Velopedia Bicycle Archive
2009 Marin Mount Vision 5.6
Mountain bike, front & rear suspension bicycle from the Velopedia historical specification archive.
- Original MSRP
- $1,999.99
- Sizes
- Xsmall, small, medium, large, xlarge
- Colors
- Silver, Brick
- Archive ID
- 17736
Frameset
| Frame Construction | TIG-welded |
|---|---|
| Frame Material | 6066 hydroformed aluminum |
| Fork | RockShox Tora 302 Solo Air, 120mm travel |
| Fork Material | Single |
| Rear Shock | Fox Float R, 120mm travel |
Drivetrain
| Component Group | Shimano Deore |
|---|---|
| Shifters | Shimano Deore Rapidfire |
| Front Derailleur | Shimano Deore |
| Rear Derailleur | Shimano SLX |
| Crankset | TruVativ Fire D 3.1, 22/32/44 teeth |
| Bottom Bracket | Truvativ sealed cartridge |
| Cassette | Shimano |
| Rear Cogs | 9-speed, 11 - 34 teeth |
| Chain | Shimano HG-53 |
| Pedals | Ritchey V4 Clipless |
Brakes
| Brakes | Hayes Stroker Ryde w/160mm rotor brakes, Hayes Stroker Ryde levers |
|---|
Cockpit & Contact Points
| Headset | 1 1/8" TH-888 |
|---|---|
| Handlebar | Double Butted 6061 Alloy OS riser |
| Handlebar Extensions | Not included |
| Stem | Marin OS Alloy |
| Saddle | WTB Speed V ATB |
| Seatpost | Comp Alloy Micro Adjust, 30.9mm diameter |
Wheels & Tires
| Hubs | Shimano Deore disc |
|---|---|
| Rims | Mavic XM 117, 32-hole |
| Spokes | WTB stainless, 15ga. (1.8mm) |
| Front Tire | 26 x 2.24" WTB MotoRaptor Comp |
| Wheel Size | 26" wheels |
Historical specifications are presented as an archival reference. Component specifications may have varied by market, size, or production run.
