2009 Masi Alare

Original specifications: Shimano Sora drivetrain · 700c wheels.

Share owner experience

Planning to sell? Draft your listing

At a glance

Archive #18179
Model year
2009
Category
Road
Original MSRP
$930.00
Sizes
47cm, 49cm, 51cm, 53cm, 56cm, 58cm, 60cm
Colors
Rosso Red, Ano White
In this record
26 specifications · archived image · original MSRP
Model history 7 other years

Browse other years

Compare side by side

Identification clues

2009 archived details

Published colors
Rosso Red, Ano White
Frame
7005 T6 Aluminum
Original equipment
Shimano Sora

Clues, not proof of model year. Colors vary and components may have been replaced.

Sponsored affiliate link
Original build7005 T6 Aluminum · Shimano Sora · 700c wheels

Historical catalog variants

Archived sizes and colors

14 item records

Item-level catalog entries recovered from Velopedia’s original bicycle archive. They document how this model was listed historically; they do not identify the frame size associated with legacy reference geometry or indicate current availability.

Published sizes

47cm49cm51cm53cm56cm58cm60cm

Published colors

Rosso RedAno White
View 14 archived size/color combinations
SizeColor
47cmRosso Red
49cmRosso Red
51cmRosso Red
53cmRosso Red
56cmRosso Red
58cmRosso Red
60cmRosso Red
47cmAno White
49cmAno White
51cmAno White
53cmAno White
56cmAno White
58cmAno White
60cmAno White

Historical catalog evidence. Exact specifications and naming may vary by market, production run or manufacturer revision.

Frameset

Frame ConstructionTIG-welded
Frame Material7005 T6 Aluminum
ForkMasi Elite/RS Carbon
Fork MaterialCarbon fiber/aluminum steerer, aero crown

Drivetrain

Component GroupShimano Sora
ShiftersShimano Sora STI
Front DerailleurShimano Sora
Rear DerailleurShimano Tiagra
CranksetTruVativ Touro 2.0, 34/50 teeth
Bottom BracketTruvativ Square Taper
CassetteShimano HG50
Rear Cogs9-speed, 12 - 25 teeth
ChainShimano HG73
PedalsAlloy Cage toe/clip & strap

Brakes

BrakesShimano Sora brakes, Shimano Sora STI levers

Cockpit & Contact Points

Headset1 1/8" Ritchey Logic V2
HandlebarMasi 6061
Handlebar ExtensionsNot included
StemMasi 3D Forged Flip/Flop
SaddleMasi SLS w/steel rails
SeatpostMasi Carbon, 27.2mm diameter

Wheels & Tires

HubsFormula alloy
RimsAlex R500, 32-hole
SpokesStainless
Front Tire700 x 23c Vittoria Zaffiro
Wheel Size700c wheels

Gearing

Lower gears help on climbs. Higher gears suit higher speeds.

RPM

RPM = pedal turns per minute.

All published sizes50/34T · 12–25T · 9-speed
Lowest1.36:1 Highest4.17:1 Total range306%
Estimated speed At 90 RPM Lowest gear9.6 mph Highest gear29.3 mph

Uses front tire 700C×23; rear size isn’t listed.

How it works

Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.

Speeds are estimates from tire size and pedal cadence. Actual speeds vary.

Try other gearing

Try your current gearingChanged tires or gears? Calculate your setup.

Your changes apply to this calculation. The archived build stays unchanged.

Your gearing setup
Gears

Use up to three front tooth counts, separated by /. For one rear sprocket, enter the same count twice.

Rear tire

Apply the marking on your rear tire or edit its dimensions below. Older or fractional inch sizes need the ISO marking (e.g. 37-590).

For 32-622, width is 32 mm and rim diameter is 622 mm. Use the rear tire on mixed-wheel bikes. Leave both fields empty to compare ratios only.

Gear, dimension and cadence changes update results automatically.

Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.

Parts & serviceability

Find replacement parts

Original specifications

Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.

Front tire · Original
700 x 23c Vittoria Zaffiro
Retailer offers
Seatpost · Original
Masi Carbon

27.2mm diameter

Retailer offers
Chain · Original
Shimano HG73
More parts (6)Fewer parts
Cassette · Original
Shimano HG50
Front derailleur · Original
Shimano Sora
Rear derailleur · Original
Shimano Tiagra
Shifters · Original
Shimano Sora STI
Headset · Original
1 1/8" Ritchey Logic V2
Rims · Original
Alex R500

32-hole

Based on the original build. Check fit and installed parts before ordering.

Parts and service referenceQuick reference before buying parts

Archived specifications for reference. Check the fitted parts before ordering.

Front tire
700 x 23c Vittoria Zaffiro
Drivetrain
9-speed
Seatpost diameter
27.2 mm
Bottom bracket / shell
Truvativ Square Taper
Equipment inspection checks 10 checks based on 5 archived component groups Open equipment checksClose equipment checks
0 of 10 checked Progress stays in this browser for this record.

Checks selected from the archived equipment. Confirm what is fitted today. This is not a complete safety inspection; use the full inspection guide before test riding.

Full used-bike inspection guide →

Archived: Frame: TIG-welded · Fork: Masi Elite/RS Carbon · Carbon fiber/aluminum steerer, aero crown

Archived: Group: Shimano Sora · Shifters: Shimano Sora STI · Front derailleur: Shimano Sora · Rear derailleur: Shimano Tiagra · Crankset: TruVativ Touro 2.0, 34/50 teeth · Bottom bracket: Truvativ Square Taper · Cassette: Shimano HG50 · Rear cogs: 9-speed, 12 - 25 teeth · Chain: Shimano HG73

Archived: Brakes: Shimano Sora brakes, Shimano Sora STI levers

Archived: Wheel size: 700c wheels · Rims: Alex R500, 32-hole · Hubs: Formula alloy · Front tire: 700 x 23c Vittoria Zaffiro

Controls and contact points

Archived: Headset: 1 1/8" Ritchey Logic V2 · Handlebar: Masi 6061 · Stem: Masi 3D Forged Flip/Flop · Seatpost: Masi Carbon, 27.2mm diameter · Saddle: Masi SLS w/steel rails · Pedals: Alloy Cage toe/clip & strap
