Lowest1.11:1
Highest4.17:1
Total range375%
Estimated speed At 90 RPM
Lowest gear
Highest gear
Uses front tire 700C×28; rear size isn’t listed.
Velopedia Bicycle Archive
2007 Marin Highway One
Original specifications: Shimano Ultegra · 10-speed · mechanical rear derailleur · 700c wheels.
Planning to sell? Draft your listing
At a glance
Archive #16364- Model year
- 2007
- Category
- Road
- Original MSRP
- $2,559.00
- Sizes
- 15.5", 17.5", 19", 20.5"
- Colors
- Carbon Gloss Black
- In this record
- 24 specifications · archived image · original MSRP
Model history 12 other years
Browse other years
Compare side by side
Identification clues
2007 archived details
- Published colors
- Carbon Gloss Black
- Frame
- CXR Venus 7 Carbon
- Original equipment
- Road Mix
Clues, not proof of model year. Colors vary and components may have been replaced.
Original buildCXR Venus 7 Carbon · Road Mix · 700c wheels
Frameset
| Frame Construction | Bonded/monocoque |
|---|---|
| Frame Material | CXR Venus 7 Carbon |
| Fork | Carbon Monocoque Rigid |
| Fork Material | Carbon/aluminum steerer, aero crown |
Drivetrain
| Component Group | Road Mix |
|---|---|
| Shifters | Shimano SL-R770 |
| Front Derailleur | Shimano R773 |
| Rear Derailleur | Shimano Ultegra |
| Crankset | FSA K-Force Carbon, 30/39/50 teeth |
| Bottom Bracket | FSA Mega EXO |
| Rear Cogs | 10-speed, 12 - 27 teeth |
| Chain | Shimano 105 |
| Pedals | Not included |
Brakes
| Brakes | Avid Single Digit 7 brakes, Shimano BL-M420 levers |
|---|
Cockpit & Contact Points
| Headset | 1 1/8" threadless FSA Orbit C |
|---|---|
| Handlebar | Carbon XC flat |
| Handlebar Extensions | Not included |
| Stem | FSA OS115 |
| Saddle | WTB Silverado Race |
| Seatpost | FSA SL-K, Carbon, 27.2mm diameter |
Wheels & Tires
| Hubs | Mavic Aksium |
|---|---|
| Rims | Mavic Aksium, 20-hole/24-hole |
| Front Tire | 700 x 28c Vittoria Zaffiro |
| Wheel Size | 700c wheels |
No specifications match. Try a component name or clear your search.
Gearing
Lower gears help on climbs. Higher gears suit higher speeds.
RPM
RPM = pedal turns per minute.
How it works
Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.
Speeds are estimates from tire size and pedal cadence. Actual speeds vary.
Try your current gearingChanged tires or gears? Calculate your setup.
Your changes apply to this calculation. The archived build stays unchanged.
Gearing results
| Measure | Original | Your setup |
|---|---|---|
| Lowest ratio | — | — |
| Highest ratio | — | — |
| Total range | — | — |
| Lowest-gear speed | — | — |
| Highest-gear speed | — | — |
Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.
Parts & serviceability
Find replacement parts
700 x 28c Vittoria Zaffiro
Retailer offers
Vittoria Zaffiro Pro V Clincher Tire Black, 700x28
700x28c
Model match
Other replacement options (4)
Vittoria Zaffiro Pro V Clincher Tire Tan/Black/Black, 700x28
700x28c
Model match
Vittoria Zaffiro V Wire Bead Tire Black, 700x28
700x28c
Model match
Vittoria Zaffiro Pro V Clincher Tire and Tubes Set Black, 700x28, 48mm Presta
700x28c, 48mm Presta
Model match
Specialized SW Mondo 2Bliss Tire Black, 700x28
700x28c
Replacement option
Vittoria Zaffiro on eBaySponsored links
FSA SL-K
Carbon, 27.2mm diameter
Retailer offers
Race Face Ride XC Seatpost Black, 27.2x375mm
Replacement option
Shimano 105
More parts (8)Fewer parts
FSA Mega EXO
WTB Silverado Race
FSA K-Force Carbon
30/39/50 teeth
Shimano Ultegra
FSA OS115
1 1/8" threadless FSA Orbit C
Mavic Aksium
Based on the original build. Check fit and installed parts before ordering. Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.
Parts and service referenceQuick reference before buying parts
Archived specifications for reference. Check the fitted parts before ordering.
- Front tire
- 700 x 28c Vittoria Zaffiro
- Drivetrain
- 10-speed
- Seatpost diameter
- 27.2 mm
- Bottom bracket / shell
- FSA Mega EXO
Equipment inspection checks 10 checks based on 5 archived component groups Open equipment checksClose equipment checks
Checks selected from the archived equipment. Confirm what is fitted today. This is not a complete safety inspection; use the full inspection guide before test riding.
Full used-bike inspection guide →
Frame and fork
Inspect the frame and fork →Archived: Frame: Bonded/monocoque · Fork: Carbon Monocoque Rigid · Carbon/aluminum steerer, aero crown
Drivetrain
Check drivetrain wear →Archived: Group: Road Mix · Shifters: Shimano SL-R770 · Front derailleur: Shimano R773 · Rear derailleur: Shimano Ultegra · Crankset: FSA K-Force Carbon, 30/39/50 teeth · Bottom bracket: FSA Mega EXO · Rear cogs: 10-speed, 12 - 27 teeth · Chain: Shimano 105
Brakes
Inspect the brakes →Archived: Brakes: Avid Single Digit 7 brakes, Shimano BL-M420 levers
Wheels and tires
Check wheels and tires →Archived: Wheel size: 700c wheels · Rims: Mavic Aksium, 20-hole/24-hole · Hubs: Mavic Aksium · Front tire: 700 x 28c Vittoria Zaffiro
Controls and contact points
Archived: Headset: 1 1/8" threadless FSA Orbit C · Handlebar: Carbon XC flat · Stem: FSA OS115 · Seatpost: FSA SL-K, Carbon, 27.2mm diameter · Saddle: WTB Silverado Race · Pedals: Not included
