Velopedia Bicycle Archive

2021 Liv Avow Advanced

Original specifications: geometry for 3 published sizes.

Share owner experience

Planning to sell? Draft your listing

At a glance

Archive #900002254
Model year
2021
Category
Road
Original MSRP
$2,680.00
Sizes
XS, S, M
Colors
Rainbow White / Chrome
Geometry
3 manufacturer sizes
In this record
21 specifications · archived image · original MSRP · geometry
Model history 5 other years

Browse other years

Compare side by side

Identification clues

2021 archived details

Published colors
Rainbow White / Chrome
Frame
Carbon Fiber

Clues, not proof of model year. Colors vary and components may have been replaced.

Sponsored affiliate link
Original buildCarbon Fiber

Manufacturer catalog

Published sizes and colors

3 sizes · 1 color

Manufacturer-published sizes and colors; availability and exact size/color pairings may vary by market or production run.

Published sizes

XSSM

Published colors

Rainbow White / Chrome

Frameset

Frame ConstructionAdvanced-Grade Composite
Frame MaterialCarbon Fiber
ForkAdvanced-Grade Composite, alloy OverDrive steerer
Fork MaterialCarbon Fiber

Drivetrain

ShiftersShimano TT SL-BSR1
Front DerailleurShimano 105
Rear DerailleurShimano 105
CranksetFSA Trimax alloy, 34/50
Bottom BracketFSA, press fit
CassetteShimano 105, 11x28
ChainKMC X11EL-1

Brakes

Brakes[F] TKB84 [R]TBK88

Cockpit & Contact Points

HandlebarLiv Avow, alloy base bar
StemGiant Contact
SaddleISM PS1.0, steel rail
SeatpostAvow, composite

Wheels & Tires

HubsGiant S-R2 wheelset
RimsGiant S-R2 wheelset
SpokesGiant S-R2 wheelset
Front TireGiant AC 1, 700x25c, tubeless
Rear TireGiant AC 1, 700x25c, tubeless

Geometry

3 sizes · 17 measurements

Frame measurements by size.

All geometry measurements3 sizes · 17 measurements
MeasurementXSSM
Seat tube480 mm510 mm530 mm
Top tube500 mm515 mm540 mm
Head tube80 mm95 mm125 mm
Head-tube angle72°72.5°72.5°
Seat-tube angle77°77°77°
Chainstay / rear center405 mm405 mm405 mm
Wheelbase961 mm974 mm1001 mm
Bottom-bracket drop75 mm75 mm75 mm
Reach387 mm398 mm417 mm
Stack490 mm504 mm534 mm
Standover height740 mm767 mm788 mm
Fork offset / rake40 mm40 mm40 mm
Trail68 mm64 mm64 mm
Crank length165 mm165 mm165 mm
Stem length80 mm80 mm80 mm
Handlebar width400 mm400 mm400 mm
Wheel size700C700C700C

Dimensions as recorded.

Gearing

Lower gears help on climbs. Higher gears suit higher speeds.

RPM

RPM = pedal turns per minute.

All published sizes50/34T · 11–28T
Lowest1.21:1 Highest4.55:1 Total range374%
Estimated speed At 90 RPM Lowest gear8.6 mph Highest gear32.2 mph

Rear tire: 700C×25.

How it works

Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.

Speeds are estimates from tire size and pedal cadence. Actual speeds vary.

Try other gearing

Try your current gearingChanged tires or gears? Calculate your setup.

Your changes apply to this calculation. The archived build stays unchanged.

Your gearing setup
Gears

Use up to three front tooth counts, separated by /. For one rear sprocket, enter the same count twice.

Rear tire

Apply the marking on your rear tire or edit its dimensions below. Older or fractional inch sizes need the ISO marking (e.g. 37-590).

For 32-622, width is 32 mm and rim diameter is 622 mm. Use the rear tire on mixed-wheel bikes. Leave both fields empty to compare ratios only.

Gear, dimension and cadence changes update results automatically.

Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.

Parts & serviceability

Find replacement parts

Original specifications

Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.

Front tire · Original
Giant AC 1

700x25c, tubeless

Before ordering: Check rim compatibility and tire clearance.
Retailer offers
Cassette · Original
Shimano 105

11x28

Crankset · Original
FSA Trimax alloy, 34/50
165 mm Frame sizes XS / S / M
More parts (3)Fewer parts
Front derailleur · Original
Shimano 105 Before ordering: Confirm whether the drivetrain is mechanical or electronic before ordering.
Rear derailleur · Original
Shimano 105 Before ordering: Confirm whether the drivetrain is mechanical or electronic before ordering.
Shifters · Original
Shimano TT SL-BSR1

Based on the original build. Check fit and installed parts before ordering.

Parts and service referenceQuick reference before buying parts

Archived specifications for reference. Check the fitted parts before ordering.

Front tire
Giant AC 1, 700x25c, tubeless
Rear tire
Giant AC 1, 700x25c, tubeless
Bottom bracket / shell
FSA, press fit
Equipment inspection checks 11 checks based on 5 archived component groups Open equipment checksClose equipment checks
0 of 11 checked Progress stays in this browser for this record.

Checks selected from the archived equipment. Confirm what is fitted today. This is not a complete safety inspection; use the full inspection guide before test riding.

Full used-bike inspection guide →

Archived: Frame: Advanced-Grade Composite · Fork: Advanced-Grade Composite, alloy OverDrive steerer · Carbon Fiber

Archived: Shifters: Shimano TT SL-BSR1 · Front derailleur: Shimano 105 · Rear derailleur: Shimano 105 · Crankset: FSA Trimax alloy, 34/50 · Bottom bracket: FSA, press fit · Cassette: Shimano 105, 11x28 · Chain: KMC X11EL-1

Archived: Brakes: [F] TKB84 [R]TBK88

Archived: Rims: Giant S-R2 wheelset · Hubs: Giant S-R2 wheelset · Front tire: Giant AC 1, 700x25c, tubeless · Rear tire: Giant AC 1, 700x25c, tubeless

Controls and contact points

Archived: Handlebar: Liv Avow, alloy base bar · Stem: Giant Contact · Seatpost: Avow, composite · Saddle: ISM PS1.0, steel rail
