Velopedia Bicycle Archive
2025 Kona Rove LTD
Cyclocross/Gravel bicycle from the Velopedia specification archive.
Selling this bike? Create a Bike History Report
What Velopedia knows
- Model year
- 2025
- Category
- Gravel & Cyclocross
- Original MSRP
- $2,899.00
- Sizes
- 48, 50, 52, 54, 56, 58
- Colors
- Gloss Metallic Gentian Blue w/ Dark Orchid Decals
- Geometry
- 6 manufacturer sizes · Geometry context
- Record coverage
- 23 preserved details · 8 archived images · original MSRP · preserved geometry
- Archive ID
- 900000989
Frameset
| Frame Construction | Kona Butted Cromoly |
|---|---|
| Fork | Kona Libre Full Carbon Flat Mount Disc |
| Fork Material | Carbon Fiber |
| Rear Shock | n/a |
Drivetrain
| Shifters | Shimano GRX |
|---|---|
| Front Derailleur | Shimano GRX2x (46/30t) |
| Rear Derailleur | Shimano GRX 12spd |
| Crankset | Shimano GRX; Chainring: 46x30t Deore |
| Bottom Bracket | Shimano Deore 68mm |
| Cassette | Shimano 105 11-36t 12spd |
| Chain | KMC X12 12spd |
| Pedals | n/a |
Brakes
| Brakes | Brake Calipers: Shimano GRX; Front Brake Rotor: Shimano CL 160mm; Rear Brake Rotor: Shimano CL 160mm; Brake Levers: Shimano |
|---|
Cockpit & Contact Points
| Headset | FSA No.1/12B/44 |
|---|---|
| Handlebar | Kona Gravel Drop Bar |
| Stem | Kona Gravel Deluxe |
| Saddle | WTB Volt |
| Seatpost | Kona Deluxe Thumb w/Offset 27.2mm |
Wheels & Tires
| Hubs | (F) Formula 100x12mm / (R) Formula 142x12mm |
|---|---|
| Rims | WTB KOM Team i23 TCS |
| Spokes | Stainless Black 14g |
| Front Tire | Maxxis Rambler EXO TR 700x40c |
| Rear Tire | Maxxis Rambler EXO TR 700x40c |
Size-specific frame data
Geometry
Manufacturer-published geometry normalized for consistent archival comparison. Effective top tube and reach remain separate measurements because they describe different aspects of fit.
| Measurement | 48 | 50 | 52 | 54 | 56 | 58 |
|---|---|---|---|---|---|---|
| Seat tube | 480 mm | 500 mm | 520 mm | 540 mm | 560 mm | 580 mm |
| Top tube | 515 mm | 531 mm | 546 mm | 562 mm | 578 mm | 598 mm |
| Head tube | 90 mm | 110 mm | 130 mm | 150 mm | 170 mm | 190 mm |
| Head-tube angle | 70.5° | 70.5° | 71° | 71° | 71.5° | 71.5° |
| Seat-tube angle | 75° | 74.5° | 74° | 73.5° | 73° | 72.5° |
| Chainstay / rear center | 435 mm | 435 mm | 435 mm | 435 mm | 435 mm | 435 mm |
| Wheelbase | 1016 mm | 1029 mm | 1036 mm | 1048 mm | 1054 mm | 1068 mm |
| Bottom-bracket drop | 74 mm | 74 mm | 72 mm | 72 mm | 70 mm | 70 mm |
| Bottom-bracket height | 282 mm | 282 mm | 284 mm | 284 mm | 286 mm | 286 mm |
| Reach | 372 mm | 378 mm | 383 mm | 388 mm | 392 mm | 400 mm |
| Stack | 532 mm | 551 mm | 570 mm | 588 mm | 607 mm | 626 mm |
| Standover height | 749 mm | 767 mm | 789 mm | 807 mm | 828 mm | 847 mm |
| Fork offset / rake | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm |
| Front center | 592 mm | 604 mm | 612 mm | 623 mm | 628 mm | 643 mm |
| Fork length / axle-to-crown | 410 mm | 410 mm | 410 mm | 410 mm | 410 mm | 410 mm |
Geometry source: Manufacturer HTML geometry table ↗ Measurements can vary by configuration, wheel size, or flip-chip position where noted by the manufacturer.
Geometry tools
Analyze a published size
48 geometry
Archive context: The seat angle of 75° sits toward the steeper end. Its stack of 532 mm sits toward the lower end. Its wheelbase of 1016 mm sits somewhat shorter than typical.
Compared with 87 distinct cyclocross/gravel geometries in the Small-equivalent size cohort from model years 2023–2027 in the Velopedia archive.Want to go deeper?Open this exact published size and configuration in the Velopedia Geometry Analyzer, then complete any measurements the manufacturer did not provide.
Analyze 48 geometry 50 geometry
Archive context: The chainstay of 435 mm sits somewhat longer than typical. Its bottom-bracket drop of 74 mm sits somewhat shallower than typical. The seat angle of 74.5° sits close to the middle of the group.
Compared with 87 distinct cyclocross/gravel geometries in the Small-equivalent size cohort from model years 2023–2027 in the Velopedia archive.Want to go deeper?Open this exact published size and configuration in the Velopedia Geometry Analyzer, then complete any measurements the manufacturer did not provide.
Analyze 50 geometry 52 geometry
Archive context: Its stack of 570 mm sits somewhat lower than typical. The chainstay of 435 mm sits somewhat longer than typical. Its bottom-bracket drop of 72 mm sits somewhat shallower than typical.
Compared with 98 distinct cyclocross/gravel geometries in the Medium-equivalent size cohort from model years 2023–2027 in the Velopedia archive.Want to go deeper?Open this exact published size and configuration in the Velopedia Geometry Analyzer, then complete any measurements the manufacturer did not provide.
Analyze 52 geometry 54 geometry
Archive context: The chainstay of 435 mm sits somewhat longer than typical. Its bottom-bracket drop of 72 mm sits somewhat shallower than typical. The seat angle of 73.5° sits somewhat more relaxed than typical.
Compared with 98 distinct cyclocross/gravel geometries in the Medium-equivalent size cohort from model years 2023–2027 in the Velopedia archive.Want to go deeper?Open this exact published size and configuration in the Velopedia Geometry Analyzer, then complete any measurements the manufacturer did not provide.
Analyze 54 geometry 56 geometry
Archive context: Its bottom-bracket drop of 70 mm sits somewhat shallower than typical. The seat angle of 73° sits somewhat more relaxed than typical. The chainstay of 435 mm sits somewhat longer than typical.
Compared with 69 distinct cyclocross/gravel geometries in the Large-equivalent size cohort from model years 2023–2027 in the Velopedia archive.Want to go deeper?Open this exact published size and configuration in the Velopedia Geometry Analyzer, then complete any measurements the manufacturer did not provide.
Analyze 56 geometry 58 geometry
Archive context: The seat angle of 72.5° sits toward the more relaxed end. Its reach of 400 mm sits somewhat shorter than typical. Its bottom-bracket drop of 70 mm sits somewhat shallower than typical.
Compared with 74 distinct cyclocross/gravel geometries in the XL-equivalent size cohort from model years 2023–2027 in the Velopedia archive.Want to go deeper?Open this exact published size and configuration in the Velopedia Geometry Analyzer, then complete any measurements the manufacturer did not provide.
Analyze 58 geometry Parts & serviceability
Find replacement parts
ChainKMC X12 12spdExact archived model
CassetteShimano 105 11-36t 12spdComponent family — verify exact version
Front tireMaxxis Rambler EXO TR 700x40cNamed tire and published size
More qualified parts (6)
Bottom bracketShimano Deore 68mmNamed archived component — verify dimensions
SaddleWTB VoltNamed archived component — verify exact version
Rear derailleurShimano GRX 12spdComponent family — verify exact version
ShiftersShimano GRXNamed component · published drivetrain speed — verify exact version
HeadsetFSA No.1/12B/44Named archived component — verify dimensions
RimsWTB KOM Team i23 TCSNamed archived component — verify dimensions
Searches use the archived manufacturer specification, not the components currently installed on a particular bicycle. Confirm the exact model, size and fit before ordering. As an Amazon Associate I earn from qualifying purchases. Velopedia may also earn from qualifying eBay purchases. Velopedia may also earn from qualifying retailer purchases. Commercial relationships do not influence Archive specifications or analysis.
Used-bike inspection
If you’re buying this bike used
Before any test ride: both brakes should stop the bike firmly and release cleanly; both wheels should run true and be securely attached; tires should have no casing damage; and the headset, handlebar, stem, cranks and pedals should have no looseness or play.
Follow the full used-bike inspection order →- FrameInspect the complete frame and fork in bright light for cracks, dents, distortion, corrosion, impact marks, suspicious paint differences or signs of repair. Check the head tube, bottom-bracket area, dropouts, joints and clamped surfaces especially closely.Inspect the frame and fork →
- BrakesTest each brake separately and confirm it stops firmly and releases cleanly. Inspect the pads and braking surfaces for wear or contamination, and check the cables or hoses for damage.Inspect the brakes →
- DrivetrainShift through every gear under light load and measure chain wear. Confirm that the shifter, derailleur, chain and cassette belong to the same 12-speed system.Check drivetrain wear →
- Wheels & tiresSpin both wheels and watch the rims for side-to-side or vertical movement. Check for dents, cracks, loose or uneven spokes and hub play, then inspect both tire casings for cuts, cracking or exposed threads.Check wheels and tires →
Bike-specific inspection checklist 19 checks based on 5 archived component groups Open checklistClose checklist
This checklist uses the archived equipment for this bike. It cannot confirm the condition, service history or later component changes of the example in front of you.
Identity and fit
Follow the full used-bike inspection order →Archived: 2025 Kona Rove LTD · Cyclocross/Gravel · Published sizes: 48, 50, 52, 54, 56, 58
Frame and fork
Inspect the frame and fork →Archived: Frame: Kona Butted Cromoly · Fork: Kona Libre Full Carbon Flat Mount Disc · Carbon Fiber
Drivetrain
Check drivetrain wear →Archived: Shifters: Shimano GRX · Front derailleur: Shimano GRX2x (46/30t) · Rear derailleur: Shimano GRX 12spd · Crankset: Shimano GRX; Chainring: 46x30t Deore · Bottom bracket: Shimano Deore 68mm · Cassette: Shimano 105 11-36t 12spd · Chain: KMC X12 12spd
Brakes
Inspect the brakes →Archived: Brakes: Brake Calipers: Shimano GRX; Front Brake Rotor: Shimano CL 160mm; Rear Brake Rotor: Shimano CL 160mm; Brake Levers: Shimano
Wheels and tires
Check wheels and tires →Archived: Rims: WTB KOM Team i23 TCS · Hubs: (F) Formula 100x12mm / (R) Formula 142x12mm · Front tire: Maxxis Rambler EXO TR 700x40c · Rear tire: Maxxis Rambler EXO TR 700x40c
Controls and contact points
Archived: Headset: FSA No.1/12B/44 · Handlebar: Kona Gravel Drop Bar · Stem: Kona Gravel Deluxe · Seatpost: Kona Deluxe Thumb w/Offset 27.2mm · Saddle: WTB Volt
Before and during the test ride
Follow the full used-bike inspection order →Build relationships are limited to the archived manufacturer specifications. Confirm exact fit and standards before ordering parts or performing service.
