Velopedia Bicycle Archive

2012 KHS Tucson

Original specifications.

Share owner experience

Planning to sell? Draft your listing

At a glance

Archive #2025575
Model year
2012
Category
Mountain
Sizes
S
Colors
Ghost White
In this record
18 specifications · 2 archived images
Model history 2 other years

Browse other years

Compare side by side

Identification clues

2012 archived details

Published colors
Ghost White
Frame
Alloy 6061 Double Butted

Clues, not proof of model year. Colors vary and components may have been replaced.

Campaign
Original buildAlloy 6061 Double Butted

Manufacturer catalog

Published sizes and colors

1 size · 1 color

Manufacturer-published sizes and colors; availability and exact size/color pairings may vary by market or production run.

Published sizes

S

Published colors

Ghost White

Frameset

Frame MaterialAlloy 6061 Double Butted
ForkRST M29 Air 100mm

Drivetrain

ShiftersShimano Deore
Front DerailleurShimano Deore
Rear DerailleurShimano SLX
CranksetShimano Deore 42/32/24t
Bottom BracketShimano outboard cartridge
CassetteShimano Deore 10spd 11-36t
ChainKMC X-10
PedalsWellgo Alloy

Brakes

BrakesAvid Elixir 1 160mm

Cockpit & Contact Points

HeadsetCane Creek 1 1/8"
HandlebarAlloy 31.8
StemAlloy 3D forged
SaddleWTB Volt Comp
SeatpostAlloy 31.6

Wheels & Tires

RimsWTB Speed Disc 29
Front TireKenda Small Block 8 29x2.1"

Gearing

Lower gears help on climbs. Higher gears suit higher speeds.

All published sizes42/32/24T · 11–36T · 10-speed
Lowest0.67:1 Highest3.82:1 Total range573%

Speed unavailable: wheel or tire size is missing or unclear.

Add your rear tire size to calculate speed
How it works

Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.

Speeds are estimates from tire size and pedal cadence. Actual speeds vary.

Try other gearing

Try your current gearingChanged tires or gears? Calculate your setup.

Your changes apply to this calculation. The archived build stays unchanged.

Your gearing setup
Gears

Use up to three front tooth counts, separated by /. For one rear sprocket, enter the same count twice.

Rear tire

Apply the marking on your rear tire or edit its dimensions below. Older or fractional inch sizes need the ISO marking (e.g. 37-590).

For 32-622, width is 32 mm and rim diameter is 622 mm. Use the rear tire on mixed-wheel bikes. Leave both fields empty to compare ratios only.

Gear, dimension and cadence changes update results automatically.

Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.

Parts & serviceability

Find replacement parts

Original specifications
Front tire · Original
Kenda Small Block 8 29x2.1"
Retailer offers
Chain · Original
KMC X-10
Cassette · Original
Shimano Deore 10spd 11-36t
More parts (6)Fewer parts
Bottom bracket · Original
Shimano outboard cartridge
Saddle · Original
WTB Volt Comp
Crankset · Original
Shimano Deore 42/32/24t
Front derailleur · Original
Shimano Deore
Rear derailleur · Original
Shimano SLX
Shifters · Original
Shimano Deore

Based on the original build. Check fit and installed parts before ordering. Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.

Parts and service referenceQuick reference before buying parts

Archived specifications for reference. Check the fitted parts before ordering.

Front tire
Kenda Small Block 8 29x2.1"
Drivetrain
10-speed
Bottom bracket / shell
Shimano outboard cartridge
Equipment inspection checks 10 checks based on 5 archived component groups Open equipment checksClose equipment checks
0 of 10 checked Progress stays in this browser for this record.

Checks selected from the archived equipment. Confirm what is fitted today. This is not a complete safety inspection; use the full inspection guide before test riding.

Full used-bike inspection guide →

Archived: Frame: Alloy 6061 Double Butted · Fork: RST M29 Air 100mm

Archived: Shifters: Shimano Deore · Front derailleur: Shimano Deore · Rear derailleur: Shimano SLX · Crankset: Shimano Deore 42/32/24t · Bottom bracket: Shimano outboard cartridge · Cassette: Shimano Deore 10spd 11-36t · Chain: KMC X-10

Archived: Brakes: Avid Elixir 1 160mm

Archived: Rims: WTB Speed Disc 29 · Front tire: Kenda Small Block 8 29x2.1"

Controls and contact points

Archived: Headset: Cane Creek 1 1/8" · Handlebar: Alloy 31.8 · Stem: Alloy 3D forged · Seatpost: Alloy 31.6 · Saddle: WTB Volt Comp · Pedals: Wellgo Alloy
