2013 KHS Flite 223 Ladies

Original specifications.

Share owner experience

At a glance

Archive #9240291

Model year: 2013
Category: Road
Sizes: XS, S
Colors: Infinite Black
In this record: 17 specifications · archived image

Model history 1 other year

Browse other years

Compare side by side

Identification clues

2013 archived details

Published colors: Infinite Black
Frame: Chromoly

Clues, not proof of model year. Colors vary and components may have been replaced.

Original buildChromoly

Manufacturer catalog

Published sizes and colors

2 sizes · 1 color

Manufacturer-published sizes and colors; availability and exact size/color pairings may vary by market or production run.

Published sizes

XSS

Published colors

Infinite Black

Frameset

Frame Material	Chromoly
Fork	Hi-Tensile Steel

Drivetrain

Shifters	Shimano 2303
Front Derailleur	Shimano 2303
Rear Derailleur	Shimano 2300
Crankset	Shimano 2300 52/42/30t
Bottom Bracket	Sealed Cartridge
Cassette	Shimano 12x25t
Rear Cogs	3x8 Speeds
Chain	KMC Z8

Brakes

Brakes	Alloy Road Caliper

Cockpit & Contact Points

Headset	1 1/8" Threadless
Handlebar	Alloy Road
Stem	Alloy
Saddle	KHS Road
Seatpost	Alloy Micro Adjust

Wheels & Tires

Front Tire	Kenda Kontender 700x26

Gearing

Lower gears help on climbs. Higher gears suit higher speeds.

All published sizes52/42/30T · 12–25T

Lowest1.20:1 Highest4.33:1 Total range361%

Speed unavailable: wheel or tire size is missing or unclear.

Add your rear tire size to calculate speed

How it works

Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.

Speeds are estimates from tire size and pedal cadence. Actual speeds vary.

Try other gearing

Try your current gearingChanged tires or gears? Calculate your setup.

Your changes apply to this calculation. The archived build stays unchanged.

Gears Drivetrain

Front teeth Smallest rear teeth Largest rear teeth

Use up to three front tooth counts, separated by /. For one rear sprocket, enter the same count twice.

Rear tire

Rear tire marking

Apply the marking on your rear tire or edit its dimensions below. Older or fractional inch sizes need the ISO marking (e.g. 37-590).

Rim diameter (BSD, mm) Tire width (mm)

For 32-622, width is 32 mm and rim diameter is 622 mm. Use the rear tire on mixed-wheel bikes. Leave both fields empty to compare ratios only.

Cadence (RPM) Speed units

Gear, dimension and cadence changes update results automatically.

Gearing comparison
Measure	Original	Your setup
Lowest ratio	—	—
Highest ratio	—	—
Total range	—	—
Lowest-gear speed	—	—
Highest-gear speed	—	—

Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.

Parts & serviceability

Find replacement parts

Original specifications

Chain · Original

KMC Z8

Search Amazon Search eBay

Retailer offers

SRAM PC-830 Chain One Color, 8 Speed

Replacement option

Competitive Cyclist ↗$11.00

Front tire · Original

Kenda Kontender 700x26

Search Amazon Search eBay

Retailer offers

Pirelli P7 Sport Clincher Tire Black, 700x26

700x26c

Replacement option

Competitive Cyclist ↗$47.12

Cassette · Original

Shimano 12x25t

Search Amazon Search eBay

Based on the original build. Check fit and installed parts before ordering. Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.

Parts and service referenceQuick reference before buying parts

Archived specifications for reference. Check the fitted parts before ordering.

Front tire: Kenda Kontender 700x26
Bottom bracket / shell: Sealed Cartridge

Equipment inspection checks 8 checks based on 4 archived component groups Open equipment checksClose equipment checks

Checks selected from the archived equipment. Confirm what is fitted today. This is not a complete safety inspection; use the full inspection guide before test riding.

Full used-bike inspection guide →

Frame and fork

Inspect the frame and fork →

Archived: Frame: Chromoly · Fork: Hi-Tensile Steel

Check paint damage, vent holes and accessible internal surfaces for corrosion. Look for dents, bent tubes and cracking around welded or brazed joints.
Inspect the fork crown, blades, dropouts and visible steerer area. Check that it is straight, securely installed and free of cracks or impact damage.

Drivetrain

Check drivetrain wear →

Archived: Shifters: Shimano 2303 · Front derailleur: Shimano 2303 · Rear derailleur: Shimano 2300 · Crankset: Shimano 2300 52/42/30t · Bottom bracket: Sealed Cartridge · Cassette: Shimano 12x25t · Rear cogs: 3x8 Speeds · Chain: KMC Z8

Shift through every available gear under light load. Hesitation, skipping or inconsistent indexing can reflect wear, damage, poor adjustment or mismatched replacement parts.
Measure chain wear with a compatible gauge and inspect chainring, cassette or freewheel teeth. A new chain does not rule out wear in the remaining drivetrain.
Turn the cranks slowly, feel for rough bearings and check for side-to-side play. Inspect crank arms, chainring bolts and pedal threads for looseness or damage.

Brakes

Inspect the brakes →

Archived: Brakes: Alloy Road Caliper

Inspect pads, cables and housings, then examine both rim braking surfaces for concavity, cracking or heavy wear. Confirm each caliper returns and centers correctly.

Controls and contact points

Archived: Headset: 1 1/8" Threadless · Handlebar: Alloy Road · Stem: Alloy · Seatpost: Alloy Micro Adjust · Saddle: KHS Road

Apply the front brake and rock the bike to check for headset play or notchiness. Inspect the stem, handlebar and clamp zones, then confirm every fastener and control is secure.
Check that the seatpost moves for adjustment and that the saddle, post and clamp hold securely without cracks, severe corrosion or damaged hardware.
