2025 Kona Honzo ESD
Mountain bicycle from the Velopedia specification archive.
Selling this bike? Create a Bike History Report
What Velopedia knows
- Model year
- 2025
- Category
- Mountain
- Original MSRP
- $2,399.00
- Sizes
- S, M, L, XL
- Colors
- Silver
- Geometry
- 4 manufacturer sizes · Geometry context
- Record coverage
- 23 preserved details · 8 archived images · original MSRP · preserved geometry
- Archive ID
- 900001153
Frameset
| Frame Construction | Kona Cromoly Butted |
|---|---|
| Fork | Marzocchi Bomber Z1 Grip Damper 150mm Tapered 110mm Spacing |
| Rear Shock | n/a |
Drivetrain
| Shifters | SRAM GX Eagle |
|---|---|
| Front Derailleur | n/a |
| Rear Derailleur | SRAM GX Eagle |
| Crankset | SRAM GX Eagle; Chainring: 30t X-Sync Eagle |
| Bottom Bracket | SRAM DUB 73mm |
| Cassette | SRAM GX 10-52t 12spd |
| Chain | SRAM NX Eagle |
| Pedals | n/a |
Brakes
| Brakes | Brake Calipers: SRAM DB8; Front Brake Rotor: SRAM Centerline 200mm; Rear Brake Rotor: SRAM Centerline 200mm; Brake Levers: SRAM DB8 |
|---|
Cockpit & Contact Points
| Headset | FSA Orbit 1.5 E ZS |
|---|---|
| Handlebar | Race Face Aeffect R 35 |
| Stem | Race Face Aeffect R 35 |
| Saddle | WTB Volt |
| Seatpost | TranzX Dropper +RAD Internal 31.6mm |
Wheels & Tires
| Hubs | (F) Race Face AR 30 110x15mm / (R) Race Face AR 30 148x12mm |
|---|---|
| Rims | Race Face AR 30 |
| Spokes | Stainless Black 14g |
| Front Tire | Maxxis Assegai EXO TR 3C 29x2.5" WT |
| Rear Tire | Maxxis Minion DHR II EXO TR 3C 29x2.4" WT |
| Wheel Size | 29" |
Size-specific frame data
Geometry
Manufacturer-published geometry normalized for consistent archival comparison. Effective top tube and reach remain separate measurements because they describe different aspects of fit.
| Measurement | S | M | L | XL |
|---|---|---|---|---|
| Seat tube | 380 mm | 380 mm | 420 mm | 450 mm |
| Top tube | 578 mm | 605 mm | 633 mm | 670 mm |
| Head tube | 90 mm | 100 mm | 110 mm | 120 mm |
| Head-tube angle | 63° | 63° | 63° | 63° |
| Seat-tube angle | 77.5° | 77.5° | 77.5° | 77.5° |
| Chainstay / rear center | 417 mm | 417 mm | 417 mm | 417 mm |
| Wheelbase | 1186 mm | 1216 mm | 1245 mm | 1285 mm |
| Bottom-bracket drop | 62.5 mm | 62.5 mm | 62.5 mm | 62.5 mm |
| Bottom-bracket height | 312.5 mm | 312.5 mm | 312.5 mm | 312.5 mm |
| Reach | 440 mm | 465 mm | 490 mm | 525 mm |
| Stack | 625 mm | 634 mm | 643 mm | 652 mm |
| Standover height | 712 mm | 710 mm | 709 mm | 706 mm |
| Fork offset / rake | 42 mm | 42 mm | 42 mm | 42 mm |
| Front center | 776 mm | 806 mm | 835 mm | 875 mm |
| Fork length / axle-to-crown | 560 mm | 560 mm | 560 mm | 560 mm |
Geometry source: Manufacturer HTML geometry table ↗ Measurements can vary by configuration, wheel size, or flip-chip position where noted by the manufacturer.
Geometry tools
Analyze a published size
S geometry
Archive context: The chainstay of 417 mm sits toward the shorter rear-center end. The head angle of 63° sits toward the slacker end. Its bottom-bracket drop of 62.5 mm sits toward the deeper-drop end.
Compared with 180 distinct mountain geometries in the Small-equivalent size cohort from model years 2023–2027 in the Velopedia archive.Want to go deeper?Open this exact published size and configuration in the Velopedia Geometry Analyzer, then complete any measurements the manufacturer did not provide.
Analyze S geometry M geometry
Archive context: The chainstay of 417 mm sits toward the shorter rear-center end. Its bottom-bracket drop of 62.5 mm sits toward the deeper-drop end. The head angle of 63° sits toward the slacker end.
Compared with 186 distinct mountain geometries in the Medium-equivalent size cohort from model years 2023–2027 in the Velopedia archive.Want to go deeper?Open this exact published size and configuration in the Velopedia Geometry Analyzer, then complete any measurements the manufacturer did not provide.
Analyze M geometry L geometry
Archive context: The chainstay of 417 mm sits toward the shorter rear-center end. Its bottom-bracket drop of 62.5 mm sits toward the deeper-drop end. The head angle of 63° sits toward the slacker end.
Compared with 179 distinct mountain geometries in the Large-equivalent size cohort from model years 2023–2027 in the Velopedia archive.Want to go deeper?Open this exact published size and configuration in the Velopedia Geometry Analyzer, then complete any measurements the manufacturer did not provide.
Analyze L geometry XL geometry
Archive context: The chainstay of 417 mm sits toward the shorter rear-center end. Its reach of 525 mm sits toward the longer end. Its bottom-bracket drop of 62.5 mm sits toward the deeper-drop end.
Compared with 158 distinct mountain geometries in the XL-equivalent size cohort from model years 2023–2027 in the Velopedia archive.Want to go deeper?Open this exact published size and configuration in the Velopedia Geometry Analyzer, then complete any measurements the manufacturer did not provide.
Analyze XL geometry Parts & serviceability
Find replacement parts
CassetteSRAM GX 10-52t 12spdComponent family — verify exact version
Front tireMaxxis Assegai EXO TR 3C 29x2.5" WTNamed tire and published size
Rear tireMaxxis Minion DHR II EXO TR 3C 29x2.4" WTNamed tire and published size
More qualified parts (6)
Bottom bracketSRAM DUB 73mmNamed archived component — verify dimensions
SaddleWTB VoltNamed archived component — verify exact version
Rear derailleurSRAM GX EagleNamed component · published drivetrain speed — verify exact version
ShiftersSRAM GX EagleNamed component · published drivetrain speed — verify exact version
HandlebarRace Face Aeffect R 35Named archived component — verify dimensions
StemRace Face Aeffect R 35Named archived component — verify dimensions
Searches use the archived manufacturer specification, not the components currently installed on a particular bicycle. Confirm the exact model, size and fit before ordering. As an Amazon Associate I earn from qualifying purchases. Velopedia may also earn from qualifying eBay purchases. Velopedia may also earn from qualifying retailer purchases. Commercial relationships do not influence Archive specifications or analysis.
Used-bike inspection
If you’re buying this bike used
Before any test ride: both brakes should stop the bike firmly and release cleanly; both wheels should run true and be securely attached; tires should have no casing damage; and the headset, handlebar, stem, cranks and pedals should have no looseness or play.
Follow the full used-bike inspection order →- FrameInspect the complete frame and fork in bright light for cracks, dents, distortion, corrosion, impact marks, suspicious paint differences or signs of repair. Check the head tube, bottom-bracket area, dropouts, joints and clamped surfaces especially closely.Inspect the frame and fork →
- BrakesTest each brake separately and confirm it stops firmly and releases cleanly. Inspect the pads and braking surfaces for wear or contamination, and check the cables or hoses for damage.Inspect the brakes →
- SuspensionAsk when the fork was last serviced. Check the stanchions for damage, look for oil at the seals and make sure the fork moves smoothly without bushing play.Evaluate the suspension →
- DrivetrainShift through every gear under light load and measure chain wear. Confirm that the shifter, derailleur, chain and cassette belong to the same 12-speed system.Check drivetrain wear →
- Wheels & tiresSpin both wheels and watch the rims for side-to-side or vertical movement. Check for dents, cracks, loose or uneven spokes and hub play, then inspect both tire casings for cuts, cracking or exposed threads.Check wheels and tires →
Bike-specific inspection checklist 20 checks based on 6 archived component groups Open checklistClose checklist
This checklist uses the archived equipment for this bike. It cannot confirm the condition, service history or later component changes of the example in front of you.
Identity and fit
Follow the full used-bike inspection order →Archived: 2025 Kona Honzo ESD · Mountain · Published sizes: S, M, L, XL
Frame and fork
Inspect the frame and fork →Archived: Frame: Kona Cromoly Butted · Fork: Marzocchi Bomber Z1 Grip Damper 150mm Tapered 110mm Spacing
Suspension
Evaluate the suspension →Archived: Fork: Marzocchi Bomber Z1 Grip Damper 150mm Tapered 110mm Spacing
Drivetrain
Check drivetrain wear →Archived: Shifters: SRAM GX Eagle · Rear derailleur: SRAM GX Eagle · Crankset: SRAM GX Eagle; Chainring: 30t X-Sync Eagle · Bottom bracket: SRAM DUB 73mm · Cassette: SRAM GX 10-52t 12spd · Chain: SRAM NX Eagle
Brakes
Inspect the brakes →Archived: Brakes: Brake Calipers: SRAM DB8; Front Brake Rotor: SRAM Centerline 200mm; Rear Brake Rotor: SRAM Centerline 200mm; Brake Levers: SRAM DB8
Wheels and tires
Check wheels and tires →Archived: Wheel size: 29" · Rims: Race Face AR 30 · Hubs: (F) Race Face AR 30 110x15mm / (R) Race Face AR 30 148x12mm · Front tire: Maxxis Assegai EXO TR 3C 29x2.5" WT · Rear tire: Maxxis Minion DHR II EXO TR 3C 29x2.4" WT
Controls and contact points
Archived: Headset: FSA Orbit 1.5 E ZS · Handlebar: Race Face Aeffect R 35 · Stem: Race Face Aeffect R 35 · Seatpost: TranzX Dropper +RAD Internal 31.6mm · Saddle: WTB Volt
