Velopedia Bicycle Archive
2007 Masi 3VC 105
Original specifications: Shimano 105 drivetrain · 700c wheels · 18.6 lb published weight.
Planning to sell? Draft your listing
No archive photo is available for this record.
At a glance
Archive #96181- Model year
- 2007
- Category
- Road
- Sizes
- 51cm, 54cm, 56cm, 58cm, 61cm
- Colors
- Ano Blue/Carbon
- Weight
- 18.6 lb
- In this record
- 25 specifications
Model history 4 other years
Browse other years
Compare side by side
Identification clues
2007 archived details
- Published colors
- Ano Blue/Carbon
- Frame
- High Modulus Full Carbon
- Original equipment
- Shimano 105
Clues, not proof of model year. Colors vary and components may have been replaced.
Original buildHigh Modulus Full Carbon · Shimano 105 · 700c wheels
Frameset
| Frame Construction | Monocoque |
|---|---|
| Frame Material | High Modulus Full Carbon |
| Fork | Masi Elite/RS |
| Fork Material | Carbon fiber/aluminum steerer, aero crown |
Drivetrain
| Component Group | Shimano 105 |
|---|---|
| Shifters | Shimano 105 STI |
| Front Derailleur | Shimano 105 |
| Rear Derailleur | Shimano Ultegra |
| Crankset | TruVativ Elita C 2.2, 34/50 teeth |
| Bottom Bracket | TruVativ Giga X Pipe |
| Rear Cogs | 10-speed, 11 - 25 teeth |
| Chain | Shimano 105 |
| Pedals | Not included |
Brakes
| Brakes | Tektro R-570 brakes, Shimano 105 STI levers |
|---|
Cockpit & Contact Points
| Headset | FSA Orbit IS |
|---|---|
| Handlebar | Ritchey Pro Logic |
| Handlebar Extensions | Not included |
| Stem | Masi ATS Adjustable |
| Saddle | Masi SLS w/ Crmo Rails |
| Seatpost | Masi Filament Wound Carbon, 27.2mm diameter |
Wheels & Tires
| Hubs | Shimano R500 |
|---|---|
| Rims | Shimano R500 |
| Spokes | Shimano |
| Front Tire | 700 x 23c Vittoria Zaffiro Pro |
| Wheel Size | 700c wheels |
No specifications match. Try a component name or clear your search.
Gearing
Lower gears help on climbs. Higher gears suit higher speeds.
RPM = pedal turns per minute.
How it works
Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.
Speeds are estimates from tire size and pedal cadence. Actual speeds vary.
Try your current gearingChanged tires or gears? Calculate your setup.
Your changes apply to this calculation. The archived build stays unchanged.
Gearing results
| Measure | Original | Your setup |
|---|---|---|
| Lowest ratio | — | — |
| Highest ratio | — | — |
| Total range | — | — |
| Lowest-gear speed | — | — |
| Highest-gear speed | — | — |
Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.
Parts & serviceability
Find replacement parts
Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.

Vittoria Rubino Pro G2.0 Clincher Tire Black, 700x23
700x23c
Replacement option
27.2mm diameter

Race Face Ride XC Seatpost Black, 27.2x375mm
Replacement option
More parts (7)Fewer parts
Based on the original build. Check fit and installed parts before ordering.
Parts and service referenceQuick reference before buying parts
Archived specifications for reference. Check the fitted parts before ordering.
- Front tire
- 700 x 23c Vittoria Zaffiro Pro
- Drivetrain
- 10-speed
- Seatpost diameter
- 27.2 mm
- Bottom bracket / shell
- TruVativ Giga X Pipe
Equipment inspection checks 10 checks based on 5 archived component groups Open equipment checksClose equipment checks
Checks selected from the archived equipment. Confirm what is fitted today. This is not a complete safety inspection; use the full inspection guide before test riding.
Full used-bike inspection guide →
Frame and fork
Inspect the frame and fork →Archived: Frame: Monocoque · Fork: Masi Elite/RS · Carbon fiber/aluminum steerer, aero crown
Drivetrain
Check drivetrain wear →Archived: Group: Shimano 105 · Shifters: Shimano 105 STI · Front derailleur: Shimano 105 · Rear derailleur: Shimano Ultegra · Crankset: TruVativ Elita C 2.2, 34/50 teeth · Bottom bracket: TruVativ Giga X Pipe · Rear cogs: 10-speed, 11 - 25 teeth · Chain: Shimano 105
Brakes
Inspect the brakes →Archived: Brakes: Tektro R-570 brakes, Shimano 105 STI levers
Wheels and tires
Check wheels and tires →Archived: Wheel size: 700c wheels · Rims: Shimano R500 · Hubs: Shimano R500 · Front tire: 700 x 23c Vittoria Zaffiro Pro
Controls and contact points
Archived: Headset: FSA Orbit IS · Handlebar: Ritchey Pro Logic · Stem: Masi ATS Adjustable · Seatpost: Masi Filament Wound Carbon, 27.2mm diameter · Saddle: Masi SLS w/ Crmo Rails · Pedals: Not included
Have you owned this model?Help document firsthand fit, ride and maintenance details that may no longer be available.
This archive record has limited published detail. Share what would help another rider understand how this model fit, rode and held up over time. Velopedia reviews every contribution before publication.
Already contributed? Send me a fresh private edit link
For privacy, Velopedia shows the same confirmation whether or not an experience exists.
No recent price sample is available for this bike. Check eBay for matching listings.
Find this bike on eBay
Search eBay US; check the model year, size and installed components. We may earn a commission from purchases.
Specifications are presented as a reference. Components may vary by market, size, production run, or later manufacturer revisions.
