Velopedia Bicycle Archive
2002 Lightning R-84
Original specifications: Campagnolo Racing Triple drivetrain · Front: 20", Rear: 700c wheels · 20 lb published weight.
Planning to sell? Draft your listing
No archive photo is available for this record.
At a glance
Archive #37699- Model year
- 2002
- Category
- Recumbent
- Original MSRP
- $5,200.00
- Sizes
- M, L, XL
- Colors
- Clear coated natural carbon
- Weight
- 20 lb
- In this record
- 27 specifications · original MSRP
Model history 9 other years
Browse other years
Compare side by side
Identification clues
2002 archived details
- Published colors
- Clear coated natural carbon
- Frame
- Carbon fiber composite
- Original equipment
- Campagnolo Racing Triple
Clues, not proof of model year. Colors vary and components may have been replaced.
Original buildCarbon fiber composite · Campagnolo Racing Triple · Front: 20", Rear: 700c wheels
Frameset
| Frame Construction | Monocoque |
|---|---|
| Frame Material | Carbon fiber composite |
| Fork | Lightning S-2, 1.6" travel |
| Fork Material | 4130 chromoly, unicrown crown |
| Rear Shock | Lightning Swing-Stay, 1.0" travel |
Drivetrain
| Component Group | Campagnolo Racing Triple |
|---|---|
| Shifters | Campagnolo Centaur Ergo |
| Front Derailleur | Campagnolo Racing Triple, bottom-pull/braze-on |
| Rear Derailleur | Campagnolo Racing Triple |
| Crankset | Campagnolo Centaur Triple, 30/42/52 teeth |
| Bottom Bracket | Campagnolo AC-H, 118mm spindle |
| BB Shell Width | 68mm English |
| Rear Cogs | 9-speed, 11 - 26 teeth |
| Chain | Campagnolo Record, 1/2 x 3/32" |
| Pedals | Not included |
Brakes
| Brakes | Campagnolo Centaur dual pivot brakes, Dia-Compe levers |
|---|
Cockpit & Contact Points
| Headset | 1 1/4" Shimano Deore XT |
|---|---|
| Handlebar | Lightning Drop |
| Stem | Aluminum |
| Saddle | Lightning Ergofit, Aluminum frame |
Wheels & Tires
| Hubs | Campagnolo Centaur |
|---|---|
| Rims | Front: Sun Rims ME14A, Rear: Campagnolo Vento |
| Spokes | Campagnolo stainless steel, bladed |
| Spoke Nipples | Brass nipples |
| Front Tire | 20 x 1.00" Continental Grand Prix |
| Rear Tire | 700 x 25c Continental Grand Prix |
| Wheel Size | Front: 20", Rear: 700c wheels |
No specifications match. Try a component name or clear your search.
Gearing
Lower gears help on climbs. Higher gears suit higher speeds.
RPM = pedal turns per minute.
How it works
Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.
Speeds are estimates from tire size and pedal cadence. Actual speeds vary.
Try your current gearingChanged tires or gears? Calculate your setup.
Your changes apply to this calculation. The archived build stays unchanged.
Gearing results
| Measure | Original | Your setup |
|---|---|---|
| Lowest ratio | — | — |
| Highest ratio | — | — |
| Total range | — | — |
| Lowest-gear speed | — | — |
| Highest-gear speed | — | — |
Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.
Parts & serviceability
Find replacement parts
Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.
118mm spindle
More parts (4)Fewer parts
30/42/52 teeth
Based on the original build. Check fit and installed parts before ordering.
Parts and service referenceQuick reference before buying parts
Archived specifications for reference. Check the fitted parts before ordering.
- Front tire
- Front: 20 x 1.00" Continental Grand Prix, Rear: 700 x 25c Continental Grand Prix
- Drivetrain
- 9-speed
- Bottom bracket / shell
- Campagnolo AC-H, 118mm spindle · 68mm English
Equipment inspection checks 13 checks based on 6 archived component groups Open equipment checksClose equipment checks
Checks selected from the archived equipment. Confirm what is fitted today. This is not a complete safety inspection; use the full inspection guide before test riding.
Full used-bike inspection guide →
Frame and fork
Inspect the frame and fork →Archived: Frame: Monocoque · Fork: Lightning S-2, 1.6" travel · 4130 chromoly, unicrown crown
Suspension
Evaluate the suspension →Archived: Fork: Lightning S-2, 1.6" travel · Rear shock: Lightning Swing-Stay, 1.0" travel
Drivetrain
Check drivetrain wear →Archived: Group: Campagnolo Racing Triple · Shifters: Campagnolo Centaur Ergo · Front derailleur: Campagnolo Racing Triple, bottom-pull/braze-on · Rear derailleur: Campagnolo Racing Triple · Crankset: Campagnolo Centaur Triple, 30/42/52 teeth · Bottom bracket: Campagnolo AC-H, 118mm spindle · Rear cogs: 9-speed, 11 - 26 teeth · Chain: Campagnolo Record, 1/2 x 3/32"
Brakes
Inspect the brakes →Archived: Brakes: Campagnolo Centaur dual pivot brakes, Dia-Compe levers
Wheels and tires
Check wheels and tires →Archived: Wheel size: Front: 20", Rear: 700c wheels · Rims: Front: Sun Rims ME14A, Rear: Campagnolo Vento · Hubs: Campagnolo Centaur · Front tire: Front: 20 x 1.00" Continental Grand Prix, Rear: 700 x 25c Continental Grand Prix
Controls and contact points
Archived: Headset: 1 1/4" Shimano Deore XT · Handlebar: Lightning Drop · Stem: Aluminum · Saddle: Lightning Ergofit, Aluminum frame · Pedals: Not included
Have you owned this model?Help document firsthand fit, ride and maintenance details that may no longer be available.
This archive record has limited published detail. Share what would help another rider understand how this model fit, rode and held up over time. Velopedia reviews every contribution before publication.
Already contributed? Send me a fresh private edit link
For privacy, Velopedia shows the same confirmation whether or not an experience exists.
No recent price sample is available for this bike. Check eBay for matching listings.
Find this bike on eBay
Search eBay US; check the model year, size and installed components. We may earn a commission from purchases.
Specifications are presented as a reference. Components may vary by market, size, production run, or later manufacturer revisions.
