Lowest0.69:1
Highest3.82:1
Total range555%
Estimated speed At 90 RPM
Lowest gear
Highest gear
Uses front tire 26×2.1; rear size isn’t listed.
Velopedia Bicycle Archive
2007 Marin Bobcat Trail
Original specifications: Shimano Deore · 8-speed · mechanical rear derailleur · 26" wheels.
Planning to sell? Draft your listing
At a glance
Archive #16350- Model year
- 2007
- Category
- Mountain
- Original MSRP
- $599.00
- Sizes
- 13", 15", 17", 19", 20.5", 22", women's 15", women's 17"
- Colors
- Matte Brushed Polish, Matte Bronze
- In this record
- 25 specifications · archived image · original MSRP
Model history 18 other years
Browse other years
Compare side by side
Identification clues
2007 archived details
- Published colors
- Matte Brushed Polish, Matte Bronze
- Frame
- Edge II 7005 Aluminum
- Original equipment
- Mountain Mix
Clues, not proof of model year. Colors vary and components may have been replaced.
Original buildEdge II 7005 Aluminum · Mountain Mix · 26" wheels
Frameset
| Frame Construction | TIG-welded |
|---|---|
| Frame Material | Edge II 7005 Aluminum |
| Fork | Rock Shox Dart 1, 100mm |
| Fork Material | Magnesium/steel/aluminum, single crown |
Drivetrain
| Component Group | Mountain Mix |
|---|---|
| Shifters | Shimano EF50 EZ-Fire |
| Front Derailleur | Shimano Acera |
| Rear Derailleur | Shimano Deore |
| Crankset | TruVativ X-Flow 3.0, 22/32/42 teeth |
| Bottom Bracket | TruVativ Sealed Cartridge |
| Rear Cogs | 8-speed, 11 - 32 teeth |
| Chain | Shimano HG40 |
| Pedals | Composite |
Brakes
| Brakes | Hayes MX-2 XC w/V6 Rotors brakes, Shimano levers |
|---|
Cockpit & Contact Points
| Headset | 1 1/8" threadless TH-888 |
|---|---|
| Handlebar | Double Butted 6061 Alloy riser |
| Handlebar Extensions | Not included |
| Stem | Forged Alloy |
| Saddle | WTB Speed V Sport SE |
| Seatpost | Alloy Micro Adjust, 27.2mm diameter |
Wheels & Tires
| Hubs | Alloy Double Sealed Disc QR |
|---|---|
| Rims | WTB DX23, 32-hole |
| Spokes | Stainless steel, 15ga. (1.8mm) straight gauge |
| Front Tire | 26 x 2.10" WTB MotoRaptor Comp |
| Wheel Size | 26" wheels |
No specifications match. Try a component name or clear your search.
Gearing
Lower gears help on climbs. Higher gears suit higher speeds.
RPM
RPM = pedal turns per minute.
How it works
Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.
Speeds are estimates from tire size and pedal cadence. Actual speeds vary.
Try your current gearingChanged tires or gears? Calculate your setup.
Your changes apply to this calculation. The archived build stays unchanged.
Gearing results
| Measure | Original | Your setup |
|---|---|---|
| Lowest ratio | — | — |
| Highest ratio | — | — |
| Total range | — | — |
| Lowest-gear speed | — | — |
| Highest-gear speed | — | — |
Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.
Parts & serviceability
Find replacement parts
Shimano HG40
Retailer offers
SRAM PC-830 Chain One Color, 8 Speed
Replacement option
Shimano CN-HG40 on eBaySponsored links
Alloy Micro Adjust
27.2mm diameter
Retailer offers
Race Face Ride XC Seatpost Black, 27.2x375mm
Replacement option
More parts (4)Fewer parts
WTB Speed V Sport SE
Shimano Acera
Shimano Deore
WTB DX23
32-hole
Based on the original build. Check fit and installed parts before ordering. Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.
Parts and service referenceQuick reference before buying parts
Archived specifications for reference. Check the fitted parts before ordering.
- Front tire
- 26 x 2.10" WTB MotoRaptor Comp
- Drivetrain
- 8-speed
- Seatpost diameter
- 27.2 mm
- Bottom bracket / shell
- TruVativ Sealed Cartridge
Equipment inspection checks 12 checks based on 6 archived component groups Open equipment checksClose equipment checks
Checks selected from the archived equipment. Confirm what is fitted today. This is not a complete safety inspection; use the full inspection guide before test riding.
Full used-bike inspection guide →
Frame and fork
Inspect the frame and fork →Archived: Frame: TIG-welded · Fork: Rock Shox Dart 1, 100mm · Magnesium/steel/aluminum, single crown
Suspension
Evaluate the suspension →Archived: Fork: Rock Shox Dart 1, 100mm
Drivetrain
Check drivetrain wear →Archived: Group: Mountain Mix · Shifters: Shimano EF50 EZ-Fire · Front derailleur: Shimano Acera · Rear derailleur: Shimano Deore · Crankset: TruVativ X-Flow 3.0, 22/32/42 teeth · Bottom bracket: TruVativ Sealed Cartridge · Rear cogs: 8-speed, 11 - 32 teeth · Chain: Shimano HG40
Brakes
Inspect the brakes →Archived: Brakes: Hayes MX-2 XC w/V6 Rotors brakes, Shimano levers
Wheels and tires
Check wheels and tires →Archived: Wheel size: 26" wheels · Rims: WTB DX23, 32-hole · Hubs: Alloy Double Sealed Disc QR · Front tire: 26 x 2.10" WTB MotoRaptor Comp
Controls and contact points
Archived: Headset: 1 1/8" threadless TH-888 · Handlebar: Double Butted 6061 Alloy riser · Stem: Forged Alloy · Seatpost: Alloy Micro Adjust, 27.2mm diameter · Saddle: WTB Speed V Sport SE · Pedals: Composite
