Velopedia Bicycle Archive
2002 Lightning Phantom II FS
Recumbent bicycle from the Velopedia specification archive.
- Original MSRP
- $1,995.00
- Sizes
- Large, small
- Colors
- Black, Metallic Green, Metallic Mango, Red
- Weight
- 28
- Archive ID
- 37708
Image not yet recovered
Current market
Checking current listings…Frameset
| Frame Construction | TIG-welded |
|---|---|
| Frame Material | 4130 Chromoly w/ Aluminum BB extension |
| Fork | Ballistic 600 A II, 2.5" travel |
| Fork Material | Aluminum, triple-clamp crown |
| Rear Shock | N/A |
Drivetrain
| Component Group | Recumbent Mix |
|---|---|
| Shifters | Shimano Dura-Ace bar-end |
| Front Derailleur | Shimano 105, bottom-pull/clamp-on 28.6mm |
| Rear Derailleur | Shimano Deore LX SGS |
| Crankset | Shimano 105, 30/42/52 teeth |
| Bottom Bracket | Shimano BB-5500, 118mm spindle |
| BB Shell Width | 68mm English |
| Rear Cogs | 9-speed, 11 - 32 teeth |
| Chain | KMC Z9200, 1/2 x 3/32" |
| Pedals | Not included |
Brakes
| Brakes | Odyssey A-brake brakes, Tektro RBP-379A levers |
|---|
Cockpit & Contact Points
| Headset | 1" Dia-Tech SBN |
|---|---|
| Handlebar | Lightning Drop |
| Handlebar Extensions | N/A |
| Stem | Aluminum |
| Saddle | Lightning Ergofit, Aluminum frame |
| Seatpost | N/A |
Wheels & Tires
| Hubs | Shimano Deore LX |
|---|---|
| Rims | Aluminum, 36-hole |
| Spokes | Sapim stainless steel, 14ga. (2.0mm) straight gauge |
| Spoke Nipples | Brass nipples |
| Front Tire | Front: 20 x 1.25" City Jet, Rear: 26 x 1.25" Primo HP |
| Wheel Size | Front: 20", Rear: 26" wheels |
Specifications are presented as a reference. Components may vary by market, size, production run, or later manufacturer revisions.
