived specifications for reference. Check the fitted parts before ordering.
- Front tire
- 700 x 28c Kenda Kwick Trax
- Drivetrain
- 10-speed
- Seatpost diameter
- 27.2 mm
- Bottom bracket / shell
- TruVativ Giga X Pipe
Equipment inspection checks 10 checks based on 5 archived component groups Open equipment checksClose equipment checks
Checks selected from the archived equipment. Confirm what is fitted today. This is not a complete safety inspection; use the full inspection guide before test riding.
Full used-bike inspection guide →
Frame and fork
Inspect the frame and fork →Archived: Frame: TIG-welded · Fork: Masi Elite/RS Carbon · Carbon fiber/aluminum steerer, aero crown
Drivetrain
Check drivetrain wear →Archived: Group: Commuter Mix · Shifters: Shimano 770 Flat Bar · Front derailleur: Shimano 770 · Rear derailleur: Shimano Ultegra 6700 · Crankset: TruVativ Elita C 2.2, 50/34 teeth · Bottom bracket: TruVativ Giga X Pipe · Cassette: Shimano 105 · Rear cogs: 10-speed, 11 - 27 teeth · Chain: Shimano 105
Brakes
Inspect the brakes →Archived: Brakes: Shimano M442 brakes, Avid FR-5 front/Avid FR- 5 rear levers
Wheels and tires
Check wheels and tires →Archived: Wheel size: 700c wheels · Rims: Alex R500 · Hubs: Front: Formula, Rear: formula cassette · Front tire: 700 x 28c Kenda Kwick Trax
Controls and contact points
Archived: Headset: 1 1/8" threadless Ritchey Logic V2 · Handlebar: Ritchey 6061 · Stem: Ritchey 6061 · Seatpost: Masi alloy w/taillight, 27.2mm diameter · Saddle: Masi SLS w/ Crmo Rails · Pedals: Alloy cage w/clips & straps
Have you owned this model?Help document firsthand fit, ride and maintenance details that may no longer be available.
This archive record has limited published detail. Share what would help another rider understand how this model fit, rode and held up over time. Velopedia reviews every contribution before publication.
Already contributed? Send me a fresh private edit link
For privacy, Velopedia shows the same confirmation whether or not an experience exists.
No recent price sample is available for this bike. Check eBay for matching listings.
Find this bike on eBay
Search eBay US; check the model year, size and installed components. We may earn a commission from purchases.
Specifications are presented as a reference. Components may vary by market, size, production run, or later manufacturer revisions.
