2004 Kona Makena

Original specifications: Shimano Tourney · 6-speed · mechanical rear derailleur · 20" wheels · 24.9 lb published weight.

Share owner experience

At a glance

Archive #10001

Model year: 2004
Category: Kids
Original MSRP: $229.00
Sizes: Boys 13"
Colors: Blue
Weight: 24.9 lb
In this record: 26 specifications · archived image · original MSRP

Model history 17 other years

Browse other years

Compare side by side

Identification clues

2004 archived details

Published colors: Blue
Frame: 7005 aluminum
Original equipment: Juvenile Mix

Clues, not proof of model year. Colors vary and components may have been replaced.

Original build7005 aluminum · Juvenile Mix · 20" wheels

Manufacturer catalog

Published sizes and colors

1 size · 1 color

Manufacturer-published sizes and colors; availability and exact size/color pairings may vary by market or production run.

Published sizes

Boys 13"

Published colors

Blue

Frameset

Frame Construction	TIG-welded
Frame Material	7005 aluminum
Fork	Suntour M-5000
Fork Material	Aluminum/steel, single crown

Drivetrain

Component Group	Juvenile Mix
Shifters	Shimano Revo 6-speed
Rear Derailleur	Shimano Tourney
Crankset	Prowheel, 40 teeth
Bottom Bracket	Chin Haur CH-32
BB Shell Width	68mm English
Rear Cogs	6-speed, 14 - 28 teeth
Chain	KMC Z50, 1/2 x 3/32"
Pedals	Victor VP resin

Brakes

Brakes	APSE linear pull brakes, APSE linear pull levers

Cockpit & Contact Points

Headset	1" threaded Victor VP-501
Handlebar	Kona Riser
Handlebar Extensions	Not included
Stem	Steel, high rise
Saddle	Velo Juvenile
Seatpost	Strong

Wheels & Tires

Hubs	Joy Tech steel, nutted
Rims	Strong Aluminum, 36-hole
Spokes	Stainless steel, 14ga. (2.0mm) straight gauge
Spoke Nipples	Brass nipples
Front Tire	20 x 1.95" Cheng Shin
Wheel Size	20" wheels

Gearing

Lower gears help on climbs. Higher gears suit higher speeds.

Pedal cadence

RPM

Speed units

RPM = pedal turns per minute.

Published build40T · 14–28T · 6-speed

Lowest1.43:1 Highest2.86:1 Total range200%

Estimated speed At 90 RPM Lowest gear7.6 mph Highest gear15.2 mph

Uses front tire 20×1.95; rear size isn’t listed.

How it works

Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.

Speeds are estimates from tire size and pedal cadence. Actual speeds vary.

Try other gearing

Try your current gearingChanged tires or gears? Calculate your setup.

Your changes apply to this calculation. The archived build stays unchanged.

Gears Drivetrain

Front teeth Smallest rear teeth Largest rear teeth

Use up to three front tooth counts, separated by /. For one rear sprocket, enter the same count twice.

Rear tire

Rear tire marking

Apply the marking on your rear tire or edit its dimensions below. Older or fractional inch sizes need the ISO marking (e.g. 37-590).

Rim diameter (BSD, mm) Tire width (mm)

For 32-622, width is 32 mm and rim diameter is 622 mm. Use the rear tire on mixed-wheel bikes. Leave both fields empty to compare ratios only.

Cadence (RPM) Speed units

Gear, dimension and cadence changes update results automatically.

Gearing comparison
Measure	Original	Your setup
Lowest ratio	—	—
Highest ratio	—	—
Total range	—	—
Lowest-gear speed	—	—
Highest-gear speed	—	—

Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.
