Lowest0.69:1
Highest4.00:1
Total range582%
Estimated speed At 90 RPM
Lowest gear
Highest gear
Uses front tire 26×2.14; rear size isn’t listed.
Velopedia Bicycle Archive
2007 Marin Juniper Trail
Original specifications: Shimano LX drivetrain · 26" wheels.
Planning to sell? Draft your listing
At a glance
Archive #16366- Model year
- 2007
- Category
- Mountain
- Original MSRP
- $959.00
- Sizes
- 13", 15", 17"
- Colors
- Gloss Vapor
- In this record
- 25 specifications · archived image · original MSRP
Model history 6 other years
Browse other years
Compare side by side
Identification clues
2007 archived details
- Published colors
- Gloss Vapor
- Frame
- Hydroformed 6061 Aluminum
- Original equipment
- Shimano LX
Clues, not proof of model year. Colors vary and components may have been replaced.
Original buildHydroformed 6061 Aluminum · Shimano LX · 26" wheels
Frameset
| Frame Construction | TIG-welded |
|---|---|
| Frame Material | Hydroformed 6061 Aluminum |
| Fork | Marzocchi MZ Race, 100mm |
| Fork Material | Magnesium/steel/aluminum, single crown |
Drivetrain
| Component Group | Shimano LX |
|---|---|
| Shifters | Shimano LX |
| Front Derailleur | Shimano Deore |
| Rear Derailleur | Shimano LX |
| Crankset | TruVativ Five D 3.1, 22/32/44 teeth |
| Bottom Bracket | TruVativ PowerSpline |
| Rear Cogs | 9-speed, 11 - 32 teeth |
| Chain | Shimano CN-HG53 |
| Pedals | Alloy Mountain |
Brakes
| Brakes | Hayes Sole w/V6 Rotors brakes, Hayes Hydraulic Disc levers |
|---|
Cockpit & Contact Points
| Headset | 1 1/8" threadless TH-888 |
|---|---|
| Handlebar | Women’s Double Butted Alloy |
| Handlebar Extensions | Not included |
| Stem | FSA OS170 |
| Saddle | WTB Speed She Comp |
| Seatpost | FSA SL-280, 30.9mm diameter |
Wheels & Tires
| Hubs | Shimano Disc |
|---|---|
| Rims | WTB SX24, 32-hole |
| Spokes | WTB stainless steel, 15ga. (1.8mm) straight gauge |
| Front Tire | 26 x 2.14" WTB MotoRaptor Comp |
| Wheel Size | 26" wheels |
No specifications match. Try a component name or clear your search.
Gearing
Lower gears help on climbs. Higher gears suit higher speeds.
RPM
RPM = pedal turns per minute.
How it works
Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.
Speeds are estimates from tire size and pedal cadence. Actual speeds vary.
Try your current gearingChanged tires or gears? Calculate your setup.
Your changes apply to this calculation. The archived build stays unchanged.
Gearing results
| Measure | Original | Your setup |
|---|---|---|
| Lowest ratio | — | — |
| Highest ratio | — | — |
| Total range | — | — |
| Lowest-gear speed | — | — |
| Highest-gear speed | — | — |
Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.
Parts & serviceability
Find replacement parts
WTB Speed She Comp
More parts (5)Fewer parts
Shimano Deore
Shimano LX
Shimano LX
FSA OS170
WTB SX24
32-hole
Based on the original build. Check fit and installed parts before ordering. Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.
Parts and service referenceQuick reference before buying parts
Archived specifications for reference. Check the fitted parts before ordering.
- Front tire
- 26 x 2.14" WTB MotoRaptor Comp
- Drivetrain
- 9-speed
- Bottom bracket / shell
- TruVativ PowerSpline
Equipment inspection checks 11 checks based on 6 archived component groups Open equipment checksClose equipment checks
Checks selected from the archived equipment. Confirm what is fitted today. This is not a complete safety inspection; use the full inspection guide before test riding.
Full used-bike inspection guide →
Frame and fork
Inspect the frame and fork →Archived: Frame: TIG-welded · Fork: Marzocchi MZ Race, 100mm · Magnesium/steel/aluminum, single crown
Suspension
Evaluate the suspension →Archived: Fork: Marzocchi MZ Race, 100mm
Drivetrain
Check drivetrain wear →Archived: Group: Shimano LX · Shifters: Shimano LX · Front derailleur: Shimano Deore · Rear derailleur: Shimano LX · Crankset: TruVativ Five D 3.1, 22/32/44 teeth · Bottom bracket: TruVativ PowerSpline · Rear cogs: 9-speed, 11 - 32 teeth · Chain: Shimano CN-HG53
Brakes
Inspect the brakes →Archived: Brakes: Hayes Sole w/V6 Rotors brakes, Hayes Hydraulic Disc levers
Wheels and tires
Check wheels and tires →Archived: Wheel size: 26" wheels · Rims: WTB SX24, 32-hole · Hubs: Shimano Disc · Front tire: 26 x 2.14" WTB MotoRaptor Comp
Controls and contact points
Archived: Headset: 1 1/8" threadless TH-888 · Handlebar: Women’s Double Butted Alloy · Stem: FSA OS170 · Seatpost: FSA SL-280, 30.9mm diameter · Saddle: WTB Speed She Comp · Pedals: Alloy Mountain
Have you owned this model?Help document firsthand fit, ride and maintenance details that may no longer be available.
This archive record has limited published detail. Share what would help another rider understand how this model fit, rode and held up over time. Velopedia reviews every contribution before publication.
Already contributed? Send me a fresh private edit link
For privacy, Velopedia shows the same confirmation whether or not an experience exists.
Checking current listings…
Find this bike on eBay
Search eBay US; check the model year, size and installed components. We may earn a commission from purchases.
Specifications are presented as a reference. Components may vary by market, size, production run, or later manufacturer revisions.
