Lowest0.69:1
Highest4.00:1
Total range582%
Estimated speed At 90 RPM
Lowest gear
Highest gear
Uses front tire 26×2.1; rear size isn’t listed.
Velopedia Bicycle Archive
2007 Kona Kula Deluxe
Original specifications: Shimano Deore LX drivetrain · 26" wheels.
Planning to sell? Draft your listing
No archive photo is available for this record.
At a glance
Archive #95191- Model year
- 2007
- Category
- Mountain
- Original MSRP
- $1,499.00
- Sizes
- 14", 16", 17", 18", 19", 20", 22"
- Colors
- Wine Red/White
- In this record
- 24 specifications · original MSRP
Model history 7 other years
Browse other years
Compare side by side
Identification clues
2007 archived details
- Published colors
- Wine Red/White
- Frame
- Easton Ultralite
- Original equipment
- Shimano Deore LX
Clues, not proof of model year. Colors vary and components may have been replaced.
Original buildEaston Ultralite · Shimano Deore LX · 26" wheels
Frameset
| Frame Construction | TIG-welded |
|---|---|
| Frame Material | Easton Ultralite |
| Fork | Rock Shox Recon 351 Air, 100mm travel |
| Fork Material | Single |
Drivetrain
| Component Group | Shimano Deore LX |
|---|---|
| Shifters | Shimano LX |
| Front Derailleur | Shimano LX |
| Rear Derailleur | Shimano XT |
| Crankset | RaceFace Evolve XC X-Type, 44/32/22 teeth |
| Bottom Bracket | Race Face Evolve XC X-Type |
| Rear Cogs | 9-speed, 11 - 32 teeth |
| Chain | Shimano CN-HG53, 1/2 x 3/32" |
| Pedals | Shimano PD-M505 |
Brakes
| Brakes | Hayes HFX-9 XC brakes, Hayes HFX-9 XC levers |
|---|
Cockpit & Contact Points
| Headset | 1 1/8" threadless TH |
|---|---|
| Handlebar | Easton EA30 OS |
| Stem | Easton EA30 OS |
| Saddle | WTB Rocket V Comp |
| Seatpost | Easton EA30 |
Wheels & Tires
| Hubs | Shimano HB-M525 Disc |
|---|---|
| Rims | Sun DS2-XC |
| Spokes | DT Swiss stainless steel, 14/15ga. (2.0/1.8mm) |
| Front Tire | 26 x 2.10" Maxxis Ignitor |
| Wheel Size | 26" wheels |
No specifications match. Try a component name or clear your search.
Gearing
Lower gears help on climbs. Higher gears suit higher speeds.
RPM
RPM = pedal turns per minute.
How it works
Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.
Speeds are estimates from tire size and pedal cadence. Actual speeds vary.
Try your current gearingChanged tires or gears? Calculate your setup.
Your changes apply to this calculation. The archived build stays unchanged.
Gearing results
| Measure | Original | Your setup |
|---|---|---|
| Lowest ratio | — | — |
| Highest ratio | — | — |
| Total range | — | — |
| Lowest-gear speed | — | — |
| Highest-gear speed | — | — |
Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.
Parts & serviceability
Find replacement parts
Race Face Evolve XC X-Type
More parts (10)Fewer parts
Shimano PD-M505
WTB Rocket V Comp
RaceFace Evolve XC X-Type
44/32/22 teeth
Shimano LX
Shimano XT
Shimano LX
Easton EA30 OS
Easton EA30 OS
Easton EA30
Shimano HB-M525 Disc
Based on the original build. Check fit and installed parts before ordering. Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.
Parts and service referenceQuick reference before buying parts
Archived specifications for reference. Check the fitted parts before ordering.
- Front tire
- 26 x 2.10" Maxxis Ignitor
- Drivetrain
- 9-speed
- Bottom bracket / shell
- Race Face Evolve XC X-Type
Equipment inspection checks 11 checks based on 6 archived component groups Open equipment checksClose equipment checks
Checks selected from the archived equipment. Confirm what is fitted today. This is not a complete safety inspection; use the full inspection guide before test riding.
Full used-bike inspection guide →
Frame and fork
Inspect the frame and fork →Archived: Frame: TIG-welded · Fork: Rock Shox Recon 351 Air, 100mm travel · Single
Suspension
Evaluate the suspension →Archived: Fork: Rock Shox Recon 351 Air, 100mm travel
Drivetrain
Check drivetrain wear →Archived: Group: Shimano Deore LX · Shifters: Shimano LX · Front derailleur: Shimano LX · Rear derailleur: Shimano XT · Crankset: RaceFace Evolve XC X-Type, 44/32/22 teeth · Bottom bracket: Race Face Evolve XC X-Type · Rear cogs: 9-speed, 11 - 32 teeth · Chain: Shimano CN-HG53, 1/2 x 3/32"
Brakes
Inspect the brakes →Archived: Brakes: Hayes HFX-9 XC brakes, Hayes HFX-9 XC levers
Wheels and tires
Check wheels and tires →Archived: Wheel size: 26" wheels · Rims: Sun DS2-XC · Hubs: Shimano HB-M525 Disc · Front tire: 26 x 2.10" Maxxis Ignitor
Controls and contact points
Archived: Headset: 1 1/8" threadless TH · Handlebar: Easton EA30 OS · Stem: Easton EA30 OS · Seatpost: Easton EA30 · Saddle: WTB Rocket V Comp · Pedals: Shimano PD-M505
Have you owned this model?Help document firsthand fit, ride and maintenance details that may no longer be available.
This archive record has limited published detail. Share what would help another rider understand how this model fit, rode and held up over time. Velopedia reviews every contribution before publication.
Already contributed? Send me a fresh private edit link
For privacy, Velopedia shows the same confirmation whether or not an experience exists.
Find this bike on eBay
Search eBay US; check the model year, size and installed components. We may earn a commission from purchases.
Specifications are presented as a reference. Components may vary by market, size, production run, or later manufacturer revisions.
