Lowest1.36:1
Highest4.17:1
Total range306%
Estimated speed At 90 RPM
Lowest gear
Highest gear
Uses front tire 700C×23; rear size isn’t listed.
Velopedia Bicycle Archive
2009 Kona Zing Deluxe
Original specifications: Shimano 105 drivetrain · 700c wheels.
Planning to sell? Draft your listing
At a glance
Archive #16998- Model year
- 2009
- Category
- Road
- Original MSRP
- $2,299.00
- Sizes
- 49cm, 53cm, 56cm, 59cm, 61cm
- Colors
- Metallic Green
- In this record
- 25 specifications · archived image · original MSRP
Model history 6 other years
Browse other years
Compare side by side
Identification clues
2009 archived details
- Published colors
- Metallic Green
- Frame
- Dedacciai Nero Corsa Carbon
- Original equipment
- Shimano 105
Clues, not proof of model year. Colors vary and components may have been replaced.
Original buildDedacciai Nero Corsa Carbon · Shimano 105 · 700c wheels
Frameset
| Frame Construction | Monocoque |
|---|---|
| Frame Material | Dedacciai Nero Corsa Carbon |
| Fork | Dedacciai Fin Carbon |
| Fork Material | Carbon, aero crown |
Drivetrain
| Component Group | Shimano 105 |
|---|---|
| Shifters | Shimano 105 STI |
| Front Derailleur | Shimano 105 |
| Rear Derailleur | Shimano Ultegra |
| Crankset | FSA Gossamer Compact, 34/50 teeth |
| Bottom Bracket | FSA BB30 |
| BB Shell Width | 68mm |
| Cassette | Shimano 105 |
| Rear Cogs | 10-speed, 12 - 25 teeth |
| Chain | Shimano 105 |
Brakes
| Brakes | Shimano 105 Dual Pivot brakes, Shimano 105 STI levers |
|---|
Cockpit & Contact Points
| Headset | FSA Orbit C#8 |
|---|---|
| Handlebar | FSA RD305 OS |
| Handlebar Extensions | Not included |
| Stem | FSA OS-150XT |
| Saddle | Selle Italia XR Light Maganese |
| Seatpost | FSA SL-280 |
Wheels & Tires
| Hubs | Mavic Aksium |
|---|---|
| Rims | Mavic Aksium |
| Front Tire | 700 x 23c Continental Ultrarace |
| Wheel Size | 700c wheels |
No specifications match. Try a component name or clear your search.
Gearing
Lower gears help on climbs. Higher gears suit higher speeds.
RPM
RPM = pedal turns per minute.
How it works
Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.
Speeds are estimates from tire size and pedal cadence. Actual speeds vary.
Try your current gearingChanged tires or gears? Calculate your setup.
Your changes apply to this calculation. The archived build stays unchanged.
Gearing results
| Measure | Original | Your setup |
|---|---|---|
| Lowest ratio | — | — |
| Highest ratio | — | — |
| Total range | — | — |
| Lowest-gear speed | — | — |
| Highest-gear speed | — | — |
Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.
Parts & serviceability
Find replacement parts
700 x 23c Continental Ultrarace
Retailer offers
Vittoria Rubino Pro G2.0 Clincher Tire Black, 700x23
700x23c
Replacement option
Continental Ultrarace on eBaySponsored links
Shimano 105
FSA BB30
More parts (10)Fewer parts
Selle Italia XR Light Maganese
FSA Gossamer Compact
34/50 teeth
Shimano 105
Before ordering: Confirm whether the drivetrain is mechanical or electronic before ordering.
Shimano Ultegra
Before ordering: Confirm whether the drivetrain is mechanical or electronic before ordering.
Shimano 105 STI
Before ordering: Confirm whether the drivetrain is mechanical or electronic before ordering.
FSA RD305 OS
FSA OS-150XT
FSA Orbit C#8
Mavic Aksium
Mavic Aksium
Based on the original build. Check fit and installed parts before ordering. Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.
Parts and service referenceQuick reference before buying parts
Archived specifications for reference. Check the fitted parts before ordering.
- Front tire
- 700 x 23c Continental Ultrarace
- Drivetrain
- 10-speed
- Bottom bracket / shell
- FSA BB30 · 68mm
Equipment inspection checks 10 checks based on 5 archived component groups Open equipment checksClose equipment checks
Checks selected from the archived equipment. Confirm what is fitted today. This is not a complete safety inspection; use the full inspection guide before test riding.
Full used-bike inspection guide →
Frame and fork
Inspect the frame and fork →Archived: Frame: Monocoque · Fork: Dedacciai Fin Carbon · Carbon, aero crown
Drivetrain
Check drivetrain wear →Archived: Group: Shimano 105 · Shifters: Shimano 105 STI · Front derailleur: Shimano 105 · Rear derailleur: Shimano Ultegra · Crankset: FSA Gossamer Compact, 34/50 teeth · Bottom bracket: FSA BB30 · Cassette: Shimano 105 · Rear cogs: 10-speed, 12 - 25 teeth · Chain: Shimano 105
Brakes
Inspect the brakes →Archived: Brakes: Shimano 105 Dual Pivot brakes, Shimano 105 STI levers
Wheels and tires
Check wheels and tires →Archived: Wheel size: 700c wheels · Rims: Mavic Aksium · Hubs: Mavic Aksium · Front tire: 700 x 23c Continental Ultrarace
Controls and contact points
Archived: Headset: FSA Orbit C#8 · Handlebar: FSA RD305 OS · Stem: FSA OS-150XT · Seatpost: FSA SL-280 · Saddle: Selle Italia XR Light Maganese
Have you owned this model?Help document firsthand fit, ride and maintenance details that may no longer be available.
This archive record has limited published detail. Share what would help another rider understand how this model fit, rode and held up over time. Velopedia reviews every contribution before publication.
Already contributed? Send me a fresh private edit link
For privacy, Velopedia shows the same confirmation whether or not an experience exists.
Checking current listings…
Find this bike on eBay
Search eBay US; check the model year, size and installed components. We may earn a commission from purchases.
Specifications are presented as a reference. Components may vary by market, size, production run, or later manufacturer revisions.
